3 Configuring Authentication

Authentication means to verify the identity of users or other entities that connect to the database.

About Authentication

Authentication means verifying the identity of a user, device, or other entity who wants to use data, resources, or applications.

Validating this identity establishes a trust relationship for further interactions. Authentication also enables accountability by making it possible to link access and actions to specific identities. After authentication, authorization processes can allow or limit the levels of access and action permitted to that entity.

You can authenticate both database and nondatabase users for an Oracle database. For simplicity, the same authentication method is generally used for all database users, but Oracle Database allows a single database instance to use any or all methods. Oracle Database requires special authentication procedures for database administrators, because they perform special database operations. Oracle Database also encrypts passwords during transmission to ensure the security of network authentication.

After authentication, authorization processes can allow or limit the levels of access and action permitted to that entity.

Configuring Password Protection

You can secure user passwords in a variety of ways, such as controlling the password creation requirements or using password management policies.

What Are the Oracle Database Built-in Password Protections?

Oracle Database provides a set of built-in password protections designed to protect your users' passwords.

These password protections are as follows:

  • Password encryption. Oracle Database automatically and transparently encrypts passwords during network (client-to-server and server-to-server) connections, using Advanced Encryption Standard (AES) before sending them across the network. However, a password that is specified within a SQL statement (such as CREATE USER user_name IDENTIFIED BY password;) is still transmitted across the network in clear text in the network trace files. For this reason, you should have native network encryption enabled or configure Secure Sockets Layer (SSL) encryption.

  • Password complexity checking. In a default installation, Oracle Database provides the ora12c_verify_function and ora12c_strong_verify_function password verification functions to ensure that new or changed passwords are sufficiently complex to prevent intruders who try to break into the system by guessing passwords. You must manually enable password complexity checking. You can further customize the complexity of your users' passwords. See About Password Complexity Verification for more information.

  • Preventing passwords from being broken. If a user tries to log in to Oracle Database multiple times using an incorrect password, Oracle Database delays each login by one second. This protection applies for attempts made from different IP addresses or multiple client connections. This feature significantly decreases the number of passwords that an intruder would be able to try within a fixed time period when attempting to log in. The failed login delay slows down each failed login attempt, increasing the overall time that is required to perform a password-guessing attack, because such attacks usually require a very large number of failed login attempts.

    For non-administrative logins, Oracle Database protects against concurrent password guessing attacks by setting an exclusive lock for the failed login delay. This prevents an intruder from attempting to sidestep the failed login delay when the intruder tries the next concurrent guess in a different database session as soon as the first guess fails and is delayed.

    By holding an exclusive lock on the account that is being attacked, Oracle Database mitigates concurrent password guessing attacks, but this can simultaneously leave the account vulnerable to denial-of-service (DoS) attacks. To remedy this problem, you should create a password profile where the FAILED_LOGIN_ATTEMPTS parameter is set to UNLIMITED, and then apply this password profile to the user account. The value UNLIMITED for the FAILED_LOGIN_ATTEMPTS parameter setting disables failed login delays and does not limit the number of failed login attempts. For these types of accounts, Oracle recommends that you use a long random password.

    The concurrent password-guessing attack protection does not apply to administrative user connections, because these kinds of connections must remain available at all times and be immune to denial-of-service attacks. Hence, Oracle recommends that you choose long passwords for any administrative privileged account.

  • Enforced case sensitivity for passwords. Passwords are case sensitive. For example, the password hPP5620qr fails if it is entered as hpp5620QR or hPp5620Qr. See Managing Password Case Sensitivity for information about how case sensitivity works, and how it affects password files and database links.

  • Passwords hashed using the 12C password version. To verify the user's password and enforce case sensitivity in password creation, Oracle Database uses the 12C password version, which is based on a de-optimized algorithm that involves Password-Based Key Derivation Function (PBKDF2) and the SHA-512 cryptographic hash functions. See Ensuring Against Password Security Threats by Using the 12C Password Version for more information.

See Also:

Guidelines for Securing Passwords for advice about securing passwords

Minimum Requirements for Passwords

Oracle provides a set of minimum requirements for passwords.

Passwords can be at most 30 bytes long. There are a variety of ways that you can secure passwords, ranging from requiring passwords to be of a sensible length to creating custom password complexity verification scripts that enforce the password complexity policy requirements that apply at your site.

Creating a Password by Using the IDENTIFIED BY Clause

SQL statements that accept the IDENTIFIED BY clause also enable you to create passwords.

  • To create passwords for users, use the CREATE USER, ALTER USER, GRANT CREATE SESSION, or CREATE DATABASE LINK SQL statement.

The following SQL statements create passwords with the IDENTIFIED BY clause.

CREATE USER psmith IDENTIFIED BY password;
GRANT CREATE SESSION TO psmith IDENTIFIED BY password;
ALTER USER psmith IDENTIFIED BY password;
CREATE DATABASE LINK AUTHENTICATED BY psmith IDENTIFIED BY password;

Using a Password Management Policy

A password management policy can create and enforce a set of restrictions that can better secure user passwords.

About Managing Passwords

Database security systems that depend on passwords require that passwords be kept secret at all times.

Because passwords are vulnerable to theft and misuse, Oracle Database uses a password management policy. Database administrators and security officers control this policy through user profiles, enabling greater control of database security.

You can use the CREATE PROFILE statement to create a user profile. The profile is assigned to a user with the CREATE USER or ALTER USER statement.

Finding User Accounts That Have Default Passwords

The DBA_USERS_WITH_DEFPWD data dictionary view can find user accounts that use default passwords.

When you create a database, most of the default accounts are locked with the passwords expired. If you have upgraded from an earlier release of Oracle Database, then you may have user accounts that have default passwords. These are default accounts that are created when you create a database, such as the HR, OE, and SCOTT accounts.

For greater security, you should change the passwords for these accounts. Using a default password that is commonly known can make your database vulnerable to attacks by intruders.

  1. Log in to the database instance using SQL*Plus with the SYSDBA administrative privilege.

    For example:

    sqlplus sys as sysdba
    Enter password: password

  2. Query the DBA_USERS_WITH_DEFPWD data dictionary view.

    For example, to find both the names of accounts that have default passwords and the status of the account:

    SELECT d.username, u.account_status
    FROM DBA_USERS_WITH_DEFPWD d, DBA_USERS u
    WHERE d.username = u.username
    ORDER BY 2,1;

    USERNAME  ACCOUNT_STATUS
    --------- ---------------------------
    SCOTT     EXPIRED & LOCKED

  3. Change the passwords for any accounts that the DBA_USERS_WITH_DEFPWD view lists.

    Oracle recommends that you do not assign these accounts passwords that they may have had in previous releases of Oracle Database.

    For example:

    ALTER USER SCOTT ACCOUNT UNLOCK IDENTIFIED BY password;


    Follow the guidelines in Minimum Requirements for Passwords to replace password with a password that is secure.

Password Settings in the Default Profile

A profile is a collection of parameters that sets limits on database resources.

If you assign the profile to a user, then that user cannot exceed these limits. You can use profiles to configure database settings such as sessions per user, logging and tracing features, and so on. Profiles can also control user passwords. To find information about the current password settings in the profile, you can query the DBA_PROFILES data dictionary view.

Table 3-1 lists the password-specific parameter settings in the default profile.

Table 3-1 Password-Specific Settings in the Default Profile

Parameter Default Setting Description

INACTIVE_ACCOUNT_TIME

UNLIMITED

Locks the account of a database user who has not logged in to the database instance in a specified number of days.

See Automatically Locking Inactive Database User Accounts for more information.

FAILED_LOGIN_ATTEMPTS

10

Sets the maximum times a user try to log in and to fail before locking the account.

Notes:

PASSWORD_GRACE_TIME

7

Sets the number of days that a user has to change his or her password before it expires.

See About Controlling Password Aging and Expiration for more information.

PASSWORD_LIFE_TIME

180

Sets the number of days the user can use his or her current password.

See About Controlling Password Aging and Expiration for more information.

PASSWORD_LOCK_TIME

1

Sets the number of days an account will be locked after the specified number of consecutive failed login attempts. After the time passes, then the account becomes unlocked. This user's profile parameter is useful to help prevent brute force attacks on user passwords but not to increase the maintenance burden on administrators.

See Automatically Locking User Accounts After Failed Logins for more information.

PASSWORD_REUSE_MAX

UNLIMITED

Sets the number of password changes required before the current password can be reused.

See Controlling the User Ability to Reuse Previous Passwords for more information.

PASSWORD_REUSE_TIME

UNLIMITED

Sets the number of days before which a password cannot be reused.

See Controlling the User Ability to Reuse Previous Passwords for more information.

Using the ALTER PROFILE Statement to Set Profile Limits

You can modify profile limits such as failed login attempts, password lock times, password reuse, and several other settings.

These settings are described in Table 3-1. For greater security, use the default settings that are described in this table, based on your needs.

  • Use the ALTER PROFILE statement to modify a user's profile limits.

For example:

ALTER PROFILE prof LIMIT
 FAILED_LOGIN_ATTEMPTS 9
 PASSWORD_LOCK_TIME 10
 INACTIVE_ACCOUNT_TIME 21;
Disabling and Enabling the Default Password Security Settings

Oracle provides scripts that you can use to disable and enable the default password security settings.

If your applications use the default password security settings from Oracle Database 10g release 2 (10.2), then you can revert to these settings until you modify the applications to use the default password security settings from Oracle Database 11g or later.
  1. Modify your applications to conform to the password security settings from Oracle Database 11g or later.
  2. Update your database to use the security configuration that suits your business needs, using one of the following methods:
    • Manually update the database security configuration.

    • Run the secconf.sql script to apply the default password settings from Oracle Database 11g or later. You can customize this script to have different security settings if you like, but remember that the settings listed in the original script are Oracle-recommended settings.

If you created your database manually, then you should run the secconf.sql script to apply the Oracle default password settings to the database. Databases that have been created with Database Configuration Assistant (DBCA) will have these settings, but manually created databases do not.

The secconf.sql script is in the $ORACLE_HOME/rdbms/admin directory. The secconf.sql script affects both password and audit settings. It has no effect on other security settings.

Automatically Locking Inactive Database User Accounts

The INACTIVE_ACCOUNT_TIME profile parameter locks a user account that has not logged in to the database instance in a specified number of days.

Users are considered active users if they log in periodically. The INACTIVE_ACCOUNT_TIME timing is based on the number of days after the last time a user successfully logs in.
  • To lock user accounts automatically after a specified number of days, set the INACTIVE_ACCOUNT_TIME profile parameter in the CREATE PROFILE or ALTER PROFILE statement.
    Note the following:
    • The default value for INACTIVE_ACCOUNT_TIME is UNLIMITED.

    • You must specify a whole number for the number of days. The minimum setting is 15 and the maximum is 24855.

    • To set the user’s account to have an unlimited inactivity time, set the INACTIVE_ACCOUNT_TIME to UNLIMITED.

    • To set the user’s account to use the time specified by the default profile, set INACTIVE_ACCOUNT_TIME to DEFAULT.

    • You can set this parameter for all database authenticated users, including administrative users, but not for external or global authenticated users.

    • In a read-only database, the last successful login is not considered in the INACTIVE_ACCOUNT_TIME timing. It is not possible to lock a user account in a read-only database (except by performing consecutive failed logins equal in number to the account’s FAILED_LOGIN_ATTEMPTS password profile setting).

    • For a newly created user account, the timing begins at account creation time. When this user logs out and then logs again, the timing starts when the user successfully logs in.

    • In a multitenant environment, the INACTIVE_ACCOUNT_TIME setting applies to the last time a common user logs in to the root. A common user is considered active if this user logs in to any of the PDBs or the root.

    • For a proxy user account login, the INACTIVE_ACCOUNT_TIME begins the timing when the proxy user logs in successfully.

For example, to create a profile that locks an account after 60 days of being inactive:

CREATE PROFILE time_limit LIMIT
 INACTIVE_ACCOUNT_TIME 60;
Automatically Locking User Accounts After Failed Logins

Oracle Database can lock a user's account after a specified number of consecutive failed log-in attempts.

  • To lock user accounts automatically after a specified time interval or to require database administrator intervention to be unlocked, set the PASSWORD_LOCK_TIME profile parameter in the CREATE PROFILE or ALTER PROFILE statement.

    For example, to set the time interval to 10 days:

    PASSWORD_LOCK_TIME = 10

Note the following:

  • You can lock accounts manually, so that they must be unlocked explicitly by a database administrator.

  • You can specify the permissible number of failed login attempts by using the CREATE PROFILE statement. You can also specify the amount of time an account remains locked.

  • Each time the user unsuccessfully logs in, Oracle Database increases the delay exponentially with each login failure.

  • If you do not specify a time interval for unlocking the account, then PASSWORD_LOCK_TIME assumes the value specified in a default profile. (The recommended value is 1 day.) If you specify PASSWORD_LOCK_TIME as UNLIMITED, then you must explicitly unlock the account by using an ALTER USER statement. For example, assuming that PASSWORD_LOCK_TIME UNLIMITED is specified for johndoe, then you use the following statement to unlock the johndoe account:

    ALTER USER johndoe ACCOUNT UNLOCK;

  • After a user successfully logs into an account, Oracle Database resets the unsuccessful login attempt count for the user. If it is non-zero, then the count is set to zero.

  • In a multitenant environment, a locked CDB common user account will be locked across all PDBs in the CDB. A locked application common user account will be locked across all PDBs that are associated with the application root.

Example: Locking an Account with the CREATE PROFILE Statement

The CREATE PROFILE statement can lock user accounts if a user’s attempt to log in violates the CREATE PROFILE settings.

Example 3-1 sets the maximum number of failed login attempts for the user johndoe to 10 (the default), and the amount of time the account locked to 30 days. The account will unlock automatically after 30 days.

Example 3-1 Locking an Account with the CREATE PROFILE Statement

CREATE PROFILE prof LIMIT
 FAILED_LOGIN_ATTEMPTS 10
 PASSWORD_GRACE_TIME 3

ALTER USER johndoe PROFILE prof;
Explicitly Locking a User Account

When you explicitly lock a user account, the account cannot be unlocked automatically. Only a security administrator can unlock the account.

In a multitenant environment, after you have locked a CDB common user account in the CDB root, this user cannot log in to any PDB that is associated with this root, nor can this account be unlocked in a PDB. In addition, you can lock a CDB common account locally in a PDB, which will prevent the CDB common user from logging in to that PDB. Similarly, an application common user account that is locked in the application root cannot log in to any PDB associated with the application root, nor can the application common user be unlocked in an application PDB. You can explicitly lock an application common user locally in an application PDB.
  • To explicitly lock a user account, use the CREATE USER or ALTER USER statement.

For example, the following statement locks the user account, susan:

ALTER USER susan ACCOUNT LOCK;
Controlling the User Ability to Reuse Previous Passwords

You can ensure that users do not reuse previous passwords for an amount of time or for a number of password changes.

  • To ensure that users cannot reuse their passwords for a specified period of time, configure the rules for password reuse with the CREATE PROFILE or ALTER PROFILE statements.

Table 3-2 lists the CREATE PROFILE and ALTER PROFILE parameters that control ability of a user to reuse a previous password.

