6 PL/SQL Static SQL
Static SQL is a PL/SQL feature that allows SQL syntax directly in a PL/SQL statement.
This chapter describes static SQL and explains how to use it.
Topics
See Also:
6.1 Description of Static SQL
6.1.1 Statements
These are the PL/SQL static SQL statements, which have the same syntax as the corresponding SQL statements, except as noted:
-
SELECT
(this statement is also called a query)For the PL/SQL syntax, see "SELECT INTO Statement".
-
Data manipulation language (DML) statements:
-
INSERT
For the PL/SQL syntax, see "INSERT Statement Extension".
-
UPDATE
For the PL/SQL syntax, see "UPDATE Statement Extensions".
-
DELETE
For the PL/SQL syntax, see "DELETE Statement Extension".
-
MERGE
(for syntax, see Oracle Database SQL Language Reference)
Note:
Oracle Database SQL Language Reference defines DML differently.
-
-
Transaction control language (TCL) statements:
-
COMMIT
(for syntax, see Oracle Database SQL Language Reference) -
ROLLBACK
(for syntax, see Oracle Database SQL Language Reference) -
SAVEPOINT
(for syntax, see Oracle Database SQL Language Reference) -
SET
TRANSACTION
(for syntax, see Oracle Database SQL Language Reference)
-
-
LOCK
TABLE
(for syntax, see Oracle Database SQL Language Reference)
A PL/SQL static SQL statement can have a PL/SQL identifier wherever its SQL counterpart can have a placeholder for a bind variable. The PL/SQL identifier must identify either a variable or a formal parameter.
To use PL/SQL identifiers for table names, column names, and so on, use the EXECUTE
IMMEDIATE
statement, explained in "Native Dynamic SQL"
Note:
After PL/SQL code runs a DML statement, the values of some variables are undefined. For example:
-
After a
FETCH
orSELECT
statement raises an exception, the values of the define variables after that statement are undefined. -
After a DML statement that affects zero rows, the values of the
OUT
bind variables are undefined, unless the DML statement is aBULK
or multiple-row operation.
Example 6-1 Static SQL Statements
In this example, a PL/SQL anonymous block declares three PL/SQL variables and uses them in the static SQL statements INSERT
, UPDATE
, DELETE
. The block also uses the static SQL statement COMMIT
.
DROP TABLE employees_temp; CREATE TABLE employees_temp AS SELECT employee_id, first_name, last_name FROM employees; DECLARE emp_id employees_temp.employee_id%TYPE := 299; emp_first_name employees_temp.first_name%TYPE := 'Bob'; emp_last_name employees_temp.last_name%TYPE := 'Henry'; BEGIN INSERT INTO employees_temp (employee_id, first_name, last_name) VALUES (emp_id, emp_first_name, emp_last_name); UPDATE employees_temp SET first_name = 'Robert' WHERE employee_id = emp_id; DELETE FROM employees_temp WHERE employee_id = emp_id RETURNING first_name, last_name INTO emp_first_name, emp_last_name; COMMIT; DBMS_OUTPUT.PUT_LINE (emp_first_name || ' ' || emp_last_name); END; /
Result:
Robert Henry
6.1.2 Pseudocolumns
A pseudocolumn behaves like a table column, but it is not stored in the table.
For general information about pseudocolumns, including restrictions, see Oracle Database SQL Language Reference.
Static SQL includes these SQL pseudocolumns:
-
CURRVAL
andNEXTVAL
, described in "CURRVAL and NEXTVAL in PL/SQL". -
LEVEL
, described in Oracle Database SQL Language Reference -
OBJECT_VALUE
, described in Oracle Database SQL Language ReferenceSee Also:
"OBJECT_VALUE Pseudocolumn" for information about using
OBJECT_VALUE
in triggers -
ROWID
, described in Oracle Database SQL Language Reference -
ROWNUM
, described in Oracle Database SQL Language Reference
6.1.2.1 CURRVAL and NEXTVAL in PL/SQL
After a sequence is created, you can access its values in SQL statements with the CURRVAL
pseudocolumn, which returns the current value of the sequence, or the NEXTVAL
pseudocolumn, which increments the sequence and returns the new value.
To reference these pseudocolumns, use dot notation—for example, sequence_name
.CURRVAL
.
Note:
Each time you reference sequence_name
.NEXTVAL
, the sequence is incremented immediately and permanently, whether you commit or roll back the transaction.
You can use sequence_name
.CURRVAL
and sequence_name
.NEXTVAL
in a PL/SQL expression wherever you can use a NUMBER
expression. However:
-
Using
sequence_name
.CURRVAL
orsequence_name
.NEXTVAL
to provide a default value for an ADT method parameter causes a compilation error. -
PL/SQL evaluates every occurrence of
sequence_name
.CURRVAL
andsequence_name
.NEXTVAL
(unlike SQL, which evaluates a sequence expression for every row in which it appears).
See Also:
-
Oracle Database SQL Language Reference for general information about sequences
-
Oracle Database SQL Language Reference for
CURRVAL
andNEXTVAL
complete syntax
Example 6-2 CURRVAL and NEXTVAL Pseudocolumns
This example generates a sequence number for the sequence HR.EMPLOYEES_SEQ
and refers to that number in multiple statements.
DROP TABLE employees_temp; CREATE TABLE employees_temp AS SELECT employee_id, first_name, last_name FROM employees; DROP TABLE employees_temp2; CREATE TABLE employees_temp2 AS SELECT employee_id, first_name, last_name FROM employees; DECLARE seq_value NUMBER; BEGIN -- Generate initial sequence number seq_value := employees_seq.NEXTVAL; -- Print initial sequence number: DBMS_OUTPUT.PUT_LINE ( 'Initial sequence value: ' || TO_CHAR(seq_value) ); -- Use NEXTVAL to create unique number when inserting data: INSERT INTO employees_temp (employee_id, first_name, last_name) VALUES (employees_seq.NEXTVAL, 'Lynette', 'Smith'); -- Use CURRVAL to store same value somewhere else: INSERT INTO employees_temp2 VALUES (employees_seq.CURRVAL, 'Morgan', 'Smith'); /* Because NEXTVAL values might be referenced by different users and applications, and some NEXTVAL values might not be stored in database, there might be gaps in sequence. */ -- Use CURRVAL to specify record to delete: seq_value := employees_seq.CURRVAL; DELETE FROM employees_temp2 WHERE employee_id = seq_value; -- Update employee_id with NEXTVAL for specified record: UPDATE employees_temp SET employee_id = employees_seq.NEXTVAL WHERE first_name = 'Lynette' AND last_name = 'Smith'; -- Display final value of CURRVAL: seq_value := employees_seq.CURRVAL; DBMS_OUTPUT.PUT_LINE ( 'Ending sequence value: ' || TO_CHAR(seq_value) ); END; /
6.2 Cursors Overview
A cursor is a pointer to a private SQL area that stores information about processing a specific SELECT
or DML statement.
Note:
The cursors that this topic explains are session cursors. A session cursor lives in session memory until the session ends, when it ceases to exist.
A cursor that is constructed and managed by PL/SQL is an implicit cursor. A cursor that you construct and manage is an explicit cursor.
You can get information about any session cursor from its attributes (which you can reference in procedural statements, but not in SQL statements).
To list the session cursors that each user session currently has opened and parsed, query the dynamic performance view V$OPEN_CURSOR
.
The number of cursors that a session can have open simultaneously is determined by:
-
The amount of memory available to the session
-
The value of the initialization parameter
OPEN_CURSORS
Note:
Generally, PL/SQL parses an explicit cursor only the first time the session opens it and parses a SQL statement (creating an implicit cursor) only the first time the statement runs.
All parsed SQL statements are cached. A SQL statement is reparsed only if it is aged out of the cache by a new SQL statement. Although you must close an explicit cursor before you can reopen it, PL/SQL need not reparse the associated query. If you close and immediately reopen an explicit cursor, PL/SQL does not reparse the associated query.
Topics
See Also:
-
Oracle Database Reference for information about the dynamic performance view
V$OPEN_CURSOR
-
Oracle Database Reference for information about the initialization parameter
OPEN_CURSORS
6.2.1 Implicit Cursors
An implicit cursor is a session cursor that is constructed and managed by PL/SQL. PL/SQL opens an implicit cursor every time you run a SELECT
or DML statement. You cannot control an implicit cursor, but you can get information from its attributes.
The syntax of an implicit cursor attribute value is SQL
attribute
(therefore, an implicit cursor is also called a SQL cursor). SQL
attribute
always refers to the most recently run SELECT
or DML statement. If no such statement has run, the value of SQL
attribute
is NULL
.
An implicit cursor closes after its associated statement runs; however, its attribute values remain available until another SELECT
or DML statement runs.
The most recently run SELECT
or DML statement might be in a different scope. To save an attribute value for later use, assign it to a local variable immediately. Otherwise, other operations, such as subprogram invocations, might change the value of the attribute before you can test it.
The implicit cursor attributes are:
-
SQL%BULK_ROWCOUNT
(see "Getting Number of Rows Affected by FORALL Statement" -
SQL%BULK_EXCEPTIONS
(see "Handling FORALL Exceptions After FORALL Statement Completes"
See Also:
"Implicit Cursor Attribute" for complete syntax and semantics
6.2.1.1 SQL%ISOPEN Attribute: Is the Cursor Open?
SQL%ISOPEN
always returns FALSE
, because an implicit cursor always closes after its associated statement runs.
6.2.1.2 SQL%FOUND Attribute: Were Any Rows Affected?
SQL%FOUND
returns:
-
NULL
if noSELECT
or DML statement has run -
TRUE
if aSELECT
statement returned one or more rows or a DML statement affected one or more rows -
FALSE
otherwise
Example 6-3 uses SQL%FOUND
to determine if a DELETE
statement affected any rows.
Example 6-3 SQL%FOUND Implicit Cursor Attribute
DROP TABLE dept_temp;
CREATE TABLE dept_temp AS
SELECT * FROM departments;
CREATE OR REPLACE PROCEDURE p (
dept_no NUMBER
) AUTHID CURRENT_USER AS
BEGIN
DELETE FROM dept_temp
WHERE department_id = dept_no;
IF SQL%FOUND THEN
DBMS_OUTPUT.PUT_LINE (
'Delete succeeded for department number ' || dept_no
);
ELSE
DBMS_OUTPUT.PUT_LINE ('No department number ' || dept_no);
END IF;
END;
/
BEGIN
p(270);
p(400);
END;
/
Result:
Delete succeeded for department number 270 No department number 400
6.2.1.3 SQL%NOTFOUND Attribute: Were No Rows Affected?
SQL%NOTFOUND
(the logical opposite of SQL%FOUND
) returns:
-
NULL
if noSELECT
or DML statement has run -
FALSE
if aSELECT
statement returned one or more rows or a DML statement affected one or more rows -
TRUE
otherwise
The SQL%NOTFOUND
attribute is not useful with the PL/SQL SELECT
INTO
statement, because:
-
If the
SELECT
INTO
statement returns no rows, PL/SQL raises the predefined exceptionNO_DATA_FOUND
immediately, before you can checkSQL%NOTFOUND
. -
A
SELECT
INTO
statement that invokes a SQL aggregate function always returns a value (possiblyNULL
). After such a statement, theSQL%NOTFOUND
attribute is alwaysFALSE
, so checking it is unnecessary.
6.2.1.4 SQL%ROWCOUNT Attribute: How Many Rows Were Affected?
SQL%ROWCOUNT
returns:
-
NULL
if noSELECT
or DML statement has run -
Otherwise, the number of rows returned by a
SELECT
statement or affected by a DML statement (anINTEGER
)
Note:
If a server is Oracle Database 12c or later and its client is Oracle Database 11g release 2 or earlier (or the reverse), then the maximum number that SQL%ROWCOUNT
returns is 4,294,967,295.
Example 6-4 uses SQL%ROWCOUNT
to determine the number of rows that were deleted.
If a SELECT
INTO
statement without a BULK
COLLECT
clause returns multiple rows, PL/SQL raises the predefined exception TOO_MANY_ROWS
and SQL%ROWCOUNT
returns 1, not the actual number of rows that satisfy the query.
The value of SQL%ROWCOUNT
attribute is unrelated to the state of a transaction. Therefore:
-
When a transaction rolls back to a savepoint, the value of
SQL%ROWCOUNT
is not restored to the value it had before the savepoint. -
When an autonomous transaction ends,
SQL%ROWCOUNT
is not restored to the original value in the parent transaction.