Table 3-2 Parameters Controlling Reuse of a Previous Password

Parameter Name Description and Use

PASSWORD_REUSE_TIME

Requires either of the following:

  • A number specifying how many days (or a fraction of a day) between the earlier use of a password and its next use

  • The word UNLIMITED

PASSWORD_REUSE_MAX

Requires either of the following:

  • An integer to specify the number of password changes required before a password can be reused

  • The word UNLIMITED

If you do not specify a parameter, then the user can reuse passwords at any time, which is not a good security practice.

If neither parameter is UNLIMITED, then password reuse is allowed, but only after meeting both conditions. The user must have changed the password the specified number of times, and the specified number of days must have passed since the previous password was last used.

For example, suppose that the profile of user A had PASSWORD_REUSE_MAX set to 10 and PASSWORD_REUSE_TIME set to 30. User A cannot reuse a password until he or she has reset the password 10 times, and until 30 days had passed since the password was last used.

If either parameter is specified as UNLIMITED, then the user can never reuse a password.

If you set both parameters to UNLIMITED, then Oracle Database ignores both, and the user can reuse any password at any time.

Note:

If you specify DEFAULT for either parameter, then Oracle Database uses the value defined in the DEFAULT profile, which sets all parameters to UNLIMITED. Oracle Database thus uses UNLIMITED for any parameter specified as DEFAULT, unless you change the setting for that parameter in the DEFAULT profile.

About Controlling Password Aging and Expiration

You can specify a password lifetime, after which the password expires.

This means that the next time the user logs in with the current, correct password, he or she is prompted to change the password. By default, there are no complexity or password history checks, so users can still reuse any previous or weak passwords. You can control these factors by setting the PASSWORD_REUSE_TIME, PASSWORD_REUSE_MAX, and PASSWORD_VERIFY_FUNCTION parameters.

In addition, you can set a grace period, during which each attempt to log in to the database account receives a warning message to change the password. If the user does not change it by the end of that period, then Oracle Database expires the account.

As a database administrator, you can manually set the password state to be expired, which sets the account status to EXPIRED. The user must then follow the prompts to change the password before the logon can proceed.

For example, in SQL*Plus, suppose user SCOTT tries to log in with the correct credentials, but his password has expired. User SCOTT will then see the ORA-28001: The password has expired error and be prompted to change his password, as follows:

Changing password for scott
New password: new_password
Retype new password: new_password
Password changed.
Using the CREATE PROFILE or ALTER PROFILE Statement to Set a Password Lifetime

When you set a lifetime for a password, the user must create a new password when this lifetime ends.

  • Use the CREATE PROFILE or ALTER PROFILE statement to specify a lifetime for passwords.

The following example demonstrates how to create and assign a profile to user johndoe, and the PASSWORD_LIFE_TIME clause specifies that johndoe can use the same password for 180 days before it expires.

CREATE PROFILE prof LIMIT
 FAILED_LOGIN_ATTEMPTS 4
 PASSWORD_GRACE_TIME 3
 PASSWORD_LIFE_TIME 180;
ALTER USER johndoe PROFILE prof;
Checking the Status of a User Account

You can check the status of any account, whether it is open, in grace, or expired.

  • To check the status of a user account, query the ACCOUNT_STATUS column of the DBA_USERS data dictionary view.

For example:

SELECT ACCOUNT_STATUS FROM DBA_USERS WHERE USERNAME = 'username';
Password Change Life Cycle

After a password is created, it follows a lifecycle and grace period in four phases.

Figure 3-1 shows the life cycle of the password lifetime and grace period.

Figure 3-1 Password Change Life Cycle

Description of Figure 3-1 follows
Description of "Figure 3-1 Password Change Life Cycle"

In this figure:

  • Phase 1: After the user account is created, or the password of an existing account is changed, the password lifetime period begins.

  • Phase 2: This phase represents the period of time after the password lifetime ends but before the user logs in again with the correct password. The correct credentials are needed for Oracle Database to update the account status. Otherwise, the account status will remain unchanged. Oracle Database does not have any background process to update the account status. All changes to the account status are driven by the Oracle Database server process on behalf of authenticated users.

  • Phase 3: When the user finally does log in, the grace period begins. Oracle Database then updates the DBA_USERS.EXPIRY_DATE column to a new value using the current time plus the value of the PASSWORD_GRACE_TIME setting from the account's password profile. At this point, the user receives an ORA-28002 warning message about the password expiring in the near future (for example, ORA-28002 The password will expire within 7 days if PASSWORD_GRACE_TIME is set to 7 days), but the user can still log in without changing the password. The DBA_USERS.EXPIRY_DATE column shows the time in the future when the user will be prompted to change their password.

  • Phase 4: After the grace period (Phase 3) ends, the ORA-28001: The password has expired error appears, and the user is prompted to change the password after entering the current, correct password before the authentication can proceed. If the user has an Oracle Active Data Guard configuration, where there is a primary and a stand-by database, and the authentication attempt is made on the standby database (which is a read-only database), then the ORA-28032: Your password has expired and the database is set to read-only error appears. The user should log into the primary database and change the password there.

During any of these four phases, you can query the DBA_USERS data dictionary view to find the user's account status in the DBA_USERS.ACCOUNT_STATUS column.

In the following example, the profile assigned to johndoe includes the specification of a grace period: PASSWORD_GRACE_TIME = 3 (the recommended value). The first time johndoe tries to log in to the database after 90 days (this can be any day after the 90th day, that is, the 91st day, 100th day, or another day), he receives a warning message that his password will expire in 3 days. If 3 days pass, and if he does not change his password, then the password expires. After this, he receives a prompt to change his password on any attempt to log in.

CREATE PROFILE prof LIMIT
 FAILED_LOGIN_ATTEMPTS 4
 PASSWORD_LIFE_TIME 90
 PASSWORD_GRACE_TIME 3;

ALTER USER johndoe PROFILE prof;

A database administrator or a user who has the ALTER USER system privilege can explicitly expire a password by using the CREATE USER and ALTER USER statements. The following statement creates a user with an expired password. This setting forces the user to change the password before the user can log in to the database.

CREATE USER jbrown
 IDENTIFIED BY password
 ...
 PASSWORD EXPIRE;

There is no "password unexpire" clause for the CREATE USER statement, but an account can be "unexpired" by changing the password on the account.

PASSWORD_LIFE_TIME Profile Parameter Low Value

Be careful if you set the PASSWORD_LIFE_TIME parameter of CREATE PROFILE or ALTER PROFILE to a low value (for example, 1 day).

The PASSWORD_LIFE_TIME limit of a profile is measured from the last time that an account's password is changed, or the account creation time if the password has never been changed. These dates are recorded in the PTIME (password change time) and CTIME (account creation time) columns of the SYS.USER$ system table. The PASSWORD_LIFE_TIME limit is not measured starting from the timestamp of the last change to the PASSWORD_LIFE_TIME profile parameter, as may be initially thought. Therefore, any accounts affected by the changed profile whose last password change time was more than PASSWORD_LIFE_TIME days ago immediately expire and enter their grace period on their next connection, issuing the ORA-28002: The password will expire within n days warning.

As a database administrator, you can find an account's last password change time as follows:

ALTER SESSION SET NLS_DATE_FORMAT='DD-MON-YYYY HH24:MI:SS';
SELECT PTIME FROM SYS.USER$ WHERE NAME = 'user_name'; -- Password change time

To find when the account was created and the password expiration date, issue the following query:

SELECT CREATED, EXPIRY_DATE FROM DBA_USERS WHERE USERNAME = 'user_name';

If the user who is assigned this profile is currently logged in when you set the PASSWORD_LIFE_TIME parameter and remains logged in, then Oracle Database does not change the user's account status from OPEN to EXPIRED(GRACE) when the currently listed expiration date passes. The timing begins only when the user logs into the database. You can check the user's last login time as follows:

SELECT LAST_LOGIN FROM DBA_USERS WHERE USERNAME = 'user_name';

When making changes to a password profile, a database administrator must be aware that if some of the users who are subject to this profile are currently logged in to the Oracle database while their password profile is being updated by the administrator, then those users could potentially remain logged in to the system even beyond the expiration date of their password. You can find the currently logged in users by querying the USERNAME column of the V$SESSION view.

This is because the expiration date of a user's password is based on the timestamp of the last password change on their account plus the value of the PASSWORD_LIFE_TIME password profile parameter set by the administrator. It is not based on the timestamp of the last change to the password profile itself.

Note the following:

  • If the user is not logged in when you set PASSWORD_LIFE_TIME to a low value, then the user's account status does not change until the user logs in.

  • You can set the PASSWORD_LIFE_TIME parameter to UNLIMITED, but this only affects accounts that have not entered their grace period. After the grace period expires, the user must change the password.

Managing the Complexity of Passwords

Oracle Database provides a set of functions that you can use to manage the complexity of passwords.

About Password Complexity Verification

Complexity verification checks that each password is complex enough to protect against intruders who try to guess user passwords.

Using a complexity verification function forces users to create strong, secure passwords for database user accounts. You must ensure that the passwords for your users are complex enough to provide reasonable protection against intruders who try to break into the system by guessing passwords.

How Oracle Database Checks the Complexity of Passwords

Oracle Database provides four password verification functions to check password complexity.

These functions are in the catpvf.sql PL/SQL script (located in $ORACLE_HOME/rdbms/admin). When these functions are enabled, they can check whether users are correctly creating or modifying their passwords. When enabled, password complexity checking is not enforced for user SYS; it only applies to non-SYS users. For better security of passwords, Oracle recommends that you associate the password verification function with the default profile. About Customizing Password Complexity Verification provides an example of how to accomplish this.

Who Can Use the Password Complexity Functions?

The password complexity functions enable you to customize how users access your data.

Before you can use the password complexity verification functions in the CREATE PROFILE or ALTER PROFILE statement, you must be granted the EXECUTE privilege on them.

The password verification functions are located in the SYS schema.

verify_function_11G Function Password Requirements

The verify_function_11G function originated in Oracle Database Release 11g.

Note:

The verify_function_11G function has been deprecated because it enforces the weaker password restrictions from earlier releases of Oracle Database. Instead, you should use the ORA12C_VERIFY_FUNCTION, ORA12C_STRONG_VERIFY_FUNCTION, ORA12C_STIG_VERIFY_FUNCTION functions, which enforce stronger, more up-to-date password verification restrictions.

This function checks for the following requirements when users create or modify passwords:

  • The password contains no fewer than 8 characters and includes at least one numeric and one alphabetic character.

  • The password is not the same as the user name, nor is it the user name reversed or with the numbers 1–100 appended.

  • The password is not the same as the server name or the server name with the numbers 1–100 appended.

  • The password does not contain oracle (for example, oracle with the numbers 1–100 appended).

  • The password is not too simple (for example, welcome1, database1, account1, user1234, password1, oracle123, computer1, abcdefg1, or change_on_install).

  • The password differs from the previous password by at least 3 characters.

The following internal check is also applied:

  • The password does not contain the double-quotation character ("). However, it can be surrounded by double-quotation marks.

ora12c_verify_function Password Requirements

The ora12c_verify_function function fulfills the Department of Defense Database Security Technical Implementation Guide requirements.

This function checks for the following requirements when users create or modify passwords:

  • The password contains no fewer than 8 characters and includes at least one numeric and one alphabetic character.

  • The password is not the same as the user name or the user name reversed.

  • The password is not the same as the database name.

  • The password does not contain the word oracle (such as oracle123).

  • The password differs from the previous password by at least 8 characters.

  • The password contains at least 1 special character.

The following internal check is also applied:

  • The password does not contain the double-quotation character ("). However, it can be surrounded by double-quotation marks.

ora12c_strong_verify_function Function Password Requirements

The ora12c_strong_verify_function function fulfills the Department of Defense Database Security Technical Implementation Guide requirements.

This function checks for the following requirements when users create or modify passwords:

  • The password must contain at least 2 upper case characters, 2 lower case characters, 2 numeric characters, and 2 special characters. These special characters are as follows:

    ‘ ~ ! @ # $ % ^ & * ( ) _ - + = { } [ ] \ / < > , . ; ? ' : | (space)
  • The password must differ from the previous password by at least 4 characters.

The following internal check is also applied:

  • The password does not contain the double-quotation character ("). It can be surrounded by double-quotation marks, however.

ora12c_stig_verify_function Password Requirements

The ora12c_stig_verify_function function fulfills the Security Technical Implementation Guides (STIG) requirements.

This function checks for the following requirements when users create or modify passwords:

  • The password has at least 15 characters.

  • The password has at least 1 lower case character and at least 1 upper case character.

  • The password has at least 1 digit.

  • The password has at least 1 special character.

  • The password differs from the previous password by at least 8 characters.

The following internal check is also applied:

  • The password does not contain the double-quotation character ("). However, it can be surrounded by double-quotation marks.

The ora12c_stig_verify_function function is the default handler for the ORA_STIG_PROFILE profile, which is available in a newly-created or upgraded Oracle database.

About Customizing Password Complexity Verification

Oracle Database enables you to customize password complexity for your site.

You can create your own password complexity verification function in the SYS schema, similar to the functions that are defined in admin/catpvf.sql. In fact, Oracle recommends that you do so to further secure your site’s passwords.

Note the following:

  • Do not include Data Definition Language (DDL) statements in the custom password complexity verification function. DDLs are not allowed during the execution of password complexity verification functions.

  • Do not modify the admin/catpvf.sql script or the Oracle-supplied password complexity functions. You can create your own functions based on the contents of these files.

  • If you make no modifications to the utlpwdmg.sql script, then it uses the ora12c_verify_function function as the default function.

See Also:

Guideline 1 in Guidelines for Securing Passwords for general advice on creating passwords
Enabling Password Complexity Verification

The catpvf.sql script can be customized to enable password complexity verification.

To enable password complexity verification, you must edit the catpvf.sql script to use the password verification function that you want, and then run the script to enable it.
  1. Log in to SQL*Plus with administrative privileges.

    For example:

    CONNECT SYSTEM
    Enter password: password

  2. Run the catpvf.sql script (or your modified version of this script) to create the password complexity functions in the SYS schema.
    @$ORACLE_HOME/rdbms/admin/catpvf.sql

  3. Grant any users who must use this function the EXECUTE privilege on it.

    For example:

    GRANT pmsith EXECUTE ON ora12c_strong_verify_function;

  4. In the default profile or the user profile, set the PASSWORD_VERIFY_FUNCTION setting to either the sample password complexity function in the catpvf.sql script, or to your customized function. Use one of the following methods:
    • Log in to SQL*Plus with administrator privileges and use the CREATE PROFILE or ALTER PROFILE statement to enable the function. Ensure that you have the EXECUTE privilege on the function.

      For example, to update the default profile to use the ora12c_strong_verify_function function:

      ALTER PROFILE default LIMIT
       PASSWORD_VERIFY_FUNCTION ora12c_strong_verify_function;

    • In Oracle Enterprise Manager Cloud Control, from the Administration menu, select Security, and then Profiles. Select the Password tab. Under Complexity, from the Complexity function list, select the name of the complexity function that you want. Click Apply.

After you have enabled password complexity verification, it takes effect immediately. If you must disable it, then run the following statement:

ALTER PROFILE DEFAULT LIMIT PASSWORD_VERIFY_FUNCTION NULL;

Note:

The ALTER USER statement has a REPLACE clause. With this clause, users can change their own unexpired passwords by supplying the previous password to authenticate themselves.

If the password has expired, then the user cannot log in to SQL to issue the ALTER USER command. Instead, the OCIPasswordChange() function must be used, which also requires the previous password.

A database administrator with ALTER ANY USER privilege can change any user password (force a new password) without supplying the old one.

Managing Password Case Sensitivity

You can manage the password case sensitivity for passwords from user accounts from previous releases.

SEC_CASE_SENSITIVE_LOGON Parameter and Password Case Sensitivity

The SEC_CASE_SENSITIVE_LOGON initialization parameter controls the use of case sensitivity in passwords.

Only users who have the ALTER SYSTEM privilege can set the SEC_CASE_SENSITIVE_LOGON parameter. You should ensure that this parameter is set to TRUE so that case sensitivity is enforced when a user enters a password. However, you should be aware that the SEC_CASE_SENSITIVE_LOGON parameter is deprecated, but is currently retained for backward compatibility.

When you create or modify user accounts, by default, passwords are case sensitive. Case sensitivity affects not only passwords that users enter manually, but it affects password files as well.

Ensure that the SEC_CASE_SENSITIVE_LOGON parameter is not set to FALSE if the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter is set to 12 or 12a. This is because the more secure password versions used for this mode only support case-sensitive password checking. For compatibility reasons, Oracle Database does not prevent the use of FALSE for SEC_CASE_SENSITIVE_LOGON when SQLNET.ALLOWED_LOGON_VERSION_SERVER is set to 12 or 12a. Setting SEC_CASE_SENSITIVE_LOGON to FALSE when SQLNET.ALLOWED_LOGON_VERSION_SERVER is set to 12 or 12a causes all accounts to become inaccessible. If SQLNET.ALLOWED_LOGON_VERSION_SERVER is set to 11 or a lower value, then Oracle recommends that you set SEC_CASE_SENSITIVE_LOGON to TRUE, because the more secure password versions used in Exclusive Mode (when SQLNET.ALLOWED_LOGON_VERSION_SERVER is 12 or 12a) in Oracle Database 12c do not support case insensitive password matching.

In addition to the server-side settings, you should ensure that the client software with which the users are connecting has the O5L_NP capability flag. All Oracle Database release 11.2.0.3 and later clients have the O5L_NP capability. If you have an earlier client, then you must install the CPUOct2012 patch.

Using the ALTER SYSTEM Statement to Enable Password Case Sensitivity

If password case sensitivity has been disabled, then you can enable it by setting the SEC_CASE_SENSITIVE_LOGON parameter to TRUE.

  1. If you are using a password file, then ensure that it was created with the ORAPWD utility IGNORECASE parameter set to N and the FORMAT parameter set to 12.

    The IGNORECASE parameter overrides the SEC_CASE_SENSITIVE_LOGON parameter. By default, IGNORECASE is set to N, which means that passwords are treated as case sensitive.

    Note that the IGNORECASE parameter and the SEC_CASE_SENSITIVE_LOGON system parameter are deprecated. Oracle strongly recommends that you set IGNORECASE to N or omit the IGNORECASE setting entirely.

  2. Enter the following ALTER SYSTEM statement:
    ALTER SYSTEM SET SEC_CASE_SENSITIVE_LOGON = TRUE;
Management of Case Sensitivity for Secure Role Passwords

For better security, you should ensure that the passwords for secure roles are case sensitive.

If before upgrading to Oracle Database 12c release 2 (12.2), you created secure roles by using the IDENTIFIED BY clause of the CREATE ROLE statement, and if upon upgrading to Oracle Database 12c release 12.2, you set the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter to one of the Exclusive Modes 12 or 12a, then you must change the password for these secure roles in order for them to remain usable. Because Exclusive Mode is now the default, secure roles that were created in earlier releases (such as Oracle Database 10g, in which the 10G password version was the default) will need to have their passwords changed.

You can query the PASSWORD_REQUIRED and AUTHENTICATION_TYPE columns of the DBA_ROLES data dictionary view to find any secure roles that must have their password changed after upgrade to Oracle Database 12c, in order to become usable again.

Otherwise, the password version for these secure roles cannot be used, unless you set the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter to 8. If this parameter is set to 12 or 12a, then you must run the following SQL statement to ensure that case sensitivity is enabled. If not, then secure roles will remain unusable even after their passwords have been changed.

ALTER SYSTEM SET SEC_CASE_SENSITIVE_LOGON = "TRUE";
Management of Password Versions of Users

By default, Oracle Database uses Exclusive Mode, which does not permit case-insensitive passwords, to manage password versions.

In a default installation, the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter is set to 12 to enable Exclusive Mode. Exclusive Mode requires that the password-based authentication protocol use one of the case-sensitive password versions (11G or 12C) for the account that is being authenticated. Exclusive Mode excludes the use of the 10G password version that was used in earlier releases. After you upgrade to Oracle Database 12c release 2 (12.2), accounts that use the 10G password version become inaccessible. This occurs because the server runs in Exclusive Mode by default, and Exclusive Mode cannot use the old 10G password version to authenticate the client. The server is left with no password version with which to authenticate the client.

The user accounts from Release 10g use the 10G password version. Therefore, you should find the user accounts that use the 10G password version, and then reset the passwords for these accounts. This generates the appropriate password version based on the setting of the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter, as follows:

  • SQLNET.ALLOWED_LOGON_VERSION_SERVER=8 generates all three password versions 10G, 11G, and 12C.

  • SQLNET.ALLOWED_LOGON_VERSION_SERVER=12 generates both 11G and 12C password versions, and removes the 10G password version.

  • SQLNET.ALLOWED_LOGON_VERSION_SERVER=12a generates only the 12C password version.

If you first relax the SQLNET.ALLOWED_LOGON_VERSION_SERVER setting to a more permissive value (such as SQLNET.ALLOWED_LOGON_VERSION_SERVER=8) and then import the user accounts from an Oracle Database release 10g (or earlier) release into the current database release, then because the 10G password version (used in the older release) is not case sensitive, these users will still be able to log into the database using any case for their password. But when such a user changes their password, the new 11G and 12C password versions are generated automatically, and their password will automatically become case sensitive, because the default value for the instance initialization parameter SEC_CASE_SENSITIVE_LOGON is TRUE. (Be aware that SEC_CASE_SENSITIVE_LOGON is deprecated, but is currently retained for backward compatibility.)

The following example demonstrates the effect of setting the SEC_CASE_SENSITIVE_LOGON parameter to TRUE. In this scenario, user rtaylor has been imported from Oracle Database release 10g, and therefore this account only has the 10G password version. On the server, the SQLNET.ALLOWED_LOGON_VERSION_SERVER is set to 8 because otherwise rtaylor would not be able to log in. In addition, the SEC_CASE_SENSITIVE_LOGON parameter is set to TRUE to enable case sensitivity for the 11G and 12C password versions.

  1. Check the password versions for user rtaylor:

    SELECT PASSWORD_VERSIONS FROM DBA_USERS WHERE USERNAME='RTAYLOR';

    PASSWORD VERSIONS
    -----------------
    10G
  2. Connect as user rtaylor.

    CONNECT rtaylor
    Enter password: "MaresEatOats"

    Connected.

    User rtaylor can connect to the database because his password still uses the 10G password version, which is case insensitive. Here, he enters his password in mixed case, though his actual password is all lower case: mareseatoats.

  3. Check the password versions for one of the default users, SCOTT.

    SELECT PASSWORD_VERSIONS FROM DBA_USERS WHERE USERNAME='SCOTT';

    PASSWORD VERSIONS
    -----------------
    11G 12C
  4. Try connecting as user SCOTT using a mixed case for the password, even though his actual password is all lowercase: luv2walkmyk9.

    CONNECT SCOTT
    Enter password: "LuvToWalkMyK9"

    ERROR: ORA-01017: invalid username/password; logon denied
    Warning: You are no longer connected to ORACLE.

    Because user SCOTT’s password versions are 11G and 12G, the password is case sensitive. The password entered in this example is correct, but the case is incorrect.

  5. Alter rtaylor’s password to grumble_mumble2work.

    ALTER USER rtaylor IDENTIFIED BY grumble_mumble2work;

    User altered.
  6. Connect with the SYSDBA administrative privilege.

    CONNECT / AS SYSDBA
  7. Find the password versions for user rtaylor.

    SELECT PASSWORD_VERSIONS FROM DBA_USERS WHERE USERNAME='RTAYLOR';

    PASSWORD VERSIONS
    -----------------
    10G 11G 12C

    The authentication protocol that was configured with the SQLNET.ALLOWED_LOGON_VERSION_SERVER and SEC_CASE_SENSITIVE_LOGON settings will enforce the case sensitivity of rtaylor’s password, now that he has changed this password.

  8. Try connecting as rtaylor using a mixed case for the password.

    CONNECT rtaylor
    Enter password: "Grumble_Mumble2Work"

    ERROR: ORA-01017: invalid username/password; logon denied
    Warning: You are no longer connected to ORACLE.

    The password entered fails because it was not entered using the case in which the password was created.

  9. Try connecting as rtaylor again but with the password using the correct case

    CONNECT rtaylor
    Enter password: "grumble_mumble2work"

    Connected.


    User rtaylor can connect.

The case sensitivity of the rtaylor account is a result of the server's default setting for SEC_CASE_SENSITIVE_LOGON, which is TRUE. If this setting is FALSE, then case-insensitive matching can be restored because the rtaylor account still has the 10G password version. However, Oracle does not recommend this setting. The SEC_CASE_SENSITIVE_LOGON parameter is deprecated for this reason. For greater security, Oracle strongly recommends that you keep case-sensitive password authentication enabled.

Finding and Resetting User Passwords That Use the 10G Password Version

For better security, find and reset passwords for user accounts that use the 10G password version so that they use later, more secure password versions.

Finding All Password Versions of Current Users

You can query the DBA_USERS data dictionary view to find a list of all the password versions configured for user accounts.

For example:

SELECT USERNAME,PASSWORD_VERSIONS FROM DBA_USERS;

USERNAME                       PASSWORD_VERSIONS
------------------------------ -----------------
JONES                          10G 11G 12C
ADAMS                          10G 11G
CLARK                          10G 11G
PRESTON                        11G
BLAKE                          10G

The PASSWORD_VERSIONS column shows the list of password versions that exist for the account. 10G refers to the earlier case-insensitive Oracle password version, 11G refers to the SHA-1-based password version, and 12C refers to the SHA-2-based SHA-512 password version.

  • User jones: The password for this user was reset in Oracle Database 12c Release 12.1 when the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter setting was 8. This enabled all three password versions to be created.

  • Users adams and clark: The passwords for these accounts were originally created in Oracle Database 10g and then reset in Oracle Database 11g. The Oracle Database 11g software was using the default SQLNET.ALLOWED_LOGON_VERSION setting of 8 at that time. Because case insensitivity is enabled by default, their passwords are now case sensitive, as is the password for preston.

  • User preston: This account was imported from an Oracle Database 11g database that was running in Exclusive Mode (SQLNET.ALLOWED_LOGON_VERSION = 12).

  • User blake: This account still uses the Oracle Database 10g password version. At this stage, user blake is prevented from logging in.

Resetting User Passwords That Use the 10G Password Version

For better security, remove the 10G password version from the accounts of all users. In the following procedure, to reset the passwords of users who have the 10G password version, you must temporarily relax the SQLNET.ALLOWED_LOGON_VERSION_SERVER setting, which controls the ability level required of clients before login can be allowed. Relaxing the setting enables these users to log in and change their passwords, and hence generate the newer password versions in addition to the 10G password version. Afterward, you can set the database to use Exclusive Mode and ensure that the clients have the O5L_NP capability. Then the users can reset their passwords again, so that their password versions no longer include 10G, but only have the more secure 11G and 12C password versions.

  1. Query the DBA_USERS view to find users who only use the 10G password version.
    SELECT USERNAME FROM DBA_USERS
    WHERE ( PASSWORD_VERSIONS = '10G '
    OR PASSWORD_VERSIONS = '10G HTTP ')
    AND USERNAME <> 'ANONYMOUS';

  2. Configure the database so that it does not run in Exclusive Mode, as follows:
    1. Edit the SQLNET.ALLOWED_LOGON_VERSION_SERVER setting in the sqlnet.ora file so that it is more permissive than the default. For example:
      SQLNET.ALLOWED_LOGON_VERSION_SERVER=11
    2. Restart the database.
  3. Expire the users that you found when you queried the DBA_USERS view to find users who only use the 10G password version.

    You must expire the users who have only the 10G password version, and do not have one or both of the 11G or 12C password versions.

    For example:

    ALTER USER username PASSWORD EXPIRE;

  4. Ask the users whose passwords you expired to log in.

    When the users log in, they are prompted to change their passwords. The database generates the missing 11G and 12C password versions for their account, in addition to the 10G password version. The 10G password version continues to be present, because the database is running in the permissive mode.

  5. Ensure that the client software with which the users are connecting has the O5L_NP ability.

    All Oracle Database release 11.2.0.3 and later clients have the O5L_NP ability. If you have an earlier Oracle Database client, then you must install the CPUOct2012 patch.

  6. After all clients have the O5L_NP capability, set the security for the server back to Exclusive Mode, as follows:
    1. Remove the SEC_CASE_SENSITIVE_LOGON parameter setting from the instance initialization file, or set SEC_CASE_SENSITIVE_LOGON to TRUE.
      SEC_CASE_SENSITIVE_LOGON = TRUE
    2. Remove the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter from the server sqlnet.ora file, or set the value of SQLNET.ALLOWED_LOGON_VERSION_SERVER in the server sqlnet.ora file back to 12, to set it to an Exclusive Mode.
      SQLNET.ALLOWED_LOGON_VERSION_SERVER = 12
    3. Restart the database.
  7. Find the accounts that still have the 10G password version.
    SELECT USERNAME FROM DBA_USERS
    WHERE PASSWORD_VERSIONS LIKE '%10G%'
    AND USERNAME <> 'ANONYMOUS';
  8. Expire the accounts that still have the 10G password version.
    ALTER USER username PASSWORD EXPIRE;
  9. Ask these users to log in to their accounts.

    When the users log in, they are prompted to reset their passwords. The database then generates only the 11G and 12C password versions for their accounts. Because the database is running in Exclusive Mode, the 10G password version is no longer generated.

  10. Rerun the following query:
    SELECT USERNAME FROM DBA_USERS
    WHERE PASSWORD_VERSIONS LIKE '%10G%'
    AND USERNAME <> 'ANONYMOUS';

    If this query does not return any results, then it means that no user accounts have the 10G password version. Hence, the database is running in a more secure mode than in previous releases.

How Case Sensitivity Affects Password Files

By default, password files are case sensitive. The IGNORECASE argument in the ORAPWD command line utility controls the case sensitivity of password files.

The default value for IGNORECASE is N (no), which enforces case sensitivity. For better security, set IGNORECASE to N or omit the ignorecase argument entirely. Note that IGNORECASE is deprecated.