Example 6-4 SQL%ROWCOUNT Implicit Cursor Attribute
DROP TABLE employees_temp;
CREATE TABLE employees_temp AS
SELECT * FROM employees;
DECLARE
mgr_no NUMBER(6) := 122;
BEGIN
DELETE FROM employees_temp WHERE manager_id = mgr_no;
DBMS_OUTPUT.PUT_LINE
('Number of employees deleted: ' || TO_CHAR(SQL%ROWCOUNT));
END;
/
Result:
Number of employees deleted: 8
6.2.2 Explicit Cursors
An explicit cursor is a session cursor that you construct and manage. You must declare and define an explicit cursor, giving it a name and associating it with a query (typically, the query returns multiple rows). Then you can process the query result set in either of these ways:
-
Open the explicit cursor (with the
OPEN
statement), fetch rows from the result set (with theFETCH
statement), and close the explicit cursor (with theCLOSE
statement). -
Use the explicit cursor in a cursor
FOR
LOOP
statement (see "Processing Query Result Sets With Cursor FOR LOOP Statements".
You cannot assign a value to an explicit cursor, use it in an expression, or use it as a formal subprogram parameter or host variable. You can do those things with a cursor variable (see "Cursor Variables").
Unlike an implicit cursor, you can reference an explicit cursor or cursor variable by its name. Therefore, an explicit cursor or cursor variable is called a named cursor.
Topics
6.2.2.1 Declaring and Defining Explicit Cursors
You can either declare an explicit cursor first and then define it later in the same block, subprogram, or package, or declare and define it at the same time.
An explicit cursor declaration, which only declares a cursor, has this syntax:
CURSOR cursor_name [ parameter_list ] RETURN return_type;
An explicit cursor definition has this syntax:
CURSOR cursor_name [ parameter_list ] [ RETURN return_type ] IS select_statement;
If you declared the cursor earlier, then the explicit cursor definition defines it; otherwise, it both declares and defines it.
Example 6-5 declares and defines three explicit cursors.
See Also:
-
"Explicit Cursor Declaration and Definition" for the complete syntax and semantics of explicit cursor declaration and definition
Example 6-5 Explicit Cursor Declaration and Definition
DECLARE CURSOR c1 RETURN departments%ROWTYPE; -- Declare c1 CURSOR c2 IS -- Declare and define c2 SELECT employee_id, job_id, salary FROM employees WHERE salary > 2000; CURSOR c1 RETURN departments%ROWTYPE IS -- Define c1, SELECT * FROM departments -- repeating return type WHERE department_id = 110; CURSOR c3 RETURN locations%ROWTYPE; -- Declare c3 CURSOR c3 IS -- Define c3, SELECT * FROM locations -- omitting return type WHERE country_id = 'JP'; BEGIN NULL; END; /
6.2.2.2 Opening and Closing Explicit Cursors
After declaring and defining an explicit cursor, you can open it with the OPEN
statement, which does the following:
-
Allocates database resources to process the query
-
Processes the query; that is:
-
Identifies the result set
If the query references variables or cursor parameters, their values affect the result set. For details, see "Variables in Explicit Cursor Queries" and "Explicit Cursors that Accept Parameters".
-
If the query has a
FOR
UPDATE
clause, locks the rows of the result setFor details, see "SELECT FOR UPDATE and FOR UPDATE Cursors".
-
-
Positions the cursor before the first row of the result set
You close an open explicit cursor with the CLOSE
statement, thereby allowing its resources to be reused. After closing a cursor, you cannot fetch records from its result set or reference its attributes. If you try, PL/SQL raises the predefined exception INVALID_CURSOR
.
You can reopen a closed cursor. You must close an explicit cursor before you try to reopen it. Otherwise, PL/SQL raises the predefined exception CURSOR_ALREADY_OPEN
.
See Also:
-
"OPEN Statement" for its syntax and semantics
-
"CLOSE Statement" for its syntax and semantics
6.2.2.3 Fetching Data with Explicit Cursors
After opening an explicit cursor, you can fetch the rows of the query result set with the FETCH
statement. The basic syntax of a FETCH
statement that returns one row is:
FETCH cursor_name INTO into_clause
The into_clause
is either a list of variables or a single record variable. For each column that the query returns, the variable list or record must have a corresponding type-compatible variable or field. The %TYPE
and %ROWTYPE
attributes are useful for declaring variables and records for use in FETCH
statements.
The FETCH
statement retrieves the current row of the result set, stores the column values of that row into the variables or record, and advances the cursor to the next row.
Typically, you use the FETCH
statement inside a LOOP
statement, which you exit when the FETCH
statement runs out of rows. To detect this exit condition, use the cursor attribute %NOTFOUND
(described in "%NOTFOUND Attribute: Has No Row Been Fetched?"). PL/SQL does not raise an exception when a FETCH
statement returns no rows.
Example 6-6 fetches the result sets of two explicit cursors one row at a time, using FETCH
and %NOTFOUND
inside LOOP
statements. The first FETCH
statement retrieves column values into variables. The second FETCH
statement retrieves column values into a record. The variables and record are declared with %TYPE
and %ROWTYPE
, respectively.
Example 6-7 fetches the first five rows of a result set into five records, using five FETCH
statements, each of which fetches into a different record variable. The record variables are declared with %ROWTYPE
.
See Also:
-
"FETCH Statement" for its complete syntax and semantics
-
"FETCH Statement with BULK COLLECT Clause" for information about
FETCH
statements that return more than one row at a time
Example 6-6 FETCH Statements Inside LOOP Statements
DECLARE CURSOR c1 IS SELECT last_name, job_id FROM employees WHERE REGEXP_LIKE (job_id, 'S[HT]_CLERK') ORDER BY last_name; v_lastname employees.last_name%TYPE; -- variable for last_name v_jobid employees.job_id%TYPE; -- variable for job_id CURSOR c2 IS SELECT * FROM employees WHERE REGEXP_LIKE (job_id, '[ACADFIMKSA]_M[ANGR]') ORDER BY job_id; v_employees employees%ROWTYPE; -- record variable for row of table BEGIN OPEN c1; LOOP -- Fetches 2 columns into variables FETCH c1 INTO v_lastname, v_jobid; EXIT WHEN c1%NOTFOUND; DBMS_OUTPUT.PUT_LINE( RPAD(v_lastname, 25, ' ') || v_jobid ); END LOOP; CLOSE c1; DBMS_OUTPUT.PUT_LINE( '-------------------------------------' ); OPEN c2; LOOP -- Fetches entire row into the v_employees record FETCH c2 INTO v_employees; EXIT WHEN c2%NOTFOUND; DBMS_OUTPUT.PUT_LINE( RPAD(v_employees.last_name, 25, ' ') || v_employees.job_id ); END LOOP; CLOSE c2; END; /
Result:
Atkinson ST_CLERK Bell SH_CLERK Bissot ST_CLERK ... Walsh SH_CLERK ------------------------------------- Higgins AC_MGR Greenberg FI_MGR Hartstein MK_MAN ... Zlotkey SA_MAN
Example 6-7 Fetching Same Explicit Cursor into Different Variables
DECLARE CURSOR c IS SELECT e.job_id, j.job_title FROM employees e, jobs j WHERE e.job_id = j.job_id AND e.manager_id = 100 ORDER BY last_name; -- Record variables for rows of cursor result set: job1 c%ROWTYPE; job2 c%ROWTYPE; job3 c%ROWTYPE; job4 c%ROWTYPE; job5 c%ROWTYPE; BEGIN OPEN c; FETCH c INTO job1; -- fetches first row FETCH c INTO job2; -- fetches second row FETCH c INTO job3; -- fetches third row FETCH c INTO job4; -- fetches fourth row FETCH c INTO job5; -- fetches fifth row CLOSE c; DBMS_OUTPUT.PUT_LINE(job1.job_title || ' (' || job1.job_id || ')'); DBMS_OUTPUT.PUT_LINE(job2.job_title || ' (' || job2.job_id || ')'); DBMS_OUTPUT.PUT_LINE(job3.job_title || ' (' || job3.job_id || ')'); DBMS_OUTPUT.PUT_LINE(job4.job_title || ' (' || job4.job_id || ')'); DBMS_OUTPUT.PUT_LINE(job5.job_title || ' (' || job5.job_id || ')'); END; /
Result:
Sales Manager (SA_MAN) Administration Vice President (AD_VP) Sales Manager (SA_MAN) Stock Manager (ST_MAN) Marketing Manager (MK_MAN) PL/SQL procedure successfully completed.
6.2.2.4 Variables in Explicit Cursor Queries
An explicit cursor query can reference any variable in its scope. When you open an explicit cursor, PL/SQL evaluates any variables in the query and uses those values when identifying the result set. Changing the values of the variables later does not change the result set.
In Example 6-8, the explicit cursor query references the variable factor
. When the cursor opens, factor
has the value 2. Therefore, sal_multiple
is always 2 times sal
, despite that factor
is incremented after every fetch.
To change the result set, you must close the cursor, change the value of the variable, and then open the cursor again, as in Example 6-9.
Example 6-8 Variable in Explicit Cursor Query—No Result Set Change
DECLARE sal employees.salary%TYPE; sal_multiple employees.salary%TYPE; factor INTEGER := 2; CURSOR c1 IS SELECT salary, salary*factor FROM employees WHERE job_id LIKE 'AD_%'; BEGIN OPEN c1; -- PL/SQL evaluates factor LOOP FETCH c1 INTO sal, sal_multiple; EXIT WHEN c1%NOTFOUND; DBMS_OUTPUT.PUT_LINE('factor = ' || factor); DBMS_OUTPUT.PUT_LINE('sal = ' || sal); DBMS_OUTPUT.PUT_LINE('sal_multiple = ' || sal_multiple); factor := factor + 1; -- Does not affect sal_multiple END LOOP; CLOSE c1; END; /
Result:
factor = 2 sal = 4400 sal_multiple = 8800 factor = 3 sal = 24000 sal_multiple = 48000 factor = 4 sal = 17000 sal_multiple = 34000 factor = 5 sal = 17000 sal_multiple = 34000
Example 6-9 Variable in Explicit Cursor Query—Result Set Change
DECLARE sal employees.salary%TYPE; sal_multiple employees.salary%TYPE; factor INTEGER := 2; CURSOR c1 IS SELECT salary, salary*factor FROM employees WHERE job_id LIKE 'AD_%'; BEGIN DBMS_OUTPUT.PUT_LINE('factor = ' || factor); OPEN c1; -- PL/SQL evaluates factor LOOP FETCH c1 INTO sal, sal_multiple; EXIT WHEN c1%NOTFOUND; DBMS_OUTPUT.PUT_LINE('sal = ' || sal); DBMS_OUTPUT.PUT_LINE('sal_multiple = ' || sal_multiple); END LOOP; CLOSE c1; factor := factor + 1; DBMS_OUTPUT.PUT_LINE('factor = ' || factor); OPEN c1; -- PL/SQL evaluates factor LOOP FETCH c1 INTO sal, sal_multiple; EXIT WHEN c1%NOTFOUND; DBMS_OUTPUT.PUT_LINE('sal = ' || sal); DBMS_OUTPUT.PUT_LINE('sal_multiple = ' || sal_multiple); END LOOP; CLOSE c1; END; /
Result:
factor = 2 sal = 4400 sal_multiple = 8800 sal = 24000 sal_multiple = 48000 sal = 17000 sal_multiple = 34000 sal = 17000 sal_multiple = 34000 factor = 3 sal = 4400 sal_multiple = 13200 sal = 24000 sal_multiple = 72000 sal = 17000 sal_multiple = 51000 sal = 17000 sal_multiple = 51000
6.2.2.5 When Explicit Cursor Queries Need Column Aliases
When an explicit cursor query includes a virtual column (an expression), that column must have an alias if either of the following is true:
-
You use the cursor to fetch into a record that was declared with
%ROWTYPE
. -
You want to reference the virtual column in your program.
In Example 6-10, the virtual column in the explicit cursor needs an alias for both of the preceding reasons.