The following example shows how to enable case sensitivity in password files.

orapwd file=orapw entries=100
Enter password for SYS: password

This command creates a case sensitive password file called orapw. By default, passwords are case sensitive. Afterwards, if you connect using this password, it succeeds—as long as you enter it using the exact case in which it was created. If you enter the same password but with a different case sensitivity, it will fail.

If you imported user accounts from a previous release and these accounts were created with SYSDBA or SYSOPER administrative privilege, then they will be included in the password file. The passwords for these accounts are case insensitive. The next time these users change their passwords, and assuming case sensitivity is enabled, the passwords become case sensitive. For greater security, have these users change their passwords.

How Case Sensitivity Affects Passwords Used in Database Link Connections

When you create a database link connection, you must define a user name and password for the connection.

When you create the database link connection, the password is case sensitive. How a user enters his or her password for connections depends on the release in which the database link was created:

  • Users can connect from a pre-Oracle Database 12c database to a Oracle Database 12c database. Because case sensitivity is enabled, then the user must enter the password using the case that was used when the account was created.

  • If the user connects from a Oracle Database 12c database to a pre-Oracle Database 12c database, and if the SEC_CASE_SENSITIVE_LOGON parameter in the pre-Release 12c database had been set to FALSE, then the password for this database link can be specified using any case.

You can find the user accounts for existing database links by querying the V$DBLINK view. For example:

SELECT DB_LINK, OWNER_ID FROM V$DBLINK;

See Oracle Database Reference for more information about the V$DBLINK view.

Ensuring Against Password Security Threats by Using the 12C Password Version

The 12C password version enables users to create complex passwords that meet compliance standards.

About the 12C Version of the Password Hash

The 12C password hash protects against password-based security threats by including support for mixed case passwords.

The cryptographic hash function used for generating the 12C version of the password hash is based on a de-optimized algorithm involving Password-Based Key Derivation Function 2 (PBKDF2) and the SHA-512 cryptographic hash functions. The PBKDF2 algorithm introduces computational asymmetry in the challenge that faces an intruder who is trying to recover the original password when in possession of the 12C version of the password hash. The 12C password generation performs a SHA-512 hash of the PBKDF2 output as its last step. This two-step approach used in the 12C password version generation allows server CPU resources to be conserved when the client has the O7L_MR capability. This is because during the password verification phase of the O5LOGON authentication, the server only needs to perform a single SHA-512 hash of a value transmitted by the O7L_MR capable client, rather than having to repeat the entire PBKDF2 calculation on the password itself.

In addition, the 12C password version adds a salt to the password when it is hashed, which provides additional protection. The 12C password version enables your users to create far more complex passwords. The 12C password version's use of salt, its use of PBKDF2 de-optimization, and its support for mixed-case passwords makes it more expensive for an intruder to perform dictionary or brute force attacks on the 12C password version in an attempt to recover the user's password. Oracle recommends that you use the 12C version of the password hash.

The password hash values are considered to be extremely sensitive, because they are used as a "shared secret" between the server and person who is logging in. If an intruder learns this secret, then the protection of the authentication is immediately and severely compromised. Remember that administrative users who have account management privileges, administrative users who have the SYSDBA administrative privilege, or even users who have the EXP_FULL_DATABASE role can immediately access the password hash values. Therefore, this type of administrative user must be trustworthy if the integrity of the database password-based authentication is to be preserved. If you cannot trust these administrators, then it is better to deploy a directory server (such as Oracle Database Enterprise User Security) so that the password hash values remain within the Enterprise User Security directory and are never accessible to anyone except the Enterprise User Security administrator.

Oracle Database 12C Password Version Configuration Guidelines

By default, Oracle Database generates two versions of the password hash: 11G and 12C.

The version of the password hash that Oracle Database uses to authenticate a given client depends on the client’s ability, and the settings for the SQLNET.ALLOWED_LOGON_VERSION_CLIENT and SQLNET.ALLOWED_LOGON_VERSION_SERVER parameters. See the column “Ability Required of the Client” in the “SQLNET.ALLOWED_LOGON_VERSION_SERVER Settings” table in the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter description in Oracle Database Net Services Reference for detailed information about how the client authentication works with password versions.

The 10G password version, which was generated in Oracle Database 10g, is not case sensitive. Both the 11G and 12C password versions are case sensitive.

In Oracle Database 12g release 2 (12.2), the sqlnet.ora parameter SQLNET.ALLOWED_LOGON_VERSION_SERVER defaults to 12, which is Exclusive Mode and prevents the use of the 10G password version, and the SQLNET.ALLOWED_LOGON_VERSION_CLIENT parameter defaults to 11. For new accounts, when the client is Oracle Database 12c, then Oracle Database uses the 12C password version exclusively with clients that are running the Oracle Database 12c release software. For accounts that were created before Oracle Database release 12c, logins will succeed as long as the client has the O5L_NP ability, because an 11G password version normally exists for accounts created in earlier releases such as Oracle Database release 11g. For a very old account (for example, from Oracle Database release 10g), the user’s password may need to be reset, in order to create a SHA-1 password version for the account. To configure this server to generate only the 12C password version whenever a new account is created or an existing account password is changed, then set the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter to 12a. However, if you want your applications to be compatible with older clients, then ensure that SQLNET.ALLOWED_LOGON_VERSION_SERVER is set to 12, which is the default.

How you set the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter depends on the balance of security and interoperability with older clients that your system requires. You can control the levels of security as follows:

  • Greatest level of compatibility: To configure the server to generate all three versions of the password hash (the 12C password version, the 11G password version, and the DES-based 10G password version), whenever a new account is created or an existing account password is changed, set the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter to the value 11 or lower. (Be aware that earlier releases used the value 8 as the default.)

  • Recommended level of security: To configure the server to generate both the 12C password version and the 11G password version (but not the 10G password version), whenever a new account is created or an existing account password is changed, set the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter to the value 12.

  • Highest level of security: To configure the server to generate only the 12C password version whenever a new account is created or an existing account password is changed, set the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter to the value 12a.

During authentication, the following scenarios are possible, based on the kinds of password versions that exist for the account, and on the version of the client software being used:

  • Accounts with only the 10G version of the password hash: If you want to force the server to generate the newer versions of the password hash for older accounts, an administrator must expire the password for any account that has only the 10G password version (and none of the more secure password versions, 11G or 12C). You must generate these password versions because the database depends on using these password versions to provide stronger security. You can find these users as follows.

    SELECT USERNAME FROM DBA_USERS
    WHERE PASSWORD_VERSIONS LIKE '%10G%
    AND USERNAME <> 'ANONYMOUS';


    And then expire each account as follows:

    ALTER USER username PASSWORD EXPIRE;


    After you have expired each account, notify these users to log in, in which case they will be prompted to change their password. The version of the client determines the password version that is used. The setting of the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter determines the password versions that are generated. If the client has the O7L_MR ability (Oracle Database release 12c), then the 12C password version is used to authenticate. If the client has the O5L_NP ability but not the O7L_MR ability (such as Oracle Database release 11g clients), then the 11G password version is used to authenticate. You should upgrade all clients to Oracle Database release 12c so that the 12C password version can be used exclusively to authenticate. (By default, Oracle Database release 11.2.0.3 and later clients have the O5L_NP ability, which enables the 11G password version to be used exclusively. If you have an earlier Oracle Database client, then you must install the CPUOct2012 patch.)

    When an account password is expired and the ALLOWED_LOGON_VERSION_SERVER parameter is set to 12 or 12a, then the 10G password version is removed and only one or both of the new password versions are created, depending on how the parameter is set, as follows:

    • If ALLOWED_LOGON_VERSION_SERVER is set to 12 (the default), then both the 11G and 12C versions of the password hash are generated.

    • If ALLOWED_LOGON_VERSION_SERVER is set to 12a, then only the 12C version of the password hash is generated.

    For more details, see the "Generated Password Version" column in the table in the "Usage Notes" section for the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter in Oracle Database Net Services Reference.

  • Accounts with both 10G and 11G versions of the password hash: For users who are using a Release 10g or later client, the user logins will succeed because the 11G version of the password hash is used. However, to use the latest version, expire these passwords, as described in the previous bulleted item for accounts.

  • Accounts with only the 11G version of the password hash: The authentication uses the 11G version of the password hash. To use the latest version, expire the passwords, as described in the first bulleted item.

The Oracle Database 12c default configuration for SQLNET.ALLOWED_LOGON_VERSION_SERVER is 12, which means that it is compatible with Oracle Database 12c release 2 (12.2) authentication protocols and later products that use OCI-based drivers, including SQL*Plus, ODBC, Oracle .NET, Oracle Forms, and various third-party Oracle Database adapters. It is also compatible with JDBC type-4 (thin) versions that have had the CPUOct2012 bundle patch applied or starting with Oracle Database 11g, and Oracle Database Client interface (OCI)-based drivers starting in Oracle Database 10g release 10.2. Be aware that earlier releases of the OCI client drivers cannot authenticate to an Oracle database using password-based authentication.

Configuring Oracle Database to Use the 12C Password Version Exclusively

You should set the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter to 12a so that only the 12C password hash version is used.

The 12C password version is the most restrictive and secure of the password hash versions, and for this reason, Oracle recommends that you use only this password version. By default, SQLNET.ALLOWED_LOGON_VERSION_SERVER is set to 12, which enables both the 11G and 12C password versions to be used. (Both the SQLNET.ALLOWED_LOGON_VERSION_SERVER values 12 and 12a are considered Exclusive Mode, which prevents the use of the earlier 10G password version.) If you have upgraded from a previous release, or if SQLNET.ALLOWED_LOGON_VERSION_SERVER is set to 12 or another setting that was used in previous releases, then you should reconfigure this parameter, because intruders will attempt to downgrade the authentication to use weaker password versions. Table 3-3 shows the effect of the SQLNET.ALLOWED_LOGON_VERSION_SERVER setting on password version generation.

Be aware that you can use the 12C password version exclusively only if you use Oracle Database 12c release 12.1.0.2 or later clients. Before you change the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter to 12a, check the versions of the database clients that are connected to the server.

  1. Log in to SQL*Plus as an administrative user who has the ALTER USER system privilege.

  2. Perform the following SQL query to find the password versions of your users.

    SELECT USERNAME,PASSWORD_VERSIONS FROM DBA_USERS;

  3. Expire the account of each user who does not have the 12C password version.

    For example, assuming user blake is still using a 10G password version:

    ALTER USER blake PASSWORD EXPIRE;


    The next time that these users log in, they will be forced to change their passwords, which enables the server to generate the password versions required for Exclusive Mode.

  4. Remind users to log in within a reasonable period of time (such as 30 days).

    When they log in, they will be prompted to change their password, ensuring that the password versions required for authentication in Exclusive Mode are generated by the server. (For more information about how Exclusive Mode works, see the usage notes for the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter in Oracle Database Net Services Reference.)

  5. Manually change the passwords for accounts that are used in test scripts or batch jobs so that they exactly match the passwords used by these test scripts or batch jobs, including the password's case.

  6. Enable the Exclusive Mode configuration as follows:

    1. Create a back up copy of the sqlnet.ora parameter file.

      By default, this file is located in the $ORACLE_HOME/network/admin directory on UNIX operating systems and the %ORACLE_HOME%\network\admin directory on Microsoft Windows operating systems.

      Be aware that in a Multitenant environment, the settings in the sqlnet.ora file apply to all PDBs.

    2. Set the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter, using Table 3-3 for guidance.

    3. Save the sqlnet.ora file.

Table 3-3 shows the effect of the SQLNET.ALLOWED_LOGON_VERSION_SERVER setting on password version generation.

Table 3-3 Effect of SQLNET.ALLOWED_LOGON_VERSION_SERVER on Password Version Generation

SQLNET.ALLOWED_LOGON_VERSION_SERVER Setting 8 11 12 12a

Server runs in Exclusive Mode?

No

No

Yes

Yes

Generate the 10G password version?

Yes

Yes

No

No

Generate the 11G password version?

Yes

Yes

Yes

No

Generate the 12C password version?

Yes

Yes

Yes

Yes

If you only use Oracle Database 12c release 12.1.0.2 or later clients, then set SQLNET.ALLOWED_LOGON_VERSION_SERVER to 12a.

The higher the setting, the more restrictive the use of password versions, as follows:

  • A setting of 12a, the most restrictive and secure setting, only permits the 12C password version.

  • A setting of 12 permits both the 11G and 12C password versions to be used for authentication.

  • A setting of 8 permits the most password versions: 10G, 11G, and 12C.

For detailed information about the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter, see Oracle Database Net Services Reference.

Note:

If your system hosts a fixed database link to a target database that runs an earlier release, then you can set the SQLNET.ALLOWED_LOGON_VERSION_CLIENT parameter, as described in How Server and Client Logon Versions Affect Database Links.
How Server and Client Logon Versions Affect Database Links

The SQLNET.ALLOWED_LOGON_VERSION_SERVER and SQLNET.ALLOWED_LOGON_VERSION_CLIENT parameters can accommodate connections between databases and clients of different releases.

The following diagram illustrates how connections between databases and clients of different releases work. The SQLNET.ALLOWED_LOGON_VERSION_CLIENT parameter affects the "client allowed logon version" aspect of a server that hosts the database link H. This setting enables H to connect through database links to older servers, such as those running Oracle 9i (T), yet still refuse connections from older unpatched clients (U). When this happens, the Oracle Net Services protocol negotiation fails, which raises an ORA-28040: No matching authentication protocol error message in this client, which is attempting to authenticate using the Oracle 9I software. The Oracle Net Services protocol negotiation for Oracle Database 10g release 10.2 client E succeeds because this release incorporates the critical patch update CPUOct2012. The Oracle Net Services protocol negotiation for Release 11.2.0.3 client C succeeds because it uses a secure password version.

This scenario uses the following settings for the system that hosts the database link H:

SQLNET.ALLOWED_LOGON_VERSION_CLIENT=8
SQLNET.ALLOWED_LOGON_VERSION_SERVER=12

Note that the remote Oracle Database T has the following setting:

SQLNET.ALLOWED_LOGON_VERSION=8

If the release of the remote Oracle Database T does not meet or exceed the value defined by the SQLNET.ALLOWED_LOGON_VERSION_CLIENT parameter set for the host H, then queries over the fixed database link would fail during authentication of the database link user, resulting in an ORA-28040: No matching authentication protocol error when an end-user attempts to access a table over the database link.

Note:

If you are using an older Oracle Database client (such as Oracle Database 11g release 11.1.0.7), then Oracle strongly recommends that you upgrade to use the critical patch update CPUOct2012.

See Also:

Configuring Oracle Database Clients to Use the 12C Password Version Exclusively

An intruder may try to provision a fake server to downgrade authentication and trick the client into using a weaker password hash version.

  • To prevent the use of the 10G password version, or both the 10G and 11G password versions, after you configure the server, configure the clients to run in Exclusive Mode, as follows:

    • To use the client Exclusive Mode setting to permit both the 11G and 12C password versions:

      SQLNET.ALLOWED_LOGON_VERSION_CLIENT = 12

    • To use the more restrictive client Exclusive Mode setting to permit only the 12C password version (this setting permits the client to connect only to Oracle Database 12c release 1 (12.1.0.2) and later servers):

      SQLNET.ALLOWED_LOGON_VERSION_CLIENT = 12a


If the server and the client are both installed on the same computer, then ensure that the TNS_ADMIN environment variable for each points to the correct directory for its respective Oracle Net Services configuration files. If the variable is the same for both, then the server could use the client's SQLNET.ALLOWED_LOGON_VERSION_CLIENT setting instead.

If you are using older Oracle Database clients (such as Oracle Database 11g release 11.1.0.7), then you should apply CPU Oct2012 or later to these clients. This patch provides the O5L_NP ability. Unless you apply this patch, users will be unable to log in.

See Also:

Managing the Secure External Password Store for Password Credentials

The secure external password store is a client-side wallet that is used to store password credentials.

About the Secure External Password Store

You can store password credentials database connections by using a client-side Oracle wallet.

An Oracle wallet is a secure software container that stores authentication and signing credentials. This wallet usage can simplify large-scale deployments that rely on password credentials for connecting to databases. When this feature is configured, application code, scripts no longer need embedded user names and passwords. This reduces risk because the passwords are no longer exposed, and password management policies are more easily enforced without changing application code whenever user names or passwords change.

Note:

The external password store of the wallet is separate from the area where public key infrastructure (PKI) credentials are stored. Consequently, you cannot use Oracle Wallet Manager to manage credentials in the external password store of the wallet. Instead, use the command-line utility mkstore to manage these credentials.

How Does the External Password Store Work?

Users (and applications, batch jobs, and scripts) connect to databases by using a standard CONNECT statement that specifies a database connection string.

This string can include a user name and password, and an Oracle Net service name identifying the database on an Oracle Database network. If the password is omitted, the connection prompts the user for the password.

For example, the service name could be the URL that identifies that database, or a TNS alias you entered in the tnsnames.ora file in the database. Another possibility is a host:port:sid string.

The following examples are standard CONNECT statements that could be used for a client that is not configured to use the external password store:

CONNECT salesapp@sales_db.us.example.com
Enter password: password

CONNECT salesapp@orasales
Enter password: password

CONNECT salesapp@ourhost37:1527:DB17
Enter password: password

In these examples, salesapp is the user name, with the unique connection string for the database shown as specified in three different ways. You could use its URL sales_db.us.example.com, or its TNS alias orasales from the tnsnames.ora file, or its host:port:sid string.

However, when clients are configured to use the secure external password store, applications can connect to a database with the following CONNECT statement syntax, without specifying database login credentials:

CONNECT /@db_connect_string

CONNECT /@db_connect_string AS SYSDBA

CONNECT /@db_connect_string AS SYSOPER

In this specification, db_connect_string is a valid connection string to access the intended database, such as the service name, URL, or alias as shown in the earlier examples. Each user account must have its own unique connection string; you cannot create one connection string for multiple users.

In this case, the database credentials, user name and password, are securely stored in an Oracle wallet created for this purpose. The autologin feature of this wallet is turned on, so the system does not need a password to open the wallet. From the wallet, it gets the credentials to access the database for the user they represent.

About Configuring Clients to Use the External Password Store

If your client is configured to use external authentication, such as Windows native authentication or SSL, then Oracle Database uses that authentication method.

The same credentials used for this type of authentication are typically also used to log in to the database. For clients not using such authentication methods or wanting to override them for database authentication, you can set the SQLNET.WALLET_OVERRIDE parameter in sqlnet.ora to TRUE. The default value for SQLNET.WALLET_OVERRIDE is FALSE, allowing standard use of authentication credentials as before.

Configuring a Client to Use the External Password Store

You can configure a client to use the secure external password store feature by using the mkstore command-line utility.

  1. Create a wallet on the client by using the following syntax at the command line:
    mkstore -wrl wallet_location -create


    For example:

    mkstore -wrl c:\oracle\product\12.2.0\db_1\wallets -create
    Enter password: password


    wallet_location is the path to the directory where you want to create and store the wallet. This command creates an Oracle wallet with the autologin feature enabled at the location you specify. The autologin feature enables the client to access the wallet contents without supplying a password. See Oracle Database Enterprise User Security Administrator's Guide for information about autologin wallets.

    The mkstore utility -create option uses password complexity verification. See About Password Complexity Verification for more information.

  2. Create database connection credentials in the wallet by using the following syntax at the command line:
    mkstore -wrl wallet_location -createCredential db_connect_string username
    Enter password: password


    For example:

    mkstore -wrl c:\oracle\product\12.2.0\db_1\wallets -createCredential orcl system
    Enter password: password


    In this specification:

    • wallet_location is the path to the directory where you created the wallet in Step 1.

    • db_connect_string is the TNS alias you use to specify the database in the tnsnames.ora file or any service name you use to identify the database on an Oracle network. By default, tnsnames.ora is located in the $ORACLE_HOME/network/admin directory on UNIX systems and in ORACLE_HOME\network\admin on Windows.

    • username is the database login credential. When prompted, enter the password for this user.

    Repeat this step for each database you want accessible using the CONNECT /@db_connect_string syntax. The db_connect_string used in the CONNECT /@db_connect_string statement must be identical to the db_connect_string specified in the -createCredential command.

  3. In the client sqlnet.ora file, enter the WALLET_LOCATION parameter and set it to the directory location of the wallet you created in Step 1.

    For example, if you created the wallet in $ORACLE_HOME/network/admin and your Oracle home is set to /private/ora11, then you need to enter the following into your client sqlnet.ora file:

    WALLET_LOCATION =
      (SOURCE =
        (METHOD = FILE)
        (METHOD_DATA =
      (DIRECTORY = /private/ora11/network/admin)
      )
     )

  4. In the client sqlnet.ora file, enter the SQLNET.WALLET_OVERRIDE parameter and set it to TRUE as follows:
    SQLNET.WALLET_OVERRIDE = TRUE


    This setting causes all CONNECT /@db_connect_string statements to use the information in the wallet at the specified location to authenticate to databases.

    When external authentication is in use, an authenticated user with such a wallet can use the CONNECT /@db_connect_string syntax to access the previously specified databases without providing a user name and password. However, if a user fails that external authentication, then these connect statements also fail.

    Note:

    If an application uses SSL for encryption, then the sqlnet.ora parameter, SQLNET.AUTHENTICATION_SERVICES, specifies SSL and an SSL wallet is created. If this application wants to use secret store credentials to authenticate to databases (instead of the SSL certificate), then those credentials must be stored in the SSL wallet. After SSL authentication, if SQLNET.WALLET_OVERRIDE = TRUE, then the user names and passwords from the wallet are used to authenticate to databases. If SQLNET.WALLET_OVERRIDE = FALSE, then the SSL certificate is used.

Example: Sample SQLNET.ORA File with Wallet Parameters Set

You can set special parameters in the sqlnet.ora file to control how wallets are managed.

Example 3-2 shows a sample sqlnet.ora file with the WALLET_LOCATION and the SQLNET.WALLET_OVERRIDE parameters set as described in Steps 3 and 4 of Configuring a Client to Use the External Password Store.

Example 3-2 Sample SQLNET.ORA File with Wallet Parameters Set

WALLET_LOCATION =
   (SOURCE =
     (METHOD = FILE)
     (METHOD_DATA =
       (DIRECTORY = /private/ora11/network/admin)
     )
    )

SQLNET.WALLET_OVERRIDE = TRUE
SSL_CLIENT_AUTHENTICATION = FALSE
SSL_VERSION = 0
Managing External Password Store Credentials

The mkstore command-line utility manages credentials from an external password store.

Listing External Password Store Contents

You can view the contents, including specific credentials, of a client wallet external password store.

Listing the external password store contents provides information you can use to decide whether to add or delete credentials from the store.

  • To list the contents of the external password store, enter the following command at the command line:

    mkstore -wrl wallet_location -listCredential


For example:

mkstore -wrl c:\oracle\product\19.1.0\db_1\wallets -listCredential

wallet_location specifies the path to the directory where the wallet, whose external password store contents you want to view, is located. This command lists all of the credential database service names (aliases) and the corresponding user name (schema) for that database. Passwords are not listed.

Adding Credentials to an External Password Store

You can store multiple credentials in one client wallet.

For example, if a client batch job connects to hr_database and a script connects to sales_database, then you can store the login credentials in the same client wallet. You cannot, however, store multiple credentials (for logging in to multiple schemas) for the same database in the same wallet. If you have multiple login credentials for the same database, then they must be stored in separate wallets.

  • To add database login credentials to an existing client wallet, enter the following command at the command line:

    mkstore -wrl wallet_location -createCredential db_alias username


For example:

mkstore -wrl c:\oracle\product\19.1.0\db_1\wallets -createCredential orcl system
Enter password: password

In this specification:

  • wallet_location is the path to the directory where the client wallet to which you want to add credentials is stored.

  • db_alias can be the TNS alias you use to specify the database in the tnsnames.ora file or any service name you use to identify the database on an Oracle network.

  • username is the database login credential for the schema to which your application connects. When prompted, enter the password for this user.

Modifying Credentials in an External Password Store

You can modify the database login credentials that are stored in the wallet if the database connection strings change.

  • To modify database login credentials in a wallet, enter the following command at the command line:

    mkstore -wrl wallet_location -modifyCredential db_alias username


For example:

mkstore -wrl c:\oracle\product\19.1.0\db_1\wallets -modifyCredential sales_db
Enter password: password

In this specification:

  • wallet_location is the path to the directory where the wallet is located.

  • db_alias is a new or different alias you want to use to identify the database. It can be a TNS alias you use to specify the database in the tnsnames.ora file or any service name you use to identify the database on an Oracle network.

  • username is the new or different database login credential. When prompted, enter the password for this user.

Deleting Credentials from an External Password Store

You can delete login credentials for a database from a wallet if the database no longer exists or to disable connections to a specific database.

  • To delete database login credentials from a wallet, enter the following command at the command line:

    mkstore -wrl wallet_location -deleteCredential db_alias


For example:

mkstore -wrl c:\oracle\product\19.1.0\db_1\wallets -deleteCredential orcl

In this specification:

  • wallet_location is the path to the directory where the wallet is located.

  • db_alias is the TNS alias you use to specify the database in the tnsnames.ora file, or any service name you use to identify the database on an Oracle Database network.

Managing Passwords for Administrative Users

The passwords of administrative users have special protections, such as password files and password complexity functions.

About Managing Passwords for Administrative Users

The passwords of administrative users are stored outside of the database so that the users can be authenticated even when the database is not open.

There is no special protection with the password file. The password verifiers must be stored outside of the database so that authentication can be performed even when the database is not open. In previous releases, password complexity functions were available for non-administrative users only. Starting with Oracle Database release 12c (12.2), password complexity functions can be used for both non-administrative users and administrative users.

Setting the LOCK and EXPIRED Status of Administrative Users

Administrative users whose accounts have been locked cannot connect to the database.

  • To unlock locked or expired administrative accounts, use the ALTER USER statement.

For example:

ALTER USER hr_admin ACCOUNT UNLOCK;

If the administrative user’s password has expired, then the next time the user attempts to log in, the user will be prompted to create a new password.

Password Profile Settings for Administrative Users

There are several user profile password settings that are enforced for administrative users.

These password profile parameters are as follows:

  • FAILED_LOGIN_ATTEMPT

  • INACTIVE_ACCOUNT_TIME

  • PASSWORD_LOCK_TIME

  • PASSWORD_LIFE_TIME

  • PASSWORD_GRACE_TIME

Last Successful Login Time for Administrative Users

The last successful login time of administrative user connections that use password file-based authentication is captured.

To find this login time, query the LAST_LOGIN column of the V$PWFILE_USERS dynamic performance view.

Management of the Password File of Administrative Users

Setting the ORAPWD utility FORMAT parameter to 12.2 enables you to manage the password profile parameters for administrative users.

The password file is particularly important for administrative users because it stores the administrative user’s credentials in an external file, not in the database itself. This enables the administrative user to log in to a database that is not open and perform tasks such as querying the data dictionary views. To create the password file, you must use the ORAPWD utility.

The FORMAT parameter setting of 12.2, which is the default setting, enables the password file to accommodate the password profile information for the administrative user.

For example:

orapwd file=orapworcl input_file=orapwold format=12.2
...

Setting FORMAT to 12.2 enforces the following rules:

  • The password contains no fewer than 8 characters and includes at least one numeric and one alphabetic character.

  • The password is not the same as the user name or the user name reversed.

  • The password is not the same as the database name.

  • The password does not contain the word oracle (such as oracle123).

  • The password differs from the previous password by at least 8 characters.

  • The password contains at least 1 special character.

FORMAT=12.2 also applies the following internal checks:

  • The password does not exceed 30 characters.

  • The password does not contain the double-quotation character ("). However, it can be surrounded by double-quotation marks.

The following user profile password settings are enforced for administrative users:

  • FAILED_LOGIN_ATTEMPT

  • INACTIVE_ACCOUNT_TIME

  • PASSWORD_GRACE_TIME

  • PASSWORD_LIFE_TIME

  • PASSWORD_LOCK_TIME

You can find the administrative users who have been included in the password file and their administrative privileges by querying the V$PWFILE_USERS dynamic view.

Migration of the Password File of Administrative Users

The ORAPWD utility input_file parameter or DBUA can be used to migrate from earlier password file formats to the 12.2 format.

You can migrate from earlier password file formats to the 12.2 format by using either the ORAPWD utility file and input_file parameters, or by using Oracle Database Upgrade Assistant (DBUA).

  • The ORAPWD FILE and INPUT_FILE parameters: To migrate using the ORAPWD utility, set the FILE parameter to a name for the new password file and the INPUT_FILE parameter to the name of the earlier password file.

    For example:

    orapwd file=orapworcl input_file=orapwold format=12.2

  • DBUA: To migrate from the earlier formats of password files (FORMAT = LEGACY and FORMAT = 12), you can use the DBUA when you upgrade an earlier database to the current release. However, ensure that the database is open in read-only mode. You can check the database read-only status by querying the OPEN_MODE column of the V$DATABASE dynamic view.

See also:

How the Multitenant Option Affects Password Files for Administrative Users

In a multitenant environment, the password information for the local and common administrative users is stored in different locations.

  • For CDB administrative users: The password information (hashes of the password) for the CDB common administrative users to whom administrative privileges were granted in the CDB root is stored in the password file.

  • For all users in a CDB to whom administrative privileges were granted outside the CDB root: To view information about the password hash information of these users, query the $PWFILE_USERS dynamic view.

Password Complexity Verification Functions for Administrative Users

For better security, use password complexity verification functions for the passwords of administrative users.

Note the following:

  • Profiles: You can specify a password complexity verification function for the SYS user by using the PASSWORD_VERIFY_FUNCTION clause of the CREATE PROFILE or ALTER PROFILE statement. Oracle recommends that you use password verification functions to better protect the passwords of administrative users.

  • ORAPWD password files: If you created a password file using the ORAPWD utility, then Oracle Database enforces password complexity checking for the SYS user and for administrative users who have logged in using the SYSDBA, SYSBACKUP, SYSDG, and SYSKM administrative privileges.