See Also:
Example 6-10 Explicit Cursor with Virtual Column that Needs Alias
DECLARE CURSOR c1 IS SELECT employee_id, (salary * .05) raise FROM employees WHERE job_id LIKE '%_MAN' ORDER BY employee_id; emp_rec c1%ROWTYPE; BEGIN OPEN c1; LOOP FETCH c1 INTO emp_rec; EXIT WHEN c1%NOTFOUND; DBMS_OUTPUT.PUT_LINE ( 'Raise for employee #' || emp_rec.employee_id || ' is $' || emp_rec.raise ); END LOOP; CLOSE c1; END; /
Result:
Raise for employee #114 is $550 Raise for employee #120 is $400 Raise for employee #121 is $410 Raise for employee #122 is $395 Raise for employee #123 is $325 Raise for employee #124 is $368.445 Raise for employee #145 is $700 Raise for employee #146 is $675 Raise for employee #147 is $600 Raise for employee #148 is $550 Raise for employee #149 is $525 Raise for employee #201 is $650
6.2.2.6 Explicit Cursors that Accept Parameters
You can create an explicit cursor that has formal parameters, and then pass different actual parameters to the cursor each time you open it. In the cursor query, you can use a formal cursor parameter anywhere that you can use a constant. Outside the cursor query, you cannot reference formal cursor parameters.
Tip:
To avoid confusion, use different names for formal and actual cursor parameters.
Example 6-11 creates an explicit cursor whose two formal parameters represent a job and its maximum salary. When opened with a specified job and maximum salary, the cursor query selects the employees with that job who are overpaid (for each such employee, the query selects the first and last name and amount overpaid). Next, the example creates a procedure that prints the cursor query result set (for information about procedures, see PL/SQL Subprograms). Finally, the example opens the cursor with one set of actual parameters, prints the result set, closes the cursor, opens the cursor with different actual parameters, prints the result set, and closes the cursor.
Topics
See Also:
-
"Explicit Cursor Declaration and Definition" for more information about formal cursor parameters
-
"OPEN Statement" for more information about actual cursor parameters
Example 6-11 Explicit Cursor that Accepts Parameters
DECLARE CURSOR c (job VARCHAR2, max_sal NUMBER) IS SELECT last_name, first_name, (salary - max_sal) overpayment FROM employees WHERE job_id = job AND salary > max_sal ORDER BY salary; PROCEDURE print_overpaid IS last_name_ employees.last_name%TYPE; first_name_ employees.first_name%TYPE; overpayment_ employees.salary%TYPE; BEGIN LOOP FETCH c INTO last_name_, first_name_, overpayment_; EXIT WHEN c%NOTFOUND; DBMS_OUTPUT.PUT_LINE(last_name_ || ', ' || first_name_ || ' (by ' || overpayment_ || ')'); END LOOP; END print_overpaid; BEGIN DBMS_OUTPUT.PUT_LINE('----------------------'); DBMS_OUTPUT.PUT_LINE('Overpaid Stock Clerks:'); DBMS_OUTPUT.PUT_LINE('----------------------'); OPEN c('ST_CLERK', 5000); print_overpaid; CLOSE c; DBMS_OUTPUT.PUT_LINE('-------------------------------'); DBMS_OUTPUT.PUT_LINE('Overpaid Sales Representatives:'); DBMS_OUTPUT.PUT_LINE('-------------------------------'); OPEN c('SA_REP', 10000); print_overpaid; CLOSE c; END; /
Result:
---------------------- Overpaid Stock Clerks: ---------------------- ------------------------------- Overpaid Sales Representatives: ------------------------------- Vishney, Clara (by 500) Abel, Ellen (by 1000) Ozer, Lisa (by 1500) PL/SQL procedure successfully completed.
6.2.2.6.1 Formal Cursor Parameters with Default Values
When you create an explicit cursor with formal parameters, you can specify default values for them. When a formal parameter has a default value, its corresponding actual parameter is optional. If you open the cursor without specifying the actual parameter, then the formal parameter has its default value.
Example 6-12 creates an explicit cursor whose formal parameter represents a location ID. The default value of the parameter is the location ID of company headquarters.
Example 6-12 Cursor Parameters with Default Values
DECLARE CURSOR c (location NUMBER DEFAULT 1700) IS SELECT d.department_name, e.last_name manager, l.city FROM departments d, employees e, locations l WHERE l.location_id = location AND l.location_id = d.location_id AND d.department_id = e.department_id ORDER BY d.department_id; PROCEDURE print_depts IS dept_name departments.department_name%TYPE; mgr_name employees.last_name%TYPE; city_name locations.city%TYPE; BEGIN LOOP FETCH c INTO dept_name, mgr_name, city_name; EXIT WHEN c%NOTFOUND; DBMS_OUTPUT.PUT_LINE(dept_name || ' (Manager: ' || mgr_name || ')'); END LOOP; END print_depts; BEGIN DBMS_OUTPUT.PUT_LINE('DEPARTMENTS AT HEADQUARTERS:'); DBMS_OUTPUT.PUT_LINE('--------------------------------'); OPEN c; print_depts; DBMS_OUTPUT.PUT_LINE('--------------------------------'); CLOSE c; DBMS_OUTPUT.PUT_LINE('DEPARTMENTS IN CANADA:'); DBMS_OUTPUT.PUT_LINE('--------------------------------'); OPEN c(1800); -- Toronto print_depts; CLOSE c; OPEN c(1900); -- Whitehorse print_depts; CLOSE c; END; /
Result is similar to:
DEPARTMENTS AT HEADQUARTERS: -------------------------------- Administration (Manager: Whalen) Purchasing (Manager: Colmenares) Purchasing (Manager: Baida) Purchasing (Manager: Himuro) Purchasing (Manager: Raphaely) Purchasing (Manager: Khoo) Purchasing (Manager: Tobias) Executive (Manager: Kochhar) Executive (Manager: De Haan) Executive (Manager: King) Finance (Manager: Popp) Finance (Manager: Greenberg) Finance (Manager: Faviet) Finance (Manager: Chen) Finance (Manager: Urman) Finance (Manager: Sciarra) Accounting (Manager: Gietz) Accounting (Manager: Higgins) -------------------------------- DEPARTMENTS IN CANADA: -------------------------------- Marketing (Manager: Hartstein) Marketing (Manager: Fay) PL/SQL procedure successfully completed.
6.2.2.6.2 Adding Formal Cursor Parameters with Default Values
If you add formal parameters to a cursor, and you specify default values for the added parameters, then you need not change existing references to the cursor. Compare Example 6-13 to Example 6-11.
Example 6-13 Adding Formal Parameter to Existing Cursor
DECLARE CURSOR c (job VARCHAR2, max_sal NUMBER, hired DATE DEFAULT TO_DATE('31-DEC-1999', 'DD-MON-YYYY')) IS SELECT last_name, first_name, (salary - max_sal) overpayment FROM employees WHERE job_id = job AND salary > max_sal AND hire_date > hired ORDER BY salary; PROCEDURE print_overpaid IS last_name_ employees.last_name%TYPE; first_name_ employees.first_name%TYPE; overpayment_ employees.salary%TYPE; BEGIN LOOP FETCH c INTO last_name_, first_name_, overpayment_; EXIT WHEN c%NOTFOUND; DBMS_OUTPUT.PUT_LINE(last_name_ || ', ' || first_name_ || ' (by ' || overpayment_ || ')'); END LOOP; END print_overpaid; BEGIN DBMS_OUTPUT.PUT_LINE('-------------------------------'); DBMS_OUTPUT.PUT_LINE('Overpaid Sales Representatives:'); DBMS_OUTPUT.PUT_LINE('-------------------------------'); OPEN c('SA_REP', 10000); -- existing reference print_overpaid; CLOSE c; DBMS_OUTPUT.PUT_LINE('------------------------------------------------'); DBMS_OUTPUT.PUT_LINE('Overpaid Sales Representatives Hired After 2004:'); DBMS_OUTPUT.PUT_LINE('------------------------------------------------'); OPEN c('SA_REP', 10000, TO_DATE('31-DEC-2004', 'DD-MON-YYYY')); -- new reference print_overpaid; CLOSE c; END; /
Result:
------------------------------- Overpaid Sales Representatives: ------------------------------- Vishney, Clara (by 500) Abel, Ellen (by 1000) Ozer, Lisa (by 1500) ------------------------------------------------ Overpaid Sales Representatives Hired After 2004: ------------------------------------------------ Vishney, Clara (by 500) Ozer, Lisa (by 1500) PL/SQL procedure successfully completed.
6.2.2.7 Explicit Cursor Attributes
The syntax for the value of an explicit cursor attribute is cursor_name
immediately followed by attribute
(for example, c1%ISOPEN
).
Note:
Explicit cursors and cursor variables (named cursors) have the same attributes. This topic applies to all named cursors except where noted.
The explicit cursor attributes are:
-
%ISOPEN Attribute: Is the Cursor Open?
-
%FOUND Attribute: Has a Row Been Fetched?
-
%NOTFOUND Attribute: Has No Row Been Fetched?
-
%ROWCOUNT Attribute: How Many Rows Were Fetched?
If an explicit cursor is not open, referencing any attribute except %ISOPEN
raises the predefined exception INVALID_CURSOR
.
See Also:
"Named Cursor Attribute" for complete syntax and semantics of named cursor (explicit cursor and cursor variable) attributes
6.2.2.7.1 %ISOPEN Attribute: Is the Cursor Open?
%ISOPEN
returns TRUE
if its explicit cursor is open; FALSE
otherwise.
%ISOPEN
is useful for:
-
Checking that an explicit cursor is not already open before you try to open it.
If you try to open an explicit cursor that is already open, PL/SQL raises the predefined exception
CURSOR_ALREADY_OPEN
. You must close an explicit cursor before you can reopen it.Note:
The preceding paragraph does not apply to cursor variables.
-
Checking that an explicit cursor is open before you try to close it.
Example 6-14 opens the explicit cursor c1
only if it is not open and closes it only if it is open.
Example 6-14 %ISOPEN Explicit Cursor Attribute
DECLARE CURSOR c1 IS SELECT last_name, salary FROM employees WHERE ROWNUM < 11; the_name employees.last_name%TYPE; the_salary employees.salary%TYPE; BEGIN IF NOT c1%ISOPEN THEN OPEN c1; END IF; FETCH c1 INTO the_name, the_salary; IF c1%ISOPEN THEN CLOSE c1; END IF; END; /
6.2.2.7.2 %FOUND Attribute: Has a Row Been Fetched?
%FOUND
returns:
-
NULL
after the explicit cursor is opened but before the first fetch -
TRUE
if the most recent fetch from the explicit cursor returned a row -
FALSE
otherwise
%FOUND
is useful for determining whether there is a fetched row to process.
Example 6-15 loops through a result set, printing each fetched row and exiting when there are no more rows to fetch.
Example 6-15 %FOUND Explicit Cursor Attribute
DECLARE
CURSOR c1 IS
SELECT last_name, salary FROM employees
WHERE ROWNUM < 11
ORDER BY last_name;
my_ename employees.last_name%TYPE;
my_salary employees.salary%TYPE;
BEGIN
OPEN c1;
LOOP
FETCH c1 INTO my_ename, my_salary;
IF c1%FOUND THEN -- fetch succeeded
DBMS_OUTPUT.PUT_LINE('Name = ' || my_ename || ', salary = ' || my_salary);
ELSE -- fetch failed
EXIT;
END IF;
END LOOP;
END;
/
Result:
Name = Austin, salary = 4800 Name = De Haan, salary = 17000 Name = Ernst, salary = 6000 Name = Faviet, salary = 9000 Name = Greenberg, salary = 12008 Name = Hunold, salary = 9000 Name = King, salary = 24000 Name = Kochhar, salary = 17000 Name = Lorentz, salary = 4200 Name = Pataballa, salary = 4800
6.2.2.7.3 %NOTFOUND Attribute: Has No Row Been Fetched?
%NOTFOUND
(the logical opposite of %FOUND
) returns:
-
NULL
after the explicit cursor is opened but before the first fetch -
FALSE
if the most recent fetch from the explicit cursor returned a row -
TRUE
otherwise
%NOTFOUND
is useful for exiting a loop when FETCH
fails to return a row, as in Example 6-16.
Example 6-16 %NOTFOUND Explicit Cursor Attribute
DECLARE
CURSOR c1 IS
SELECT last_name, salary FROM employees
WHERE ROWNUM < 11
ORDER BY last_name;
my_ename employees.last_name%TYPE;
my_salary employees.salary%TYPE;
BEGIN
OPEN c1;
LOOP
FETCH c1 INTO my_ename, my_salary;
IF c1%NOTFOUND THEN -- fetch failed
EXIT;
ELSE -- fetch succeeded
DBMS_OUTPUT.PUT_LINE
('Name = ' || my_ename || ', salary = ' || my_salary);
END IF;
END LOOP;
END;
/
Result:
Name = Austin, salary = 4800 Name = De Haan, salary = 17000 Name = Ernst, salary = 6000 Name = Faviet, salary = 9000 Name = Greenberg, salary = 12008 Name = Hunold, salary = 9000 Name = King, salary = 24000 Name = Kochhar, salary = 17000 Name = Lorentz, salary = 4200 Name = Pataballa, salary = 4800
6.2.2.7.4 %ROWCOUNT Attribute: How Many Rows Were Fetched?