    The password checks for the following requirements:

    • The password contains no fewer than 8 characters and includes at least one numeric character, one alphabetic character, and one special character.

    • The password is not the same as the user name or the user name reversed.

    • The password does not contain the word oracle (such as oracle123).

    • The password differs from the previous password by at least three characters.

    The following internal checks are also applied:

    • The password does not exceed 30 characters.

    • The password does not contain the double-quotation character ("). However, it can be surrounded by double-quotation marks.

Authentication of Database Administrators

You can authenticate database administrators by using strong authentication, from the operating system, or from the database using passwords.

About Authentication of Database Administrators

Database administrators perform special administrative operations, such as shutting down or starting databases.

Oracle Database provides methods to secure the authentication of database administrators who have the SYSDBA, SYSOPER, SYSBACKUP, SYSDG, or SYSKM administrative privilege.

Strong Authentication, Centralized Management for Administrators

Strong authentication methods for centrally managed databases include directory authentication, Kerberos authentication, and SSL authentication.

About Strong Authentication for Database Administrators

Strong authentication lets you centrally control SYSDBA and SYSOPER access to multiple databases.

Consider using this type of authentication for database administration for the following situations:

  • You have concerns about password file vulnerability.

  • Your site has very strict security requirements.

  • You want to separate the identity management from your database. By using a directory server such as Oracle Internet Directory (OID), for example, you can maintain, secure, and administer that server separately.

To enable the Oracle Internet Directory server to authorize SYSDBA and SYSOPER connections, use one of the following methods described in this section, depending on your environment.

Configuring Directory Authentication for Administrative Users

Oracle Internet Directory configures directory authentication for administrative users.

  1. Configure the administrative user by using the same procedures you would use to configure a typical user.
  2. In Oracle Internet Directory, grant the SYSDBA or SYSOPER administrative privilege to the user for the database that this user will administer.

    Grant SYSDBA or SYSOPER only to trusted users.

  3. Set the LDAP_DIRECTORY_SYSAUTH initialization parameter to YES:
    ALTER SYSTEM SET LDAP_DIRECTORY_SYSAUTH = YES;


    When set to YES, the LDAP_DIRECTORY_SYSAUTH parameter enables SYSDBA and SYSOPER users to authenticate to the database by using a strong authentication method.

  4. Set the LDAP_DIRECTORY_ACCESS parameter to either PASSWORD or SSL. For example:
    ALTER SYSTEM SET LDAP_DIRECTORY_ACCESS = PASSWORD;


    Ensure that the LDAP_DIRECTORY_ACCESS initialization parameter is not set to NONE. Setting this parameter to PASSWORD or SSL ensures that users can be authenticated using the SYSDBA or SYSOPER administrative privileges through Oracle Internet Directory.

Afterward, this user can log in by including the net service name in the CONNECT statement in SQL*Plus. For example, to log on as SYSDBA if the net service name is orcl:

CONNECT SOMEUSER@ORCL AS SYSDBA
Enter password: password

If the database is configured to use a password file for remote authentication, Oracle Database checks the password file first.

Configuring Kerberos Authentication for Administrative Users

Oracle Internet Directory can be used to configure Kerberos authentication for administrative users.

  1. Configure the administrative user by using the same procedures you would use to configure a typical user.

    See Configuring Kerberos Authentication, for more information.

  2. Configure Oracle Internet Directory for Kerberos authentication.
  3. In Oracle Internet Directory, grant the SYSDBA or SYSOPER administrative privilege to the user for the database that this user will administer.

    Grant SYSDBA or SYSOPER only to trusted users. See Guidelines for Securing User Accounts and Privileges for advice on this topic.

  4. Set the LDAP_DIRECTORY_SYSAUTH initialization parameter to YES:
    ALTER SYSTEM SET LDAP_DIRECTORY_SYSAUTH = YES;


    When set to YES, the LDAP_DIRECTORY_SYSAUTH parameter enables SYSDBA and SYSOPER users to authenticate to the database by using strong authentication methods. See Oracle Database Reference for more information about LDAP_DIRECTORY_SYSAUTH.

  5. Set the LDAP_DIRECTORY_ACCESS parameter to either PASSWORD or SSL. For example:
    ALTER SYSTEM SET LDAP_DIRECTORY_ACCESS = SSL;


    Ensure that the LDAP_DIRECTORY_ACCESS initialization parameter is not set to NONE. Setting this parameter to PASSWORD or SSL ensures that users can be authenticated using SYSDBA or SYSOPER through Oracle Internet Directory. See Oracle Database Reference for more information about LDAP_DIRECTORY_ACCESS.

Afterward, this user can log in by including the net service name in the CONNECT statement in SQL*Plus. For example, to log on as SYSDBA if the net service name is orcl:

CONNECT /@orcl AS SYSDBA
Configuring Secure Sockets Layer Authentication for Administrative Users

Both the client and server side can authenticate administrative users with Secure Sockets Layer (SSL).

  1. Configure the client to use SSL:

    1. Configure the client wallet and user certificate. Update the wallet location in the sqlnet.ora configuration file.

      You can use Wallet Manager to configure the client wallet and user certificate. See Oracle Database Enterprise User Security Administrator's Guide for more information.

    2. Configure the Oracle net service name to include server DNs and use TCP/IP with SSL in tnsnames.ora.

    3. Configure TCP/IP with SSL in listener.ora.

    4. Set the client SSL cipher suites and the required SSL version, and then set SSL as an authentication service in sqlnet.ora.

  2. Configure the server to use SSL:

    1. Enable SSL for your database listener on TCPS and provide a corresponding TNS name. You can use Net Configuration Assistant to configure the TNS name.

    2. Store the database PKI credentials in the database wallet. You can use Wallet Manager do this.

    3. Set the LDAP_DIRECTORY_ACCESS initialization parameter to SSL:

      ALTER SYSTEM SET LDAP_DIRECTORY_ACCESS = SSL;


      See Oracle Database Reference for more information about LDAP_DIRECTORY_ACCESS.

  3. Configure Oracle Internet Directory for SSL user authentications.

    See Oracle Database Enterprise User Security Administrator's Guide for information about configuring enterprise user security SSL authentication.

  4. In Oracle Internet Directory, grant the SYSDBA or SYSOPER privilege to the user for the database that the user will administer.

  5. On the server computer, set the LDAP_DIRECTORY_SYSAUTH initialization parameter to YES.

    ALTER SYSTEM SET LDAP_DIRECTORY_SYSAUTH = YES;


    When set to YES, the LDAP_DIRECTORY_SYSAUTH parameter enables SYSDBA and SYSOPER users to authenticate to the database by using a strong authentication method. See Oracle Database Reference for more information about LDAP_DIRECTORY_SYSAUTH.

Afterward, this user can log in by including the net service name in the CONNECT statement in SQL*Plus. For example, to log on as SYSDBA if the net service name is orcl:

CONNECT /@orcl AS SYSDBA

Authentication of Database Administrators by Using the Operating System

For both Windows and UNIX systems, you use DBA-privileged groups to authenticate for the operating system.

Operating system authentication for a database administrator typically involves establishing a group on the operating system, granting DBA privileges to that group, and then adding the names of persons who should have those privileges to that group. (On UNIX systems, the group is the dba group.)

Note:

In a multitenant environment, you can use operating system authentication for a database administrator only for the CDB root. You cannot use it for for PDBs, the application root, or application PDBs.

On Microsoft Windows systems:

  • Users who connect with the SYSDBA administrative privilege can take advantage of the Windows native authentication. If these users work with Oracle Database using their domain accounts, then you must explicitly grant them local administrative privileges and ORA_DBA membership.

  • Oracle recommends that you run Oracle Database services using a low privileged Microsoft Windows user account rather than a Microsoft Windows built-in account.

See Also:

Your Oracle Database operating system-specific documentation for information about configuring operating system authentication of database administrators

Authentication of Database Administrators by Using Their Passwords

Password files are used to authenticate database administrators.

That is, Oracle Database users who have been granted the SYSDBA, SYSOPER, SYSASM, SYSBACKUP, SYSDG, and SYSKM administrative privileges are first authenticated using database-specific password files.

These privileges enable the following activities:

  • The SYSOPER system privilege lets database administrators perform STARTUP, SHUTDOWN, ALTER DATABASE OPEN/MOUNT, ALTER DATABASE BACKUP, ARCHIVE LOG, and RECOVER operations. SYSOPER also includes the RESTRICTED SESSION privilege.

  • The SYSDBA administrative privilege has all system privileges with ADMIN OPTION, including the SYSOPER administrative privilege, and permits CREATE DATABASE and time-based recovery.

  • A password file containing users who have the SYSDBA, SYSOPER, SYSASM, SYSBACKUP, SYSDG, and SYSKM administrative privileges can be shared between different databases. In addition, this type of password file authentication can be used in a Secure Sockets Layer (SSL) or Kerberos configuration, and for common administrative users in a multitenant environment. You can have a shared password file that contains users in addition to the SYS user. To share a password file among different databases, set the REMOTE_LOGIN_PASSWORDFILE parameter in the init.ora file to SHARED.

    If you set the REMOTE_LOGIN_PASSWORDFILE initialization parameter to EXCLUSIVE or SHARED from NONE, then ensure that the password file is synchronized with the dictionary passwords. See Oracle Database Administrator’s Guide for more information.

  • For Automatic Storage Management (ASM) environments, you can create shared ASM password files. Remember that you must have the SYSASM system privilege to create an ASM password file. See Oracle Automatic Storage Management Administrator's Guide for more information.

  • The SYSDG administrative privilege must be included in a password file for sharding administrators to perform tasks that involve file transfer and Oracle Recovery Manager (RMAN) activities.

  • Password file-based authentication is enabled by default. This means that the database is ready to use a password file for authenticating users that have SYSDBA, SYSOPER, SYSASM, SYSBACKUP, SYSDG, and SYSKM administrative privileges. Password file-based authentication is activated as soon as you create a password file by using the ORAPWD utility.

    Anyone who has EXECUTE privileges and write privileges to the $ORACLE_HOME/dbs directory can run the ORAPWD utility.

  • Password limits such as FAILED_LOGIN_ATTEMPTS and PASSWORD_LIFE_TIME are enforced for administrative logins, if the password file is created in the Oracle Database 12c release 2 (12.2) format.

Note:

  • To find a list of users who are included in the password file, you can query the V$PWFILE_USERS data dictionary view.

  • Connections requested AS SYSDBA or AS SYSOPER must use these phrases. Without them, the connection fails. The Oracle Database parameter O7_DICTIONARY_ACCESSIBILITY can be set to FALSE to limit sensitive data dictionary access only to authorized users. The parameter also enforces the required AS SYSDBA or AS SYSOPER syntax.

Risks of Using Password Files for Database Administrator Authentication

Be aware that using password files may pose security risks.

For this reason, consider using the authentication methods described in Strong Authentication, Centralized Management for Administrators.

Examples of password security risks are as follows:

  • An intruder could steal or attack the password file.

  • Many users do not change the default password.

  • The password could be easily guessed.

  • The password is vulnerable if it can be found in a dictionary.

  • Passwords that are too short, chosen perhaps for ease of typing, are vulnerable if an intruder obtains the cryptographic hash of the password.

Note:

Oracle Database Administrator’s Guide for information about creating and maintaining password files

Database Authentication of Users

Database authentication of users entails using information within the database itself to perform the authentication.

About Database Authentication

Oracle Database can authenticate users attempting to connect to a database by using information stored in that database itself.

To configure Oracle Database to use database authentication, you must create each user with an associated password. User names can use the National Language Support (NLS) character format, but you cannot include double quotation mark characters in the password. The user must provide this user name and password when attempting to establish a connection.

Oracle Database generates a one-way hash of the user's password and stores it for use when verifying the provided login password. In order to support older clients, Oracle Database can be configured to generate the one-way hash of the user's password using a variety of different hashing algorithms. The resulting password hashes are known as password versions, which have the short names 10G, 11G, and 12C. The short names 10G, 11G, and 12C serve as abbreviations for the details of the one-way password hashing algorithms, which are described in more detail in the documentation for the PASSWORD_VERSIONS column of the DBA_USERS view. To find the list of password versions for any given user, query the PASSWORD_VERSIONS column of the DBA_USERS view.

By default, there are currently two versions of the one-way hashing algorithm in use in Oracle Database 12c release 2 (12.2): the salted SHA-1 hashing algorithm, and the salted PKBDF2 SHA-2 SHA-512 hashing algorithm. The salted SHA-1 hashing algorithm generates the hash that is used for the 11G password version. The salted PKBDF2 SHA-2 SHA-512 hashing algorithm generates the hash that is used for the 12C password version. This hash generation takes place for the same password; that is, both algorithms run for the same password. Oracle Database records these password versions in the DBA_USERS data dictionary view. When you query this view, you will see two password versions. For example:

SELECT USERNAME, PASSWORD_VERSIONS FROM DBA_USERS;

USERNAME  PASSWORD_VERSIONS
--------  -----------------
ADAMS     11G, 12C
SYS       11G, 12C
...

To specify which authentication protocol to allow during authentication of a client or of a database server acting as a client, you can explicitly set the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter in the server sqlnet.ora file. (The client version of this parameter is SQLNET.ALLOWED_LOGON_VERSION_CLIENT.) Each connection attempt is tested, and if the client or server does not meet the client ability requirements specified by its partner, authentication fails with an ORA-28040 No matching authentication protocol error in the “Ability Required of the Client” in the “SQLNET.ALLOWED_LOGON_VERSION_SERVER Settings” table under the description of the SQLNET.ALLOWED_LOGON_VERSION_SERVER parameter in Oracle Database Net Services Reference. The parameter can take the values 12a, 12, 11, 10, 9, or 8. The default value is 12, which is Exclusive Mode. These values represent the version of the authentication protocol. Oracle recommends the value 12. However, be aware that if you set SQLNET.ALLOWED_LOGON_VERSION_SERVER and SQLNET.ALLOWED_LOGON_VERSION_CLIENT to 11, then pre-Oracle Database Release 11.1 client applications including JDBC thin clients cannot authenticate to the Oracle database using password-based authentication.

To enhance security when using database authentication, Oracle recommends that you use password management, including account locking, password aging and expiration, password history, and password complexity verification.

See Also:

Advantages of Database Authentication

There are three advantages of using the database to authenticate users.

These advantages are as follows:

  • User accounts and all authentication are controlled by the database. There is no reliance on anything outside of the database.

  • Oracle Database provides strong password management features to enhance security when using database authentication.

  • It is easier to administer when there are small user communities.

Creating Users Who Are Authenticated by the Database

When you create a user who is authenticated by the database, you assign this user a password.

  • To create a user who is authenticated by the database, include the IDENTIFIED BY clause when you create the user.

For example, the following SQL statement creates a user who is identified and authenticated by Oracle Database. User sebastian must specify the assigned password whenever he connects to Oracle Database.

CREATE USER sebastian IDENTIFIED BY password;

Related Topics

Schema-Only Accounts

You can create schema-only accounts, that is, the schema user has no password.

About Schema-Only Accounts

A schema-only account cannot log in to the database but can proxy in a single session proxy.

This type of account, designed for some Oracle-provided schemas along with some user-created schemas, can be created without the specification of a password or an authentication type. It cannot be authenticated unless an authentication method is assigned by using the ALTER USER statement. A schema-only account does not contain an entry in the DBA_USERS_WITH_DEFPWD data dictionary view.

By default, most of the predefined schema user accounts that are available with Oracle Database, such as the sample schema user accounts (for example, HR), are schema-only accounts. You can assign these accounts passwords if you want to, but for better security, Oracle recommends that you set them back to being schema-only afterwards. To check if a schema user account is schema only, query the STATUS column of the DBA_USERS data dictionary view. NONE indicates that the account is schema only.

Note the following rules about using schema only accounts:

  • Schema only accounts can be used for both administrator and non-administrator accounts.

  • Schema only accounts must be created on the database instance only, not in Oracle Automatic Storage Management (ASM) environments.

  • You can grant system privileges (such as CREATE ANY TABLE) and administrator roles (such as DBA) to schema only accounts. Schema only accounts can create objects such as tables or procedures, assuming they have had to correct privileges granted to them.

  • You can configure schema only accounts to be used as client users in a proxy authentication in a single session proxy. This is because in a single session proxy, only the credentials of the proxy user are verified, not the credentials of the client user. Therefore, a schema only account can be a client user. However, you cannot configure schema only accounts for a two-proxy scenario, because the client credentials must be verified. Hence, the authentication for a schema only account will fail.

  • Schema only accounts cannot connect through database links, either with connected user links, fixed user links, or current user links.

Creating a Schema-Only Account

The CREATE USER SQL statement creates schema-only accounts.

You can run the CREATE USER statement with the NO AUTHENTICATION clause only on a database instance. You cannot run it on an Oracle Automatic Storage Management (ASM) instance.
  • Use the CREATE USER statement with the NO AUTHENTICATION clause.
    For example:
    CREATE USER psmith NO AUTHENTICATION;

Altering a Schema-Only Account

The ALTER USER SQL statement can be used to modify schema-only accounts.

  1. Check if the schema user has administrative privileges.
    You can query the V$PWFILE_USERS to find if the schema user has administrative privileges.
  2. If the schema user has administrative privileges, then use the REVOKE statement to revoke these privileges.
  3. Use the ALTER USER SQL statement with the NO AUTHENTICATION clause to modify the schema account to have no authentication.
    For example:
    ALTER USER psmith NO AUTHENTICATION;
You can use ALTER USER to enable authentication for a schema-only account.

Operating System Authentication of Users

Oracle Database can authenticate by using information that is maintained by the operating system.

Using the operating system to authenticate users has both advantages and disadvantages.

This functionality has the following benefits:

  • Once authenticated by the operating system, users can connect to Oracle Database more conveniently, without specifying a user name or password. For example, an operating system-authenticated user can invoke SQL*Plus and omit the user name and password prompts by entering the following command at the command line:

    SQLPLUS /


    Within SQL*Plus, you enter:

    CONNECT /

  • With control over user authentication centralized in the operating system, Oracle Database does not need to store or manage the cryptographic hashes (also called verifiers) of the user passwords, although it still maintains user names in the database.

  • The audit trail captures the operating system user name and the database user name, where the database user name is the value of the OS_AUTHENT_PREFIX instance initialization parameter prefixed to the operating system user name. For example, if OS_AUTHENT_PREFIX is set to OPS$ and the operating system user name is psmith, then the database user name will be OPS$PSMITH.

  • You can authenticate both operating system and non-operating system users in the same system. For example:

    • Authenticate users by the operating system. You create the user account using the IDENTIFIED EXTERNALLY clause of the CREATE USER statement, and then you set the OS_AUTHENT_PREFIX initialization parameter to specify a prefix that Oracle Database uses to authenticate users attempting to connect to the server.

    • Authenticate non-operating system users. These are users who are assigned passwords and authenticated by the database.

    • Authenticate Oracle Database Enterprise User Security users. These user accounts where created using the IDENTIFIED GLOBALLY clause of the CREATE USER statement, and then authenticated by Oracle Internet Directory (OID) currently in the same database.

However, you should be aware of the following drawbacks to using the operating system to authenticate users:

  • A user must have an operating system account on the computer that must be accessed. Not all users have operating system accounts, particularly non-administrative users.

  • If a user has logged in using this method and steps away from the terminal, another user could easily log in because this user does not need any passwords or credentials. This could pose a serious security problem.

  • When an operating system is used to authenticate database users, managing distributed database environments and database links requires special care. Operating system-authenticated database links can pose a security weakness. For this reason, Oracle recommends that you do not use them.

  • In a multitenant environment, you can use operating system authentication for a database administrator only for the CDB root. You cannot use it for PDBs, the application root, or application PDBs.

See Also:

  • Oracle Database Administrator’s Guide for more information about authentication, operating systems, distributed database concepts, and distributed data management

  • Operating system-specific documentation by Oracle Database for more information about authenticating by using your operating system

Network Authentication of Users

You can authenticate users over a network by using Secure Sockets Layer with third-party services.

Authentication with Secure Sockets Layer

The Secure Sockets Layer (SSL) protocol is an application layer protocol.

You can use SSL for user authentication to a database, and it is independent of global user management in Oracle Internet Directory. That is, users can use SSL to authenticate to the database without a directory server in place.

Authentication with Third-Party Services

The third-party services Kerberos, RADIUS, directory-based services, and public key infrastructure can authenticate Oracle Database over a network.

About Authentication Using Third-Party Services

You must use third-party network authentication services if you want to authenticate Oracle Database users over a network.

Prominent examples include Kerberos, PKI (public key infrastructure), the RADIUS (Remote Authentication Dial-In User Service), and directory-based services.

If network authentication services are available to you, then Oracle Database can accept authentication from the network service. If you use a network authentication service, then some special considerations arise for network roles and database links.

Authentication with Kerberos

Kerberos is a trusted third-party authentication system that relies on shared secrets.

Kerberos presumes that the third party is secure, and provides single sign-on capabilities, centralized password storage, database link authentication, and enhanced PC security. It does this through a Kerberos authentication server, or through Cybersafe Active Trust, a commercial Kerberos-based authentication server.

Authentication with RADIUS

Remote Authentication Dial-In User Service (RADIUS) is a standard lightweight protocol used for user authentication, authorization, and accounting.

RADIUS also enables users to use the RSA One-Time Password Specifications (OTPS) to authenticate to the Oracle database.

See Also:

Authentication with Directory-Based Services

Using a central directory can make authentication and its administration efficient.

Directory-based services include the following:

  • Oracle Internet Directory, which uses the Lightweight Directory Access Protocol (LDAP), uses a central repository to store and manage information about users (called enterprise users) whose accounts were created in a distributed environment. Although database users must be created (with passwords) in each database that they need to access, enterprise user information is accessible centrally in the Oracle Internet Directory. You can also integrate this directory with Microsoft Active Directory and SunOne.

  • Oracle Enterprise Security Manager lets you store and retrieve roles from Oracle Internet Directory, which provides centralized privilege management to make administration easier and increase security levels.

Authentication with Public Key Infrastructure

Authentication systems based on public key infrastructure (PKI) issue digital certificates to user clients.

These clients can use these certificates to authenticate directly to servers in the enterprise without directly involving an authentication. Oracle Database provides a PKI for using public keys and certificates, consisting of the following components:

  • Authentication and secure session key management using SSL. See Authentication with Secure Sockets Layer for more information.

  • Trusted certificates. These are used to identify third-party entities that are trusted as signers of user certificates when an identity is being validated. When the user certificate is being validated, the signer is checked by using trust points or a trusted certificate chain of certificate authorities stored in the validating system. If there are several levels of trusted certificates in this chain, then a trusted certificate at a lower level is simply trusted without needing to have all its higher-level certificates reverified.

  • Oracle Wallet Manager. An Oracle wallet is a data structure that contains the private key of a user, a user certificate, and the set of trust points of a user (trusted certificate authorities). See Oracle Database Enterprise User Security Administrator's Guide for information about managing Oracle wallets.

    You can use Oracle Wallet Manager to manage Oracle wallets. This is a standalone Java application used to manage and edit the security credentials in Oracle wallets. It performs the following operations:

    • Generates a public-private key pair and creates a certificate request for submission to a certificate authority, and creates wallets

    • Installs a certificate for the entity

    • Manages X.509 version 3 certificates on Oracle Database clients and servers

    • Configures trusted certificates for the entity

    • Opens a wallet to enable access to PKI-based services

  • X.509 version 3 certificates obtained from (and signed by) a trusted entity, a certificate authority. Because the certificate authority is trusted, these certificates verify that the requesting entity's information is correct and that the public key on the certificate belongs to the identified entity. The certificate is loaded into an Oracle wallet to enable future authentication.

Configuring Operating System Users for a PDB

The DBMS_CREDENTIAL.CREATE_CREDENTIAL procedure configures user accounts to be operating system users for a PDB.

About Configuring Operating System Users for a PDB

Instead the oracle operating system user, you can set a specific user account to be the operating system user for that PDB.

If you do not set a specific user to be the operating system user for the PDB, then by default the PDB uses the oracle operating system user. For the root, you can use the oracle operating system user when you must interact with the operating system.

For better security, Oracle recommends that you set a unique operating system user for each PDB in a multitenant environment. Doing so helps to ensure that operating system interactions are performed as a less powerful user than the oracle operating system user, and helps to protect data that belongs to one PDB from being accessed by users who are connected to other PDBs.

Configuring an Operating System User for a PDB

The DBMS_CREDENTIAL.CREATE_CREDENTIAL procedure can set an operating system user for a PDB.

  1. Log in to the database instance root as a user who has the EXECUTE privilege for the DBMS_CREDENTIAL PL/SQL package and the ALTER SYSTEM system privilege.
    For example:
    sqlplus c##sec_admin
    Enter password: password
  2. Run the DBMS_CREDENTIAL.CREATE_CREDENTIAL procedure to create an Oracle credential for the operating system user.
    For example, to set the credential for a user named os_admin:
    BEGIN
     DBMS_CREDENTIAL.CREATE_CREDENTIAL (
        credential_name => 'PDB1_OS_USER',
        username        => 'os_admin',
        password        => 'password');
    END;
    /

  3. Connect to the PDB for which the operating system user will be used.
    For example:
    CONNECT cc##sec_admin@hrpdb
    Enter password: password


    To find the available PDBs, run the show pdbs command. To check the current PDB, run the show con_name command.

  4. Set the PDB_OS_CREDENTIAL initialization parameter for the user whose credential was set in Step 2.
    For example:
    ALTER SYSTEM SET PDB_OS_CREDENTIAL = PDB1_OS_USER SCOPE = SPFILE;

    The PDB_OS_CREDENTIAL parameter is a static parameter, so you must set it using the SCOPE = SPFILE clause.

  5. Restart the database instance.
    SHUTDOWN IMMEDIATE
    STARTUP

Global User Authentication and Authorization

Global user authentication and authorization enables you to centralize the management of user-related information.

About Configuring Global User Authentication and Authorization

An LDAP-based directory service centralizes the management of user-related information, including authorizations.

This enables users and administrators to be identified in the database as global users, meaning that they are authenticated by SSL and that the management of these users is handled outside of the database by the centralized directory service. Global roles are defined in a database and are known only to that database, but the directory service handles authorizations for global roles.

Note:

You can also have users authenticated by Secure Sockets Layer (SSL), whose authorizations are not managed in a directory, that is, they have local database roles only.

This centralized management enables the creation of enterprise users and enterprise roles. Enterprise users are defined and managed in the directory. They have unique identities across the enterprise and can be assigned enterprise roles that determine their access privileges across multiple databases. An enterprise role consists of one or more global roles, and might be thought of as a container for global roles.

You also can use centrally managed users to authenticate and authorize users through a directory service such as Microsoft Active Directory.

Configuration of Users Who Are Authorized by a Directory Service

You can configure either a global user or multiple enterprise users to be authorized by a directory service.

Creating a Global User Who Has a Private Schema

You can create a user account who has a private schema by providing an identifier (distinguished name, or DN) meaningful to the enterprise directory.

However, be aware that you must create this user in every database that the user must access, plus the directory.
  • To create a global user who has a private schema, use the CREATE USER ... IDENTIFIED GLOBALLY SQL statement.

    You can include standard LDAP Data Interchange Format (LDIF) fields. For example, to create a global user (psmith_gl with a private schema, authenticated by SSL, and authorized by the enterprise directory service:

    CREATE USER psmith_gl IDENTIFIED GLOBALLY AS 'CN=psmith,OU=division1,O=example,C=US';

    In this specification:

    • CN refers to the common name of this user, psmith_gl.

    • OU refers to the user’s organizational unit, division1.

    • O refers to the user’s organization, Example.

    • C refers to the country in which the organization Example is located, the US.

Creating Multiple Enterprise Users Who Share Schemas

Multiple enterprise users can share a single schema in the database.

These users are authorized by the enterprise directory service but do not own individual private schemas in the database. These users are not individually created in the database. They connect to a shared schema in the database.

  1. Create a shared schema in the database using the following example:
    CREATE USER appschema IDENTIFIED GLOBALLY AS '';

  2. In the directory, create multiple enterprise users and a mapping object.

    The mapping object tells the database how you want to map the DNs for the users to the shared schema. You can either create a full distinguished name (DN) mapping (one directory entry for each unique DN), or you can map, for each user, multiple DN components to one schema. For example:

    OU=division1,O=Example,C=US


    See Also:

    Oracle Database Enterprise User Security Administrator's Guide for an explanation of these mappings

Most users do not need their own schemas, and implementing schema-independent users separates users from databases. You create multiple users who share the same schema in a database, and as enterprise users, they can also access shared schemas in other databases.

Advantages of Global Authentication and Global Authorization

There are several advantages of global user authentication and authorization.

  • Provides strong authentication using SSL, Kerberos, or Windows native authentication.

  • Enables centralized management of users and privileges across the enterprise.

  • Is easy to administer: You do not have to create a schema for every user in every database in the enterprise.

  • Facilitates single sign-on: Users need to sign on once to only access multiple databases and services. Further, users using passwords can have a single password to access multiple databases accepting password-authenticated enterprise users.

  • Because global user authentication and authorization provide password-based access, you can migrate previously defined password-authenticated database users to the directory (using the User Migration Utility) to be centrally administered. This makes global authentication and authorization available for earlier Oracle Database release clients that are still supported.

  • CURRENT_USER database links connect as a global user. A local user can connect as a global user in the context of a stored procedure, that is, without storing the global user password in a link definition.

Configuring an External Service to Authenticate Users and Passwords

An external service (the operating system or the network) can administer passwords and authenticate users.

About External Authentication

With external authentication, Oracle Database maintains the user account, but an external service performs the password administration and user authentication.

This external service can be the operating system or a network service, such as Oracle Net. If you are authenticating users through a password file, then you can configure external authentication for users who have been granted the SYSDBA, SYSOPER, SYSASM, SYSBACKUP, SYSDG, and SYSKM administrative privileges.

With external authentication, your database relies on the underlying operating system or network authentication service to restrict access to database accounts. A database password is not used for this type of login. If your operating system or network service permits, then it can authenticate users before they can log in to the database.