%ROWCOUNT
returns:
-
Zero after the explicit cursor is opened but before the first fetch
-
Otherwise, the number of rows fetched (an
INTEGER
)Note:
If a server is Oracle Database 12c or later and its client is Oracle Database 11g2 or earlier (or the reverse), then the maximum number that
SQL%ROWCOUNT
returns is 4,294,967,295.
Example 6-17 numbers and prints the rows that it fetches and prints a message after fetching the fifth row.
Example 6-17 %ROWCOUNT Explicit Cursor Attribute
DECLARE CURSOR c1 IS SELECT last_name FROM employees WHERE ROWNUM < 11 ORDER BY last_name; name employees.last_name%TYPE; BEGIN OPEN c1; LOOP FETCH c1 INTO name; EXIT WHEN c1%NOTFOUND OR c1%NOTFOUND IS NULL; DBMS_OUTPUT.PUT_LINE(c1%ROWCOUNT || '. ' || name); IF c1%ROWCOUNT = 5 THEN DBMS_OUTPUT.PUT_LINE('--- Fetched 5th row ---'); END IF; END LOOP; CLOSE c1; END; /
Result:
1. Abel 2. Ande 3. Atkinson 4. Austin 5. Baer --- Fetched 5th row --- 6. Baida 7. Banda 8. Bates 9. Bell 10. Bernstein
6.3 Processing Query Result Sets
In PL/SQL, as in traditional database programming, you use cursors to process query result sets. However, in PL/SQL, you can use either implicit or explicit cursors.
The former need less code, but the latter are more flexible. For example, explicit cursors can accept parameters.
The following PL/SQL statements use implicit cursors that PL/SQL defines and manages for you:
-
SELECT
INTO
-
Implicit cursor
FOR
LOOP
The following PL/SQL statements use explicit cursors:
-
Explicit cursor
FOR
LOOP
You define the explicit cursor, but PL/SQL manages it while the statement runs.
-
OPEN
,FETCH
, andCLOSE
You define and manage the explicit cursor.
Note:
If a query returns no rows, PL/SQL raises the exception NO_DATA_FOUND
.
Topics
-
Processing Query Result Sets With Cursor FOR LOOP Statements
-
Processing Query Result Sets With Explicit Cursors, OPEN, FETCH, and CLOSE
See Also:
-
Oracle Database Development Guide for information about returning result sets to clients
-
"Exception Handler" for information about handling exceptions
6.3.1 Processing Query Result Sets With SELECT INTO Statements
Using an implicit cursor, the SELECT
INTO
statement retrieves values from one or more database tables (as the SQL SELECT
statement does) and stores them in variables (which the SQL SELECT
statement does not do).
Topics
See Also:
"SELECT INTO Statement" for its complete syntax and semantics
6.3.1.1 Handling Single-Row Result Sets
If you expect the query to return only one row, then use the SELECT
INTO
statement to store values from that row in either one or more scalar variables, or one record variable.
If the query might return multiple rows, but you care about only the nth row, then restrict the result set to that row with the clause WHERE
ROWNUM=
n
.
See Also:
-
"Assigning Values to Variables with the SELECT INTO Statement"
-
Oracle Database SQL Language Reference for more information about the
ROWNUM
pseudocolumn
6.3.1.2 Handling Large Multiple-Row Result Sets
If you must assign a large quantity of table data to variables, Oracle recommends using the SELECT
INTO
statement with the BULK
COLLECT
clause.
This statement retrieves an entire result set into one or more collection variables.
For more information, see "SELECT INTO Statement with BULK COLLECT Clause".
6.3.2 Processing Query Result Sets With Cursor FOR LOOP Statements
The cursor FOR
LOOP
statement lets you run a SELECT
statement and then immediately loop through the rows of the result set.
This statement can use either an implicit or explicit cursor (but not a cursor variable).
If you use the SELECT
statement only in the cursor FOR
LOOP
statement, then specify the SELECT
statement inside the cursor FOR
LOOP
statement, as in Example 6-18. This form of the cursor FOR
LOOP
statement uses an implicit cursor, and is called an implicit cursor FOR
LOOP
statement. Because the implicit cursor is internal to the statement, you cannot reference it with the name SQL
.
If you use the SELECT
statement multiple times in the same PL/SQL unit, then define an explicit cursor for it and specify that cursor in the cursor FOR
LOOP
statement, as in Example 6-19. This form of the cursor FOR
LOOP
statement is called an explicit cursor FOR
LOOP
statement. You can use the same explicit cursor elsewhere in the same PL/SQL unit.
The cursor FOR
LOOP
statement implicitly declares its loop index as a %ROWTYPE
record variable of the type that its cursor returns. This record is local to the loop and exists only during loop execution. Statements inside the loop can reference the record and its fields. They can reference virtual columns only by aliases, as in Example 6-21.
After declaring the loop index record variable, the FOR
LOOP
statement opens the specified cursor. With each iteration of the loop, the FOR
LOOP
statement fetches a row from the result set and stores it in the record. When there are no more rows to fetch, the cursor FOR
LOOP
statement closes the cursor. The cursor also closes if a statement inside the loop transfers control outside the loop or if PL/SQL raises an exception.
See Also:
"Cursor FOR LOOP Statement" for its complete syntax and semantics
Note:
When an exception is raised inside a cursor FOR
LOOP
statement, the cursor closes before the exception handler runs. Therefore, the values of explicit cursor attributes are not available in the handler.
Example 6-18 Implicit Cursor FOR LOOP Statement
In this example, an implicit cursor FOR
LOOP
statement prints the last name and job ID of every clerk whose manager has an ID greater than 120.
BEGIN FOR item IN ( SELECT last_name, job_id FROM employees WHERE job_id LIKE '%CLERK%' AND manager_id > 120 ORDER BY last_name ) LOOP DBMS_OUTPUT.PUT_LINE ('Name = ' || item.last_name || ', Job = ' || item.job_id); END LOOP; END; /
Result:
Name = Atkinson, Job = ST_CLERK Name = Bell, Job = SH_CLERK Name = Bissot, Job = ST_CLERK ... Name = Walsh, Job = SH_CLERK
Example 6-19 Explicit Cursor FOR LOOP Statement
This exmaple is like Example 6-18, except that it uses an explicit cursor FOR
LOOP
statement.
DECLARE CURSOR c1 IS SELECT last_name, job_id FROM employees WHERE job_id LIKE '%CLERK%' AND manager_id > 120 ORDER BY last_name; BEGIN FOR item IN c1 LOOP DBMS_OUTPUT.PUT_LINE ('Name = ' || item.last_name || ', Job = ' || item.job_id); END LOOP; END; /
Result:
Name = Atkinson, Job = ST_CLERK Name = Bell, Job = SH_CLERK Name = Bissot, Job = ST_CLERK ... Name = Walsh, Job = SH_CLERK
Example 6-20 Passing Parameters to Explicit Cursor FOR LOOP Statement
This example declares and defines an explicit cursor that accepts two parameters, and then uses it in an explicit cursor FOR
LOOP
statement to display the wages paid to employees who earn more than a specified wage in a specified department.
DECLARE CURSOR c1 (job VARCHAR2, max_wage NUMBER) IS SELECT * FROM employees WHERE job_id = job AND salary > max_wage; BEGIN FOR person IN c1('ST_CLERK', 3000) LOOP -- process data record DBMS_OUTPUT.PUT_LINE ( 'Name = ' || person.last_name || ', salary = ' || person.salary || ', Job Id = ' || person.job_id ); END LOOP; END; /
Result:
Name = Nayer, salary = 3200, Job Id = ST_CLERK Name = Bissot, salary = 3300, Job Id = ST_CLERK Name = Mallin, salary = 3300, Job Id = ST_CLERK Name = Ladwig, salary = 3600, Job Id = ST_CLERK Name = Stiles, salary = 3200, Job Id = ST_CLERK Name = Rajs, salary = 3500, Job Id = ST_CLERK Name = Davies, salary = 3100, Job Id = ST_CLERK
Example 6-21 Cursor FOR Loop References Virtual Columns
In this example, the implicit cursor FOR
LOOP
references virtual columns by their aliases, full_name
and dream_salary
.
BEGIN FOR item IN ( SELECT first_name || ' ' || last_name AS full_name, salary * 10 AS dream_salary FROM employees WHERE ROWNUM <= 5 ORDER BY dream_salary DESC, last_name ASC ) LOOP DBMS_OUTPUT.PUT_LINE (item.full_name || ' dreams of making ' || item.dream_salary); END LOOP; END; /
Result:
Stephen King dreams of making 240000 Lex De Haan dreams of making 170000 Neena Kochhar dreams of making 170000 Alexander Hunold dreams of making 90000 Bruce Ernst dreams of making 60000
6.3.3 Processing Query Result Sets With Explicit Cursors, OPEN, FETCH, and CLOSE
For full control over query result set processing, declare explicit cursors and manage them with the statements OPEN, FETCH, and CLOSE.
This result set processing technique is more complicated than the others, but it is also more flexible. For example, you can:
-
Process multiple result sets in parallel, using multiple cursors.
-
Process multiple rows in a single loop iteration, skip rows, or split the processing into multiple loops.
-
Specify the query in one PL/SQL unit but retrieve the rows in another.
For instructions and examples, see "Explicit Cursors".
6.3.4 Processing Query Result Sets with Subqueries
If you process a query result set by looping through it and running another query for each row, then you can improve performance by removing the second query from inside the loop and making it a subquery of the first query.
While an ordinary subquery is evaluated for each table, a correlated subquery is evaluated for each row.
For more information about subqueries, see Oracle Database SQL Language Reference.
Example 6-22 Subquery in FROM Clause of Parent Query
This example defines explicit cursor c1
with a query whose FROM
clause contains a subquery.
DECLARE CURSOR c1 IS SELECT t1.department_id, department_name, staff FROM departments t1, ( SELECT department_id, COUNT(*) AS staff FROM employees GROUP BY department_id ) t2 WHERE (t1.department_id = t2.department_id) AND staff >= 5 ORDER BY staff; BEGIN FOR dept IN c1 LOOP DBMS_OUTPUT.PUT_LINE ('Department = ' || dept.department_name || ', staff = ' || dept.staff); END LOOP; END; /
Result:
Department = IT, staff = 5 Department = Finance, staff = 6 Department = Purchasing, staff = 6 Department = Sales, staff = 34 Department = Shipping, staff = 45
Example 6-23 Correlated Subquery
This example returns the name and salary of each employee whose salary exceeds the departmental average. For each row in the table, the correlated subquery computes the average salary for the corresponding department.
DECLARE CURSOR c1 IS SELECT department_id, last_name, salary FROM employees t WHERE salary > ( SELECT AVG(salary) FROM employees WHERE t.department_id = department_id ) ORDER BY department_id, last_name; BEGIN FOR person IN c1 LOOP DBMS_OUTPUT.PUT_LINE('Making above-average salary = ' || person.last_name); END LOOP; END; /
Result:
Making above-average salary = Hartstein Making above-average salary = Raphaely Making above-average salary = Bell ... Making above-average salary = Higgins
6.4 Cursor Variables
A cursor variable is like an explicit cursor, except that:
-
It is not limited to one query.
You can open a cursor variable for a query, process the result set, and then use the cursor variable for another query.
-
You can assign a value to it.
-
You can use it in an expression.
-
It can be a subprogram parameter.
You can use cursor variables to pass query result sets between subprograms.
-
It can be a host variable.
You can use cursor variables to pass query result sets between PL/SQL stored subprograms and their clients.
-
It cannot accept parameters.
You cannot pass parameters to a cursor variable, but you can pass whole queries to it. The queries can include variables.
A cursor variable has this flexibility because it is a pointer; that is, its value is the address of an item, not the item itself.
Before you can reference a cursor variable, you must make it point to a SQL work area, either by opening it or by assigning it the value of an open PL/SQL cursor variable or open host cursor variable.
Note:
Cursor variables and explicit cursors are not interchangeable—you cannot use one where the other is expected. For example, you cannot reference a cursor variable in a cursor FOR
LOOP
statement.
Topics
See Also:
-
"Explicit Cursors" for more information about explicit cursors
-
Oracle Database Development Guide for advantages of cursor variables
-
Oracle Database Development Guide for disadvantages of cursor variables
6.4.1 Creating Cursor Variables
To create a cursor variable, either declare a variable of the predefined type SYS_REFCURSOR
or define a REF
CURSOR
type and then declare a variable of that type.
Note:
Informally, a cursor variable is sometimes called a REF
CURSOR
).
The basic syntax of a REF
CURSOR
type definition is:
TYPE type_name IS REF CURSOR [ RETURN return_type ]
For the complete syntax and semantics, see "Cursor Variable Declaration".
If you specify return_type
, then the REF
CURSOR
type and cursor variables of that type are strong; if not, they are weak. SYS_REFCURSOR
and cursor variables of that type are weak.
With a strong cursor variable, you can associate only queries that return the specified type. With a weak cursor variable, you can associate any query.
Weak cursor variables are more error-prone than strong ones, but they are also more flexible. Weak REF
CURSOR
types are interchangeable with each other and with the predefined type SYS_REFCURSOR
. You can assign the value of a weak cursor variable to any other weak cursor variable.
You can assign the value of a strong cursor variable to another strong cursor variable only if both cursor variables have the same type (not merely the same return type).
Note:
You can partition weak cursor variable arguments to table functions only with the PARTITION
BY
ANY
clause, not with PARTITION
BY
RANGE
or PARTITION
BY
HASH
.
For syntax and semantics, see "PARALLEL_ENABLE Clause".
Example 6-24 Cursor Variable Declarations
This example defines strong and weak REF
CURSOR
types, variables of those types, and a variable of the predefined type SYS_REFCURSOR
.
DECLARE TYPE empcurtyp IS REF CURSOR RETURN employees%ROWTYPE; -- strong type TYPE genericcurtyp IS REF CURSOR; -- weak type cursor1 empcurtyp; -- strong cursor variable cursor2 genericcurtyp; -- weak cursor variable my_cursor SYS_REFCURSOR; -- weak cursor variable TYPE deptcurtyp IS REF CURSOR RETURN departments%ROWTYPE; -- strong type dept_cv deptcurtyp; -- strong cursor variable BEGIN NULL; END; /
Example 6-25 Cursor Variable with User-Defined Return Type
In this example, EmpRecTyp
is a user-defined RECORD
type.
DECLARE TYPE EmpRecTyp IS RECORD ( employee_id NUMBER, last_name VARCHAR2(25), salary NUMBER(8,2)); TYPE EmpCurTyp IS REF CURSOR RETURN EmpRecTyp; emp_cv EmpCurTyp; BEGIN NULL; END; /
6.4.2 Opening and Closing Cursor Variables
After declaring a cursor variable, you can open it with the OPEN
FOR
statement, which does the following:
-
Associates the cursor variable with a query (typically, the query returns multiple rows)
The query can include placeholders for bind variables, whose values you specify in the
USING
clause of theOPEN
FOR
statement. -
Allocates database resources to process the query
-
Processes the query; that is:
-
Identifies the result set
If the query references variables, their values affect the result set. For details, see "Variables in Cursor Variable Queries".
-
If the query has a
FOR
UPDATE
clause, locks the rows of the result setFor details, see "SELECT FOR UPDATE and FOR UPDATE Cursors".
-
-
Positions the cursor before the first row of the result set
You need not close a cursor variable before reopening it (that is, using it in another OPEN
FOR
statement). After you reopen a cursor variable, the query previously associated with it is lost.
When you no longer need a cursor variable, close it with the CLOSE
statement, thereby allowing its resources to be reused. After closing a cursor variable, you cannot fetch records from its result set or reference its attributes. If you try, PL/SQL raises the predefined exception INVALID_CURSOR
.
You can reopen a closed cursor variable.
See Also:
-
"OPEN FOR Statement" for its syntax and semantics
-
"CLOSE Statement" for its syntax and semantics
6.4.3 Fetching Data with Cursor Variables
After opening a cursor variable, you can fetch the rows of the query result set with the FETCH
statement.
The return type of the cursor variable must be compatible with the into_clause
of the FETCH
statement. If the cursor variable is strong, PL/SQL catches incompatibility at compile time. If the cursor variable is weak, PL/SQL catches incompatibility at run time, raising the predefined exception ROWTYPE_MISMATCH
before the first fetch.
See Also:
-
"FETCH Statement" for its complete syntax and semantics
-
"FETCH Statement with BULK COLLECT Clause" for information about
FETCH
statements that return more than one row at a time
Example 6-26 Fetching Data with Cursor Variables
This example uses one cursor variable to do what Example 6-6 does with two explicit cursors. The first OPEN
FOR
statement includes the query itself. The second OPEN
FOR
statement references a variable whose value is a query.
DECLARE cv SYS_REFCURSOR; -- cursor variable v_lastname employees.last_name%TYPE; -- variable for last_name v_jobid employees.job_id%TYPE; -- variable for job_id query_2 VARCHAR2(200) := 'SELECT * FROM employees WHERE REGEXP_LIKE (job_id, ''[ACADFIMKSA]_M[ANGR]'') ORDER BY job_id'; v_employees employees%ROWTYPE; -- record variable row of table BEGIN OPEN cv FOR SELECT last_name, job_id FROM employees WHERE REGEXP_LIKE (job_id, 'S[HT]_CLERK') ORDER BY last_name; LOOP -- Fetches 2 columns into variables FETCH cv INTO v_lastname, v_jobid; EXIT WHEN cv%NOTFOUND; DBMS_OUTPUT.PUT_LINE( RPAD(v_lastname, 25, ' ') || v_jobid ); END LOOP; DBMS_OUTPUT.PUT_LINE( '-------------------------------------' ); OPEN cv FOR query_2; LOOP -- Fetches entire row into the v_employees record FETCH cv INTO v_employees; EXIT WHEN cv%NOTFOUND; DBMS_OUTPUT.PUT_LINE( RPAD(v_employees.last_name, 25, ' ') || v_employees.job_id ); END LOOP; CLOSE cv; END; /
Result:
Atkinson ST_CLERK Bell SH_CLERK Bissot ST_CLERK ... Walsh SH_CLERK ------------------------------------- Higgins AC_MGR Greenberg FI_MGR Hartstein MK_MAN ... Zlotkey SA_MAN
Example 6-27 Fetching from Cursor Variable into Collections
This example fetches from a cursor variable into two collections (nested tables), using the BULK
COLLECT
clause of the FETCH
statement.
DECLARE
TYPE empcurtyp IS REF CURSOR;
TYPE namelist IS TABLE OF employees.last_name%TYPE;
TYPE sallist IS TABLE OF employees.salary%TYPE;
emp_cv empcurtyp;
names namelist;
sals sallist;
BEGIN
OPEN emp_cv FOR
SELECT last_name, salary FROM employees
WHERE job_id = 'SA_REP'
ORDER BY salary DESC;
FETCH emp_cv BULK COLLECT INTO names, sals;
CLOSE emp_cv;
-- loop through the names and sals collections
FOR i IN names.FIRST .. names.LAST
LOOP
DBMS_OUTPUT.PUT_LINE
('Name = ' || names(i) || ', salary = ' || sals(i));
END LOOP;
END;
/
Result:
Name = Ozer, salary = 11500 Name = Abel, salary = 11000 Name = Vishney, salary = 10500 ... Name = Kumar, salary = 6100
6.4.4 Assigning Values to Cursor Variables
You can assign to a PL/SQL cursor variable the value of another PL/SQL cursor variable or host cursor variable.
The syntax is:
target_cursor_variable := source_cursor_variable;
If source_cursor_variable
is open, then after the assignment, target_cursor_variable
is also open. The two cursor variables point to the same SQL work area.
If source_cursor_variable
is not open, opening target_cursor_variable
after the assignment does not open source_cursor_variable
.
6.4.5 Variables in Cursor Variable Queries
The query associated with a cursor variable can reference any variable in its scope.
When you open a cursor variable with the OPEN
FOR
statement, PL/SQL evaluates any variables in the query and uses those values when identifying the result set. Changing the values of the variables later does not change the result set.
To change the result set, you must change the value of the variable and then open the cursor variable again for the same query, as in Example 6-29.
Example 6-28 Variable in Cursor Variable Query—No Result Set Change
This example opens a cursor variable for a query that references the variable factor
, which has the value 2. Therefore, sal_multiple
is always 2 times sal
, despite that factor
is incremented after every fetch.
DECLARE sal employees.salary%TYPE; sal_multiple employees.salary%TYPE; factor INTEGER := 2; cv SYS_REFCURSOR; BEGIN OPEN cv FOR SELECT salary, salary*factor FROM employees WHERE job_id LIKE 'AD_%'; -- PL/SQL evaluates factor LOOP FETCH cv INTO sal, sal_multiple; EXIT WHEN cv%NOTFOUND; DBMS_OUTPUT.PUT_LINE('factor = ' || factor); DBMS_OUTPUT.PUT_LINE('sal = ' || sal); DBMS_OUTPUT.PUT_LINE('sal_multiple = ' || sal_multiple); factor := factor + 1; -- Does not affect sal_multiple END LOOP; CLOSE cv; END; /
Result:
factor = 2 sal = 4400 sal_multiple = 8800 factor = 3 sal = 24000 sal_multiple = 48000 factor = 4 sal = 17000 sal_multiple = 34000 factor = 5 sal = 17000 sal_multiple = 34000
Example 6-29 Variable in Cursor Variable Query—Result Set Change
DECLARE sal employees.salary%TYPE; sal_multiple employees.salary%TYPE; factor INTEGER := 2; cv SYS_REFCURSOR; BEGIN DBMS_OUTPUT.PUT_LINE('factor = ' || factor); OPEN cv FOR SELECT salary, salary*factor FROM employees WHERE job_id LIKE 'AD_%'; -- PL/SQL evaluates factor LOOP FETCH cv INTO sal, sal_multiple; EXIT WHEN cv%NOTFOUND; DBMS_OUTPUT.PUT_LINE('sal = ' || sal); DBMS_OUTPUT.PUT_LINE('sal_multiple = ' || sal_multiple); END LOOP; factor := factor + 1; DBMS_OUTPUT.PUT_LINE('factor = ' || factor); OPEN cv FOR SELECT salary, salary*factor FROM employees WHERE job_id LIKE 'AD_%'; -- PL/SQL evaluates factor LOOP FETCH cv INTO sal, sal_multiple; EXIT WHEN cv%NOTFOUND; DBMS_OUTPUT.PUT_LINE('sal = ' || sal); DBMS_OUTPUT.PUT_LINE('sal_multiple = ' || sal_multiple); END LOOP; CLOSE cv; END; /
Result:
factor = 2 sal = 4400 sal_multiple = 8800 sal = 24000 sal_multiple = 48000 sal = 17000 sal_multiple = 34000 sal = 17000 sal_multiple = 34000 factor = 3 sal = 4400 sal_multiple = 13200 sal = 24000 sal_multiple = 72000 sal = 17000 sal_multiple = 51000 sal = 17000 sal_multiple = 51000
6.4.6 Querying a Collection
You can query a collection if all of the following are true:
-
The data type of the collection was either created at schema level or declared in a package specification.
-
The data type of the collection element is either a scalar data type, a user-defined type, or a record type.
In the query FROM
clause, the collection appears in table_collection_expression
as the argument of the TABLE
operator.
Note:
In SQL contexts, you cannot use a function whose return type was declared in a package specification.
See Also:
-
Oracle Database SQL Language Reference for information about the
table_collection_expression
-
"CREATE PACKAGE Statement" for information about the
CREATE
PACKAGE
statement -
"PL/SQL Collections and Records" for information about collection types and collection variables
-
Example 7-9, "Querying a Collection with Native Dynamic SQL"
Example 6-30 Querying a Collection with Static SQL
In this example, the cursor variable is associated with a query on an associative array of records. The nested table type, mytab
, is declared in a package specification.
CREATE OR REPLACE PACKAGE pkg AUTHID DEFINER AS TYPE rec IS RECORD(f1 NUMBER, f2 VARCHAR2(30)); TYPE mytab IS TABLE OF rec INDEX BY pls_integer; END; DECLARE v1 pkg.mytab; -- collection of records v2 pkg.rec; c1 SYS_REFCURSOR; BEGIN v1(1).f1 := 1; v1(1).f2 := 'one'; OPEN c1 FOR SELECT * FROM TABLE(v1); FETCH c1 INTO v2; CLOSE c1; DBMS_OUTPUT.PUT_LINE('Values in record are ' || v2.f1 || ' and ' || v2.f2); END; /
Result:
Values in record are 1 and one
6.4.7 Cursor Variable Attributes
A cursor variable has the same attributes as an explicit cursor (see Explicit Cursor Attributes.). The syntax for the value of a cursor variable attribute is cursor_variable_name
immediately followed by attribute
(for example, cv%ISOPEN
). If a cursor variable is not open, referencing any attribute except %ISOPEN
raises the predefined exception INVALID_CURSOR
.
6.4.8 Cursor Variables as Subprogram Parameters
You can use a cursor variable as a subprogram parameter, which makes it useful for passing query results between subprograms.
For example:
-
You can open a cursor variable in one subprogram and process it in a different subprogram.
-
In a multilanguage application, a PL/SQL subprogram can use a cursor variable to return a result set to a subprogram written in a different language.
Note:
The invoking and invoked subprograms must be in the same database instance. You cannot pass or return cursor variables to subprograms invoked through database links.
Caution:
Because cursor variables are pointers, using them as subprogram parameters increases the likelihood of subprogram parameter aliasing, which can have unintended results. For more information, see "Subprogram Parameter Aliasing with Cursor Variable Parameters".
When declaring a cursor variable as the formal parameter of a subprogram:
-
If the subprogram opens or assigns a value to the cursor variable, then the parameter mode must be
IN
OUT
. -
If the subprogram only fetches from, or closes, the cursor variable, then the parameter mode can be either
IN
orIN
OUT
.
Corresponding formal and actual cursor variable parameters must have compatible return types. Otherwise, PL/SQL raises the predefined exception ROWTYPE_MISMATCH
.
To pass a cursor variable parameter between subprograms in different PL/SQL units, define the REF
CURSOR
type of the parameter in a package. When the type is in a package, multiple subprograms can use it. One subprogram can declare a formal parameter of that type, and other subprograms can declare variables of that type and pass them to the first subprogram.
See Also:
-
"Subprogram Parameters" for more information about subprogram parameters
-
"CURSOR Expressions" for information about
CURSOR
expressions, which can be actual parameters for formal cursor variable parameters -
PL/SQL Packages, for more information about packages
Example 6-31 Procedure to Open Cursor Variable for One Query
This example defines, in a package, a REF
CURSOR
type and a procedure that opens a cursor variable parameter of that type.
CREATE OR REPLACE PACKAGE emp_data AUTHID DEFINER AS TYPE empcurtyp IS REF CURSOR RETURN employees%ROWTYPE; PROCEDURE open_emp_cv (emp_cv IN OUT empcurtyp); END emp_data; / CREATE OR REPLACE PACKAGE BODY emp_data AS PROCEDURE open_emp_cv (emp_cv IN OUT EmpCurTyp) IS BEGIN OPEN emp_cv FOR SELECT * FROM employees; END open_emp_cv; END emp_data; /
Example 6-32 Opening Cursor Variable for Chosen Query (Same Return Type)
In this example ,the stored procedure opens its cursor variable parameter for a chosen query. The queries have the same return type.
CREATE OR REPLACE PACKAGE emp_data AUTHID DEFINER AS TYPE empcurtyp IS REF CURSOR RETURN employees%ROWTYPE; PROCEDURE open_emp_cv (emp_cv IN OUT empcurtyp, choice INT); END emp_data; / CREATE OR REPLACE PACKAGE BODY emp_data AS PROCEDURE open_emp_cv (emp_cv IN OUT empcurtyp, choice INT) IS BEGIN IF choice = 1 THEN OPEN emp_cv FOR SELECT * FROM employees WHERE commission_pct IS NOT NULL; ELSIF choice = 2 THEN OPEN emp_cv FOR SELECT * FROM employees WHERE salary > 2500; ELSIF choice = 3 THEN OPEN emp_cv FOR SELECT * FROM employees WHERE department_id = 100; END IF; END; END emp_data; /
Example 6-33 Opening Cursor Variable for Chosen Query (Different Return Types)
In this example,the stored procedure opens its cursor variable parameter for a chosen query. The queries have the different return types.
CREATE OR REPLACE PACKAGE admin_data AUTHID DEFINER AS TYPE gencurtyp IS REF CURSOR; PROCEDURE open_cv (generic_cv IN OUT gencurtyp, choice INT); END admin_data; / CREATE OR REPLACE PACKAGE BODY admin_data AS PROCEDURE open_cv (generic_cv IN OUT gencurtyp, choice INT) IS BEGIN IF choice = 1 THEN OPEN generic_cv FOR SELECT * FROM employees; ELSIF choice = 2 THEN OPEN generic_cv FOR SELECT * FROM departments; ELSIF choice = 3 THEN OPEN generic_cv FOR SELECT * FROM jobs; END IF; END; END admin_data; /
6.4.9 Cursor Variables as Host Variables
You can use a cursor variable as a host variable, which makes it useful for passing query results between PL/SQL stored subprograms and their clients.
When a cursor variable is a host variable, PL/SQL and the client (the host environment) share a pointer to the SQL work area that stores the result set.
To use a cursor variable as a host variable, declare the cursor variable in the host environment and then pass it as an input host variable (bind variable) to PL/SQL. Host cursor variables are compatible with any query return type (like weak PL/SQL cursor variables).
A SQL work area remains accessible while any cursor variable points to it, even if you pass the value of a cursor variable from one scope to another. For example, in Example 6-34, the Pro*C program passes a host cursor variable to an embedded PL/SQL anonymous block. After the block runs, the cursor variable still points to the SQL work area.
If you have a PL/SQL engine on the client side, calls from client to server impose no restrictions. For example, you can declare a cursor variable on the client side, open and fetch from it on the server side, and continue to fetch from it on the client side. You can also reduce network traffic with a PL/SQL anonymous block that opens or closes several host cursor variables in a single round trip. For example:
/* PL/SQL anonymous block in host environment */ BEGIN OPEN :emp_cv FOR SELECT * FROM employees; OPEN :dept_cv FOR SELECT * FROM departments; OPEN :loc_cv FOR SELECT * FROM locations; END; /
Because the cursor variables still point to the SQL work areas after the PL/SQL anonymous block runs, the client program can use them. When the client program no longer needs the cursors, it can use a PL/SQL anonymous block to close them. For example:
/* PL/SQL anonymous block in host environment */ BEGIN CLOSE :emp_cv; CLOSE :dept_cv; CLOSE :loc_cv; END; /
This technique is useful for populating a multiblock form, as in Oracle Forms. For example, you can open several SQL work areas in a single round trip, like this:
/* PL/SQL anonymous block in host environment */ BEGIN OPEN :c1 FOR SELECT 1 FROM DUAL; OPEN :c2 FOR SELECT 1 FROM DUAL; OPEN :c3 FOR SELECT 1 FROM DUAL; END; /
Note:
If you bind a host cursor variable into PL/SQL from an Oracle Call Interface (OCI) client, then you cannot fetch from it on the server side unless you also open it there on the same server call.
Example 6-34 Cursor Variable as Host Variable in Pro*C Client Program
In this example, a Pro*C client program declares a cursor variable and a selector and passes them as host variables to a PL/SQL anonymous block, which opens the cursor variable for the selected query.
EXEC SQL BEGIN DECLARE SECTION; SQL_CURSOR generic_cv; -- Declare host cursor variable. int choice; -- Declare selector. EXEC SQL END DECLARE SECTION; EXEC SQL ALLOCATE :generic_cv; -- Initialize host cursor variable. -- Pass host cursor variable and selector to PL/SQL block. / EXEC SQL EXECUTE BEGIN IF :choice = 1 THEN OPEN :generic_cv FOR SELECT * FROM employees; ELSIF :choice = 2 THEN OPEN :generic_cv FOR SELECT * FROM departments; ELSIF :choice = 3 THEN OPEN :generic_cv FOR SELECT * FROM jobs; END IF; END; END-EXEC;
6.5 CURSOR Expressions
A CURSOR
expression returns a nested cursor.
It has this syntax:
CURSOR ( subquery )
You can use a CURSOR
expression in a SELECT
statement that is not a subquery (as in Example 6-35) or pass it to a function that accepts a cursor variable parameter (see "Passing CURSOR Expressions to Pipelined Table Functions"). You cannot use a cursor expression with an implicit cursor.
See Also:
Oracle Database SQL Language Reference for more information about CURSOR
expressions, including restrictions
Example 6-35 CURSOR Expression
This example declares and defines an explicit cursor for a query that includes a cursor expression. For each department in the departments
table, the nested cursor returns the last name of each employee in that department (which it retrieves from the employees
table).
DECLARE TYPE emp_cur_typ IS REF CURSOR; emp_cur emp_cur_typ; dept_name departments.department_name%TYPE; emp_name employees.last_name%TYPE; CURSOR c1 IS SELECT department_name, CURSOR ( SELECT e.last_name FROM employees e WHERE e.department_id = d.department_id ORDER BY e.last_name ) employees FROM departments d WHERE department_name LIKE 'A%' ORDER BY department_name; BEGIN OPEN c1; LOOP -- Process each row of query result set FETCH c1 INTO dept_name, emp_cur; EXIT WHEN c1%NOTFOUND; DBMS_OUTPUT.PUT_LINE('Department: ' || dept_name); LOOP -- Process each row of subquery result set FETCH emp_cur INTO emp_name; EXIT WHEN emp_cur%NOTFOUND; DBMS_OUTPUT.PUT_LINE('-- Employee: ' || emp_name); END LOOP; END LOOP; CLOSE c1; END; /
Result:
Department: Accounting -- Employee: Gietz -- Employee: Higgins Department: Administration -- Employee: Whalen
6.6 Transaction Processing and Control
Transaction processing is an Oracle Database feature that lets multiple users work on the database concurrently, and ensures that each user sees a consistent version of data and that all changes are applied in the right order.
A transaction is a sequence of one or more SQL statements that Oracle Database treats as a unit: either all of the statements are performed, or none of them are.
Different users can write to the same data structures without harming each other's data or coordinating with each other, because Oracle Database locks data structures automatically. To maximize data availability, Oracle Database locks the minimum amount of data for the minimum amount of time.
You rarely must write extra code to prevent problems with multiple users accessing data concurrently. However, if you do need this level of control, you can manually override the Oracle Database default locking mechanisms.
Topics
See Also:
-
Oracle Database Concepts for more information about transactions
-
Oracle Database Concepts for more information about transaction processing
-
Oracle Database Concepts for more information about the Oracle Database locking mechanism
-
Oracle Database Concepts for more information about manual data locks
6.6.1 COMMIT Statement
The COMMIT
statement ends the current transaction, making its changes permanent and visible to other users.
Note:
A transaction can span multiple blocks, and a block can contain multiple transactions.
The WRITE
clause of the COMMIT
statement specifies the priority with which Oracle Database writes to the redo log the information that the commit operation generates.
Note:
The default PL/SQL commit behavior for nondistributed transactions is BATCH
NOWAIT
if the COMMIT_LOGGING
and COMMIT_WAIT
database initialization parameters have not been set.
See Also:
-
Oracle Database Concepts for more information about committing transactions
-
Oracle Database Concepts for information about distributed transactions
-
Oracle Database SQL Language Referencefor information about the
COMMIT
statement -
Oracle Data Guard Concepts and Administration for information about ensuring no loss of data during a failover to a standby database
Example 6-36 COMMIT Statement with COMMENT and WRITE Clauses
In this example, a transaction transfers money from one bank account to another. It is important that the money both leaves one account and enters the other, hence the COMMIT
WRITE
IMMEDIATE
NOWAIT
statement.
DROP TABLE accounts; CREATE TABLE accounts ( account_id NUMBER(6), balance NUMBER (10,2) ); INSERT INTO accounts (account_id, balance) VALUES (7715, 6350.00); INSERT INTO accounts (account_id, balance) VALUES (7720, 5100.50); CREATE OR REPLACE PROCEDURE transfer ( from_acct NUMBER, to_acct NUMBER, amount NUMBER ) AUTHID CURRENT_USER AS BEGIN UPDATE accounts SET balance = balance - amount WHERE account_id = from_acct; UPDATE accounts SET balance = balance + amount WHERE account_id = to_acct; COMMIT WRITE IMMEDIATE NOWAIT; END; /
Query before transfer:
SELECT * FROM accounts;
Result:
ACCOUNT_ID BALANCE ---------- ---------- 7715 6350 7720 5100.5 BEGIN transfer(7715, 7720, 250); END; /
Query after transfer:
SELECT * FROM accounts;
Result:
ACCOUNT_ID BALANCE ---------- ---------- 7715 6100 7720 5350.5
6.6.2 ROLLBACK Statement
The ROLLBACK
statement ends the current transaction and undoes any changes made during that transaction.
If you make a mistake, such as deleting the wrong row from a table, a rollback restores the original data. If you cannot finish a transaction because a SQL statement fails or PL/SQL raises an exception, a rollback lets you take corrective action and perhaps start over.
See Also:
Oracle Database SQL Language Reference for more information about the ROLLBACK
statement
Example 6-37 ROLLBACK Statement
This example inserts information about an employee into three different tables. If an INSERT
statement tries to store a duplicate employee number, PL/SQL raises the predefined exception DUP_VAL_ON_INDEX
. To ensure that changes to all three tables are undone, the exception handler runs a ROLLBACK
.
DROP TABLE emp_name; CREATE TABLE emp_name AS SELECT employee_id, last_name FROM employees; CREATE UNIQUE INDEX empname_ix ON emp_name (employee_id); DROP TABLE emp_sal; CREATE TABLE emp_sal AS SELECT employee_id, salary FROM employees; CREATE UNIQUE INDEX empsal_ix ON emp_sal (employee_id); DROP TABLE emp_job; CREATE TABLE emp_job AS SELECT employee_id, job_id FROM employees; CREATE UNIQUE INDEX empjobid_ix ON emp_job (employee_id); DECLARE emp_id NUMBER(6); emp_lastname VARCHAR2(25); emp_salary NUMBER(8,2); emp_jobid VARCHAR2(10); BEGIN SELECT employee_id, last_name, salary, job_id INTO emp_id, emp_lastname, emp_salary, emp_jobid FROM employees WHERE employee_id = 120; INSERT INTO emp_name (employee_id, last_name) VALUES (emp_id, emp_lastname); INSERT INTO emp_sal (employee_id, salary) VALUES (emp_id, emp_salary); INSERT INTO emp_job (employee_id, job_id) VALUES (emp_id, emp_jobid); EXCEPTION WHEN DUP_VAL_ON_INDEX THEN ROLLBACK; DBMS_OUTPUT.PUT_LINE('Inserts were rolled back'); END; /
6.6.3 SAVEPOINT Statement
The SAVEPOINT
statement names and marks the current point in the processing of a transaction.
Savepoints let you roll back part of a transaction instead of the whole transaction. The number of active savepoints for each session is unlimited.
When you roll back to a savepoint, any savepoints marked after that savepoint are erased. The savepoint to which you roll back is not erased. A simple rollback or commit erases all savepoints.
If you mark a savepoint in a recursive subprogram, new instances of the SAVEPOINT
statement run at each level in the recursive descent, but you can only roll back to the most recently marked savepoint.
Savepoint names are undeclared identifiers. Reusing a savepoint name in a transaction moves the savepoint from its old position to the current point in the transaction, which means that a rollback to the savepoint affects only the current part of the transaction.
See Also:
Oracle Database SQL Language Reference for more information about the SET
TRANSACTION
SQL statement
Example 6-38 SAVEPOINT and ROLLBACK Statements
This example marks a savepoint before doing an insert. If the INSERT
statement tries to store a duplicate value in the employee_id
column, PL/SQL raises the predefined exception DUP_VAL_ON_INDEX
and the transaction rolls back to the savepoint, undoing only the INSERT
statement.
DROP TABLE emp_name; CREATE TABLE emp_name AS SELECT employee_id, last_name, salary FROM employees; CREATE UNIQUE INDEX empname_ix ON emp_name (employee_id); DECLARE emp_id employees.employee_id%TYPE; emp_lastname employees.last_name%TYPE; emp_salary employees.salary%TYPE; BEGIN SELECT employee_id, last_name, salary INTO emp_id, emp_lastname, emp_salary FROM employees WHERE employee_id = 120; UPDATE emp_name SET salary = salary * 1.1 WHERE employee_id = emp_id; DELETE FROM emp_name WHERE employee_id = 130; SAVEPOINT do_insert; INSERT INTO emp_name (employee_id, last_name, salary) VALUES (emp_id, emp_lastname, emp_salary); EXCEPTION WHEN DUP_VAL_ON_INDEX THEN ROLLBACK TO do_insert; DBMS_OUTPUT.PUT_LINE('Insert was rolled back'); END; /
Example 6-39 Reusing SAVEPOINT with ROLLBACK
DROP TABLE emp_name; CREATE TABLE emp_name AS SELECT employee_id, last_name, salary FROM employees; CREATE UNIQUE INDEX empname_ix ON emp_name (employee_id); DECLARE emp_id employees.employee_id%TYPE; emp_lastname employees.last_name%TYPE; emp_salary employees.salary%TYPE; BEGIN SELECT employee_id, last_name, salary INTO emp_id, emp_lastname, emp_salary FROM employees WHERE employee_id = 120; SAVEPOINT my_savepoint; UPDATE emp_name SET salary = salary * 1.1 WHERE employee_id = emp_id; DELETE FROM emp_name WHERE employee_id = 130; SAVEPOINT my_savepoint; INSERT INTO emp_name (employee_id, last_name, salary) VALUES (emp_id, emp_lastname, emp_salary); EXCEPTION WHEN DUP_VAL_ON_INDEX THEN ROLLBACK TO my_savepoint; DBMS_OUTPUT.PUT_LINE('Transaction rolled back.'); END; /
6.6.4 Implicit Rollbacks
Before running an INSERT
, UPDATE
, DELETE
, or MERGE
statement, the database marks an implicit savepoint (unavailable to you). If the statement fails, the database rolls back to the savepoint.
Usually, just the failed SQL statement is rolled back, not the whole transaction. If the statement raises an unhandled exception, the host environment determines what is rolled back.
The database can also roll back single SQL statements to break deadlocks. The database signals an error to a participating transaction and rolls back the current statement in that transaction.
Before running a SQL statement, the database must parse it, that is, examine it to ensure it follows syntax rules and refers to valid schema objects. Errors detected while running a SQL statement cause a rollback, but errors detected while parsing the statement do not.
If you exit a stored subprogram with an unhandled exception, PL/SQL does not assign values to OUT
parameters, and does not do any rollback.
For information about handling exceptions, see PL/SQL Error Handling
6.6.5 SET TRANSACTION Statement
You use the SET
TRANSACTION
statement to begin a read-only or read-write transaction, establish an isolation level, or assign your current transaction to a specified rollback segment.
Read-only transactions are useful for running multiple queries while other users update the same tables.
During a read-only transaction, all queries refer to the same snapshot of the database, providing a multi-table, multi-query, read-consistent view. Other users can continue to query or update data as usual. A commit or rollback ends the transaction.
The SET
TRANSACTION
statement must be the first SQL statement in a read-only transaction and can appear only once in a transaction. If you set a transaction to READ
ONLY
, subsequent queries see only changes committed before the transaction began. The use of READ
ONLY
does not affect other users or transactions.
Only the SELECT
, OPEN
, FETCH
, CLOSE
, LOCK
TABLE
, COMMIT
, and ROLLBACK
statements are allowed in a read-only transaction. Queries cannot be FOR
UPDATE
.
See Also:
Oracle Database SQL Language Reference for more information about the SQL statement SET
TRANSACTION
Example 6-40 SET TRANSACTION Statement in Read-Only Transaction
In this example, a read-only transaction gather order totals for the day, the past week, and the past month. The totals are unaffected by other users updating the database during the transaction. The orders
table is in the sample schema OE.
DECLARE daily_order_total NUMBER(12,2); weekly_order_total NUMBER(12,2); monthly_order_total NUMBER(12,2); BEGIN COMMIT; -- end previous transaction SET TRANSACTION READ ONLY NAME 'Calculate Order Totals'; SELECT SUM (order_total) INTO daily_order_total FROM orders WHERE order_date = SYSDATE; SELECT SUM (order_total) INTO weekly_order_total FROM orders WHERE order_date = SYSDATE - 7; SELECT SUM (order_total) INTO monthly_order_total FROM orders WHERE order_date = SYSDATE - 30; COMMIT; -- ends read-only transaction END; /
6.6.6 Overriding Default Locking
By default, Oracle Database locks data structures automatically, which lets different applications write to the same data structures without harming each other's data or coordinating with each other.
If you must have exclusive access to data during a transaction, you can override default locking with these SQL statements:
-
LOCK
TABLE
, which explicitly locks entire tables. -
SELECT
with theFOR
UPDATE
clause (SELECT
FOR
UPDATE
), which explicitly locks specific rows of a table.
Topics
6.6.6.1 LOCK TABLE Statement
The LOCK
TABLE
statement explicitly locks one or more tables in a specified lock mode so that you can share or deny access to them.
The lock mode determines what other locks can be placed on the table. For example, many users can acquire row share locks on a table at the same time, but only one user at a time can acquire an exclusive lock. While one user has an exclusive lock on a table, no other users can insert, delete, or update rows in that table.
A table lock never prevents other users from querying a table, and a query never acquires a table lock. Only if two different transactions try to modify the same row does one transaction wait for the other to complete. The LOCK
TABLE
statement lets you specify how long to wait for another transaction to complete.
Table locks are released when the transaction that acquired them is either committed or rolled back.
See Also:
-
Oracle Database Development Guide for more information about locking tables explicitly
-
Oracle Database SQL Language Reference for more information about the
LOCK
TABLE
statement
6.6.6.2 SELECT FOR UPDATE and FOR UPDATE Cursors
The SELECT
statement with the FOR
UPDATE
clause (SELECT
FOR
UPDATE
statement) selects the rows of the result set and locks them. SELECT
FOR
UPDATE
lets you base an update on the existing values in the rows, because it ensures that no other user can change those values before you update them. You can also use SELECT
FOR
UPDATE
to lock rows that you do not want to update, as in Example 9-6.
Note:
In tables compressed with Hybrid Columnar Compression (HCC), DML statements lock compression units rather than rows. HCC, a feature of certain Oracle storage systems, is described in Oracle Database Concepts.
By default, the SELECT
FOR
UPDATE
statement waits until the requested row lock is acquired. To change this behavior, use the NOWAIT
, WAIT
, or SKIP
LOCKED
clause of the SELECT
FOR
UPDATE
statement. For information about these clauses, see Oracle Database SQL Language Reference.
When SELECT
FOR
UPDATE
is associated with an explicit cursor, the cursor is called a FOR
UPDATE
cursor. Only a FOR
UPDATE
cursor can appear in the CURRENT
OF
clause of an UPDATE
or DELETE
statement. (The CURRENT
OF
clause, a PL/SQL extension to the WHERE
clause of the SQL statements UPDATE
and DELETE
, restricts the statement to the current row of the cursor.)
When SELECT
FOR
UPDATE
queries multiple tables, it locks only rows whose columns appear in the FOR
UPDATE
clause.
6.6.6.3 Simulating CURRENT OF Clause with ROWID Pseudocolumn
The rows of the result set are locked when you open a FOR
UPDATE
cursor, not as they are fetched. The rows are unlocked when you commit or roll back the transaction. After the rows are unlocked, you cannot fetch from the FOR
UPDATE
cursor, as Example 6-41 shows (the result is the same if you substitute ROLLBACK
for COMMIT
).
The workaround is to simulate the CURRENT
OF
clause with the ROWID
pseudocolumn (described in Oracle Database SQL Language Reference). Select the rowid of each row into a UROWID
variable and use the rowid to identify the current row during subsequent updates and deletes, as in Example 6-42. (To print the value of a UROWID
variable, convert it to VARCHAR2
, using the ROWIDTOCHAR
function described in Oracle Database SQL Language Reference.)
Note:
When you update a row in a table compressed with Hybrid Columnar Compression (HCC), the ROWID
of the row changes. HCC, a feature of certain Oracle storage systems, is described in Oracle Database Concepts.
Caution:
Because no FOR
UPDATE
clause locks the fetched rows, other users might unintentionally overwrite your changes.
Note:
The extra space needed for read consistency is not released until the cursor is closed, which can slow down processing for large updates.
Example 6-41 FETCH with FOR UPDATE Cursor After COMMIT Statement
DROP TABLE emp; CREATE TABLE emp AS SELECT * FROM employees; DECLARE CURSOR c1 IS SELECT * FROM emp FOR UPDATE OF salary ORDER BY employee_id; emp_rec emp%ROWTYPE; BEGIN OPEN c1; LOOP FETCH c1 INTO emp_rec; -- fails on second iteration EXIT WHEN c1%NOTFOUND; DBMS_OUTPUT.PUT_LINE ( 'emp_rec.employee_id = ' || TO_CHAR(emp_rec.employee_id) ); UPDATE emp SET salary = salary * 1.05 WHERE employee_id = 105; COMMIT; -- releases locks END LOOP; END; /
Result:
emp_rec.employee_id = 100 DECLARE * ERROR at line 1: ORA-01002: fetch out of sequence ORA-06512: at line 11
Example 6-42 Simulating CURRENT OF Clause with ROWID Pseudocolumn
DROP TABLE emp; CREATE TABLE emp AS SELECT * FROM employees; DECLARE CURSOR c1 IS SELECT last_name, job_id, rowid FROM emp; -- no FOR UPDATE clause my_lastname employees.last_name%TYPE; my_jobid employees.job_id%TYPE; my_rowid UROWID; BEGIN OPEN c1; LOOP FETCH c1 INTO my_lastname, my_jobid, my_rowid; EXIT WHEN c1%NOTFOUND; UPDATE emp SET salary = salary * 1.02 WHERE rowid = my_rowid; -- simulates WHERE CURRENT OF c1 COMMIT; END LOOP; CLOSE c1; END; /
6.7 Autonomous Transactions
An autonomous transaction is an independent transaction started by another transaction, the main transaction.
Autonomous transactions do SQL operations and commit or roll back, without committing or rolling back the main transaction.
Figure 6-1 shows how control flows from the main transaction (MT) to an autonomous routine (proc2
) and back again. The autonomous routine commits two autonomous transactions (AT1 and AT2).
Note:
Although an autonomous transaction is started by another transaction, it is not a nested transaction, because:
-
It does not share transactional resources (such as locks) with the main transaction.
-
It does not depend on the main transaction.
For example, if the main transaction rolls back, nested transactions roll back, but autonomous transactions do not.
-
Its committed changes are visible to other transactions immediately.
A nested transaction's committed changes are not visible to other transactions until the main transaction commits.
-
Exceptions raised in an autonomous transaction cause a transaction-level rollback, not a statement-level rollback.
Topics
See Also:
Oracle Database Development Guide for more information about autonomous transactions
6.7.1 Advantages of Autonomous Transactions
After starting, an autonomous transaction is fully independent. It shares no locks, resources, or commit-dependencies with the main transaction. You can log events, increment retry counters, and so on, even if the main transaction rolls back.
Autonomous transactions help you build modular, reusable software components. You can encapsulate autonomous transactions in stored subprograms. An invoking application needs not know whether operations done by that stored subprogram succeeded or failed.
6.7.2 Transaction Context
The main transaction shares its context with nested routines, but not with autonomous transactions. When one autonomous routine invokes another (or itself, recursively), the routines share no transaction context. When an autonomous routine invokes a nonautonomous routine, the routines share the same transaction context.
6.7.3 Transaction Visibility
Changes made by an autonomous transaction become visible to other transactions when the autonomous transaction commits. These changes become visible to the main transaction when it resumes, if its isolation level is set to READ
COMMITTED
(the default).
If you set the isolation level of the main transaction to SERIALIZABLE
, changes made by its autonomous transactions are not visible to the main transaction when it resumes:
SET TRANSACTION ISOLATION LEVEL SERIALIZABLE;
Note:
-
Transaction properties apply only to the transaction in which they are set.
-
Cursor attributes are not affected by autonomous transactions.
6.7.4 Declaring Autonomous Routines
To declare an autonomous routine, use the AUTONOMOUS_TRANSACTION
pragma.
For information about this pragma, see "AUTONOMOUS_TRANSACTION Pragma".
Tip:
For readability, put the AUTONOMOUS_TRANSACTION
pragma at the top of the declarative section. (The pragma is allowed anywhere in the declarative section.)
You cannot apply the AUTONOMOUS_TRANSACTION
pragma to an entire package or ADT, but you can apply it to each subprogram in a package or each method of an ADT.
Example 6-43 Declaring Autonomous Function in Package
This example marks a package function as autonomous.
CREATE OR REPLACE PACKAGE emp_actions AUTHID DEFINER AS -- package specification FUNCTION raise_salary (emp_id NUMBER, sal_raise NUMBER) RETURN NUMBER; END emp_actions; / CREATE OR REPLACE PACKAGE BODY emp_actions AS -- package body -- code for function raise_salary FUNCTION raise_salary (emp_id NUMBER, sal_raise NUMBER) RETURN NUMBER IS PRAGMA AUTONOMOUS_TRANSACTION; new_sal NUMBER(8,2); BEGIN UPDATE employees SET salary = salary + sal_raise WHERE employee_id = emp_id; COMMIT; SELECT salary INTO new_sal FROM employees WHERE employee_id = emp_id; RETURN new_sal; END raise_salary; END emp_actions; /
Example 6-44 Declaring Autonomous Standalone Procedure
This example marks a standalone subprogram as autonomous.
CREATE OR REPLACE PROCEDURE lower_salary
(emp_id NUMBER, amount NUMBER)
AUTHID DEFINER AS
PRAGMA AUTONOMOUS_TRANSACTION;
BEGIN
UPDATE employees
SET salary = salary - amount
WHERE employee_id = emp_id;
COMMIT;
END lower_salary;
/
Example 6-45 Declaring Autonomous PL/SQL Block
This example marks a schema-level PL/SQL block as autonomous. (A nested PL/SQL block cannot be autonomous.)
DROP TABLE emp;
CREATE TABLE emp AS SELECT * FROM employees;
DECLARE
PRAGMA AUTONOMOUS_TRANSACTION;
emp_id NUMBER(6) := 200;
amount NUMBER(6,2) := 200;
BEGIN
UPDATE employees
SET salary = salary - amount
WHERE employee_id = emp_id;
COMMIT;
END;
/
6.7.5 Controlling Autonomous Transactions
The first SQL statement in an autonomous routine begins a transaction. When one transaction ends, the next SQL statement begins another transaction. All SQL statements run since the last commit or rollback comprise the current transaction. To control autonomous transactions, use these statements, which apply only to the current (active) transaction:
-
COMMIT
-
ROLLBACK
[TO
savepoint_name
] -
SAVEPOINT
savepoint_name
-
SET
TRANSACTION
Topics
6.7.5.1 Entering and Exiting Autonomous Routines
When you enter the executable section of an autonomous routine, the main transaction suspends. When you exit the routine, the main transaction resumes.
If you try to exit an active autonomous transaction without committing or rolling back, the database raises an exception. If the exception is unhandled, or if the transaction ends because of some other unhandled exception, then the transaction rolls back.
To exit normally, the routine must explicitly commit or roll back all autonomous transactions. If the routine (or any routine invoked by it) has pending transactions, then PL/SQL raises an exception and the pending transactions roll back.
6.7.5.2 Committing and Rolling Back Autonomous Transactions
COMMIT
and ROLLBACK
end the active autonomous transaction but do not exit the autonomous routine. When one transaction ends, the next SQL statement begins another transaction. A single autonomous routine can contain several autonomous transactions, if it issues several COMMIT
statements.
6.7.5.3 Savepoints
The scope of a savepoint is the transaction in which it is defined. Savepoints defined in the main transaction are unrelated to savepoints defined in its autonomous transactions. In fact, the main transaction and an autonomous transaction can use the same savepoint names.
You can roll back only to savepoints marked in the current transaction. In an autonomous transaction, you cannot roll back to a savepoint marked in the main transaction. To do so, you must resume the main transaction by exiting the autonomous routine.
When in the main transaction, rolling back to a savepoint marked before you started an autonomous transaction does not roll back the autonomous transaction. Remember, autonomous transactions are fully independent of the main transaction.
6.7.5.4 Avoiding Errors with Autonomous Transactions
To avoid some common errors, remember:
-
If an autonomous transaction tries to access a resource held by the main transaction, a deadlock can occur. The database raises an exception in the autonomous transaction, which rolls back if the exception is unhandled.
-
The database initialization parameter
TRANSACTIONS
specifies the maximum number of concurrent transactions. That number might be exceeded because an autonomous transaction runs concurrently with the main transaction. -
If you try to exit an active autonomous transaction without committing or rolling back, the database raises an exception. If the exception is unhandled, the transaction rolls back.
-
You cannot run a
PIPE
ROW
statement in an autonomous routine while an autonomous transaction is open. You must close the autonomous transaction before running thePIPE
ROW
statement. This is normally accomplished by committing or rolling back the autonomous transaction before running thePIPE
ROW
statement.
6.7.6 Autonomous Triggers
A trigger must be autonomous to run TCL or DDL statements.
To run DDL statements, the trigger must use native dynamic SQL.
See Also:
-
PL/SQL Triggers, for general information about triggers
-
"Description of Static SQL" for general information about TCL statements
-
Oracle Database SQL Language Reference for information about DDL statements
-
"Native Dynamic SQL" for information about native dynamic SQL
One use of triggers is to log events transparently—for example, to log all inserts into a table, even those that roll back.
Example 6-46 Autonomous Trigger Logs INSERT Statements
In this example, whenever a row is inserted into the EMPLOYEES
table, a trigger inserts the same row into a log table. Because the trigger is autonomous, it can commit changes to the log table regardless of whether they are committed to the main table.
DROP TABLE emp; CREATE TABLE emp AS SELECT * FROM employees; -- Log table: DROP TABLE log; CREATE TABLE log ( log_id NUMBER(6), up_date DATE, new_sal NUMBER(8,2), old_sal NUMBER(8,2) ); -- Autonomous trigger on emp table: CREATE OR REPLACE TRIGGER log_sal BEFORE UPDATE OF salary ON emp FOR EACH ROW DECLARE PRAGMA AUTONOMOUS_TRANSACTION; BEGIN INSERT INTO log ( log_id, up_date, new_sal, old_sal ) VALUES ( :old.employee_id, SYSDATE, :new.salary, :old.salary ); COMMIT; END; / UPDATE emp SET salary = salary * 1.05 WHERE employee_id = 115; COMMIT; UPDATE emp SET salary = salary * 1.05 WHERE employee_id = 116; ROLLBACK; -- Show that both committed and rolled-back updates -- add rows to log table SELECT * FROM log WHERE log_id = 115 OR log_id = 116;
Result:
LOG_ID UP_DATE NEW_SAL OLD_SAL ---------- --------- ---------- ---------- 115 02-OCT-12 3255 3100 116 02-OCT-12 3045 2900 2 rows selected.
Example 6-47 Autonomous Trigger Uses Native Dynamic SQL for DDL
In this example, an autonomous trigger uses native dynamic SQL (an EXECUTE
IMMEDIATE
statement) to drop a temporary table after a row is inserted into the table log
.
DROP TABLE temp; CREATE TABLE temp ( temp_id NUMBER(6), up_date DATE ); CREATE OR REPLACE TRIGGER drop_temp_table AFTER INSERT ON log DECLARE PRAGMA AUTONOMOUS_TRANSACTION; BEGIN EXECUTE IMMEDIATE 'DROP TABLE temp'; COMMIT; END; / -- Show how trigger works SELECT * FROM temp;
Result:
no rows selected INSERT INTO log (log_id, up_date, new_sal, old_sal) VALUES (999, SYSDATE, 5000, 4500); 1 row created. SELECT * FROM temp;
Result:
SELECT * FROM temp * ERROR at line 1: ORA-00942: table or view does not exist
6.7.7 Invoking Autonomous Functions from SQL
A function invoked from SQL statements must obey rules meant to control side effects.
By definition, an autonomous routine never reads or writes database state (that is, it neither queries nor modifies any database table).
See Also:
"Subprogram Side Effects" for more information
Example 6-48 Invoking Autonomous Function
The package function log_msg
is autonomous. Therefore, when the query invokes the function, the function inserts a message into database table debug_output
without violating the rule against writing database state (modifying database tables).
DROP TABLE debug_output; CREATE TABLE debug_output (message VARCHAR2(200)); CREATE OR REPLACE PACKAGE debugging AUTHID DEFINER AS FUNCTION log_msg (msg VARCHAR2) RETURN VARCHAR2; END debugging; / CREATE OR REPLACE PACKAGE BODY debugging AS FUNCTION log_msg (msg VARCHAR2) RETURN VARCHAR2 IS PRAGMA AUTONOMOUS_TRANSACTION; BEGIN INSERT INTO debug_output (message) VALUES (msg); COMMIT; RETURN msg; END; END debugging; / -- Invoke package function from query DECLARE my_emp_id NUMBER(6); my_last_name VARCHAR2(25); my_count NUMBER; BEGIN my_emp_id := 120; SELECT debugging.log_msg(last_name) INTO my_last_name FROM employees WHERE employee_id = my_emp_id; /* Even if you roll back in this scope, the insert into 'debug_output' remains committed, because it is part of an autonomous transaction. */ ROLLBACK; END; /