You also can use centrally managed users to authenticate and authorize users through a directory service such as Microsoft Active Directory.

Advantages of External Authentication

External authentication provides several advantages.

These advantages are as follows:

  • More choices of authentication mechanisms are available, such as smart cards, fingerprints, Kerberos, or the operating system.

  • Many network authentication services, such as Kerberos support single sign-on, enabling users to have fewer passwords to remember.

  • If you are already using an external mechanism for authentication, such as one of those listed earlier, then there may be less administrative overhead to use that mechanism with the database.

Enabling External Authentication

To enable external authentication, you can set the initialization parameter OS_AUTHENT_PREFIX, and use this prefix in Oracle Database user names.

The OS_AUTHENT_PREFIX parameter defines a prefix that Oracle Database adds to the beginning of the operating system account name of every user. Oracle Database compares the prefixed user name with the Oracle Database user names in the database when a user attempts to connect.

  1. Set OS_AUTHENT_PREFIX to a null string (an empty set of double quotation marks: ""). Using a null string eliminates the addition of any prefix to operating system account names, so that Oracle Database user names exactly match operating system user names.

    For example:

    OS_AUTHENT_PREFIX=" "

  2. Ensure that the OS_AUTHENT_PREFIXremains the same for the life of a database. If you change the prefix, then any database user name that includes the old prefix cannot be used to establish a connection, unless you alter the user name to have it use password authentication.

The default value of the OS_AUTHENT_PREFIX parameter is OPS$ for backward compatibility with previous versions of Oracle Database. For example, assume that you set OS_AUTHENT_PREFIX as follows:

OS_AUTHENT_PREFIX=OPS$

If a user with an operating system account named tsmith is to connect to an Oracle database installation and be authenticated by the operating system, then Oracle Database checks that there is a corresponding database user OPS$tsmith and, if so, lets the user connect. All references to a user authenticated by the operating system must include the prefix, OPS$, as seen in OPS$tsmith.

Note:

The text of the OS_AUTHENT_PREFIX initialization parameter is case-sensitive on some operating systems. See your operating system-specific Oracle Database documentation for more information about this initialization parameter.

Creating a User Who Is Authenticated Externally

Externally authenticated users are authenticated by the operating system or network service.

You can create users who are authenticated externally. Oracle Database then relies on this external login authentication when it provides that specific operating system user with access to the database resources of a specific user.

  • Use the IDENTIFIED EXTERNALLY clause of the CREATE USER statement to create users who are authenticated externally.

The following example creates a user who is identified by Oracle Database and authenticated by the operating system or a network service. This example assumes that the OS_AUTHENT_PREFIX parameter has been set to a blank space (" ").

CREATE USER psmith IDENTIFIED EXTERNALLY;

Authentication of User Logins By Using the Operating System

Oracle Database allows operating system-authenticated logins only over secure connections, which precludes using Oracle Net and a shared server configuration.

This type of operating system authentication is the default. This restriction prevents a remote user from impersonating another operating system user over a network connection.

Setting the REMOTE_OS_AUTHENT parameter to TRUE in the database initialization parameter file forces the database to accept the client operating system user name received over an unsecure connection and use it for account access. Because clients, in general, such as PCs, are not trusted to perform operating system authentication properly, it is very poor security practice to turn on this feature.

The default setting, REMOTE_OS_AUTHENT = FALSE, creates a more secure configuration that enforces proper, server-based authentication of clients connecting to an Oracle database.

Be aware that the REMOTE_OS_AUTHENT parameter was deprecated in Oracle Database 11g Release 1 (11.1), and is retained only for backward compatibility.

Any change to this parameter takes effect the next time you start the instance and mount the database. Generally, user authentication through the host operating system offers faster and more convenient connection to Oracle Database without specifying a separate database user name or password. Also, user entries correspond in the database and operating system audit trails.

Authentication of User Logins Using Network Authentication

Oracle strong authentication performs network authentication, which you can configure to use a third-party service such as Kerberos.

If you are using Oracle strong authentication as your only external authentication service, then the REMOTE_OS_AUTHENT parameter setting is irrelevant, because Oracle strong authentication permits only secure connections.

Multitier Authentication and Authorization

Oracle Database secures middle-tier applications by limiting privileges, preserving client identities through all tiers, and auditing actions by clients.

In applications that use a very busy middle tier, such as a transaction processing monitor, the identity of the clients connecting to the middle tier must be preserved. One advantage of using a middle tier is connection pooling, which allows multiple users to access a data server without each of them needing a separate connection. In such environments, you need to be able to set up and break down connections very quickly.

For these environments, you can use the Oracle Call Interface to create lightweight sessions, which enable database password authentication for each user. This method preserves the identity of the real user through the middle tier without the overhead of a separate database connection for each user.

You can create lightweight sessions with or without passwords. However, if a middle tier is outside of or on a firewall, then security is better when each lightweight session has its own password. For an internal application server, lightweight sessions without passwords might be appropriate.

Administration and Security in Clients, Application Servers, and Database Servers

In a multitier environment, an application server provides data for clients and serves as an interface to one or more database servers.

The application server can validate the credentials of a client, such as a Web browser, and the database server can audit operations performed by the application server. These auditable operations include actions performed by the application server on behalf of clients, such as requests that information be displayed on the client. A request to connect to the database server is an example of an application server operation not related to a specific client.

Authentication in a multitier environment is based on trust regions. Client authentication is the domain of the application server. The application server itself is authenticated by the database server. The following operations take place:

  • The end user provides proof of authenticity to the application server, typically, by using a password or an X.509 certificate.

  • The application server authenticates the end user and then authenticates itself to the database server.

  • The database server authenticates the application server, verifies that the end user exists, and verifies that the application server has the privilege to connect for the end user.

Application servers can also enable roles for an end user on whose behalf they connect. The application server can obtain these roles from a directory, which serves as an authorization repository. The application server can only request that these roles be enabled. The database verifies the following requirements:

  • That the client has these roles by checking its internal role repository

  • That the application server has the privilege to connect on behalf of the user and thus to use these roles as the user could

Figure 3-2 shows an example of multitier authentication.

Figure 3-2 Multitier Authentication

Description of Figure 3-2 follows
Description of "Figure 3-2 Multitier Authentication"

The following actions take place:

  1. The user logs on using a password or Secure Sockets Layer. The authentication information is passed through Oracle Application Server.

  2. Oracle Internet Directory authenticates the user, gets the roles associated with that user from the wallet, and then passes this information back to Oracle Application Server.

  3. Oracle Application Server checks the identity of the user in Oracle Database, which contains a wallet that stores this information, and then sets the role for that user.

Security for middle-tier applications must address the following key issues:

  • Accountability. The database server must be able to distinguish between the actions of the application and the actions an application takes on behalf of a client. It must be possible to audit both kinds of actions.

  • Least privilege. Users and middle tiers should be given the fewest privileges necessary to perform their actions, to reduce the danger of inadvertent or malicious unauthorized activities.

Preserving User Identity in Multitiered Environments

You can use middle tier servers for proxy authentication and client identifiers to identify application users who are not known to the database.

Middle Tier Server Use for Proxy Authentication

Oracle Call Interface (OCI), JDBC/OCI, or JDBC Thin Driver supports the middle tier for proxy authentication for database users or enterprise users.

About Proxy Authentication

Oracle Database provides proxy authentication in Oracle Call Interface (OCI), JDBC/OCI, or JDBC Thin Driver for database users or enterprise users.

Enterprise users are those who are managed in Oracle Internet Directory and who access a shared schema in the database.

You can design a middle-tier server to authenticate clients in a secure fashion by using the following three forms of proxy authentication:

  • The middle-tier server authenticates itself with the database server and a client, in this case an application user or another application, authenticates itself with the middle-tier server. Client identities can be maintained all the way through to the database.

  • The client, in this case a database user, is not authenticated by the middle-tier server. The clients identity and database password are passed through the middle-tier server to the database server for authentication.

  • The client, in this case a global user, is authenticated by the middle-tier server, and passes one of the following through the middle tier for retrieving the client's user name.

    • Distinguished name (DN)

    • Certificate

In all cases, an administrator must authorize the middle-tier server to act on behalf of the client.

Advantages of Proxy Authentication

In multitier environments, proxy authentication preserves client identities and privileges through all tiers in middle-tier applications and by auditing client actions.

For example, this feature allows the identity of a user using a Web application (which acts as a proxy) to be passed through the application to the database server.

Three-tier systems provide the following benefits to organizations:

  • Organizations can separate application logic from data storage, partitioning the former in application servers and the latter in databases.

  • Application servers and Web servers enable users to access data stored in databases.

  • Users like using a familiar, easy-to-use browser interface.

  • Organizations can also lower their cost of computing by replacing many thick clients with numerous thin clients and an application server.

In addition, Oracle Database proxy authentication provides the following security benefits:

  • A limited trust model, by controlling the users on whose behalf middle tiers can connect and the roles that the middle tiers can assume for the user

  • Scalability, by supporting user sessions through OCI, JDBC/OCI, or JDBC Thin driver and eliminating the overhead of reauthenticating clients

  • Accountability, by preserving the identity of the real user through to the database, and enabling auditing of actions taken on behalf of the real user

  • Flexibility, by supporting environments in which users are known to the database, and in which users are merely application users of which the database has no awareness

    Note:

    Oracle Database supports this proxy authentication functionality in three tiers only. It does not support it across multiple middle tiers.

Who Can Create Proxy User Accounts?

To create proxy user accounts, users must have special privileges.

These privileges are as follows:

  • The CREATE USER system privilege to create a database user account that will be used as a proxy user account

  • The DV_ACCTMGR role if Oracle Database Vault is enabled, to create the proxy user account

  • The ability to grant the CREATE SESSION system privilege to the proxy user account

  • The ALTER USER system privilege to enable existing user accounts to connect to the database through the proxy account

Guidelines for Creating Proxy User Accounts

Oracle provides special guidelines for when you create proxy user accounts.

  • For better security and to adhere to the principle of least privilege, only grant the proxy user account the CREATE SESSION privilege. Do not grant this user any other privileges. The proxy user account is designed to only enable another user to connect using the proxy account. Any privileges that must be exercised during the connection should belong to the connecting user, not to the proxy account.

  • As with all passwords, ensure that the password you create for the proxy user is strong and not easily guessed. Remember that multiple users will be connecting as the proxy user, so it is especially important that this password be strong.

  • Consider using the Oracle strong authentication network connection features, to prevent network eavesdropping.

  • For further fine-tuning of the amount of control that the connecting user has, consider restricting the roles used by the connecting user when he or she is connected through the proxy account. The ALTER USER statement WITH ROLE clause enables you to configure the user to connect using specified roles, any role except a specified role, or with no roles at all. Be aware that the proxy user can only activate those roles that are included in the WITH ROLE clause. The proxy user session will have all the privileges that were directly granted to the client (that is, current) user.

  • A proxy user in a proxy session can enable a password-protected role or secure application role only if the role has been allowed to be enabled with the WITH ROLE or WITH ROLE ALL clause. (If this clause is not specified, then WITH ROLE ALL is the default.) If WITH ROLE does not specify the secure roles, then those roles cannot be enabled, even with the correct password.

Creating Proxy User Accounts and Authorizing Users to Connect Through Them

The CREATE USER and ALTER USER statements can be used to create a proxy user and authorize users to connect through it.

A proxy user in a proxy session can enable a password-protected role or secure application role only if the role has been allowed to be enabled with the WITH ROLE or WITH ROLE ALL clause. (If this clause is not specified, then WITH ROLE ALL is the default.) If WITH ROLE does not specify the secure roles, then those roles cannot be enabled, even with the correct password.

  1. Use the CREATE USER statement to create the proxy user account.

    For example:

    CREATE USER appuser IDENTIFIED BY password;

  2. Use the GRANT CONNECT THROUGH clause of the ALTER USER statement to enable an existing user to connect through the proxy user account.

    For example:

    ALTER USER preston GRANT CONNECT THROUGH appuser;


    Be aware that the user name and proxy combination must not exceed 250 characters.

    Suppose user preston has a large number of roles, but you only want her to use one role (for example, the appuser_role) when she is connected to the database through the appuser proxy account. You can use the following ALTER USER statement:

    ALTER USER preston GRANT CONNECT THROUGH appuser WITH ROLE appuser_role;


    Any other roles that user preston has will not be available to her as long as she is connecting as the appuser proxy.

After you complete these steps, user preston can connect using the appuser proxy user as follows:

CONNECT appuser[preston]
Enter password: appuser_password
Proxy User Accounts and the Authorization of Users to Connect Through Them

The CREATE USER statement enables you to create the several types of user accounts, all of which can be used as proxy accounts.

These accounts are as follows:

  • Database user accounts, which are authenticated by passwords

  • External user accounts, which are authenticated by external sources, such as Secure Socket Layer (SSL) or Kerberos

  • Global user accounts, which are authenticated by an enterprise directory service (Oracle Internet Directory).

Note the following:

  • The proxy user can only perform activities that the user preston has privileges to perform. Remember that the proxy user itself, appuser, only has the minimum privileges (CREATE SESSION).

  • Using roles with middle-tier clients. You can also specify roles that the middle tier is permitted to activate when connecting as the client. Operations performed on behalf of a client by a middle-tier server can be audited.

  • Finding proxy users. To find the users who are currently authorized to connect through a middle tier, query the PROXY_USERS data dictionary view, for example:

    SELECT * FROM PROXY_USERS;

  • Removing proxy connections. Use the REVOKE CONNECT THROUGH clause of ALTER USER to disallow a proxy connection. For example, to revoke user preston from connecting through the proxy user appuser, enter the following statement:

    ALTER USER preston REVOKE CONNECT THROUGH appuser;

  • Password expiration and proxy connections. Middle-tier use of password expiration does not apply to accounts that are authenticated through a proxy. Instead, lock the account rather than expire the password.

Using Proxy Authentication with the Secure External Password Store

Use a secure external password store if you are concerned about the password used in proxy authentication being obtained by a malicious user.

To accomplish this, you use the secure external password store with the proxy authentication to store the password credentials in a wallet.

Connecting to Oracle Database using proxy authentication and the secure external password store is ideal for situations such as running batch files. When a proxy user connects to the database and authenticates using a secure external password, the password is not exposed in the event that a malicious user tries to obtain the password.

To use proxy authentication with the secure external password store:

  1. Configure the proxy authentication account, as shown in the procedure in Proxy User Accounts and the Authorization of Users to Connect Through Them.
  2. Configure the secure external password store, as described in About Configuring Clients to Use the External Password Store.

Afterward, the user can connect using the proxy but without having to specify a password. For example:

sqlplus [preston]/@db_alias

When you use the secure external password store, the user logging in does not need to supply the user name and password. Only the SERVICE_NAME value (that is, db_alias) from the tnsnames.ora file must be specified.

How the Identity of the Real User Is Passed with Proxy Authentication

You can use Oracle Call Interface, JDBC/OCI, or Thin drivers for enterprise users or database users.

These tools enable a middle tier to set up several user sessions within a single database connection, each of which uniquely identifies a connected user (connection pooling)

These sessions reduce the network overhead of creating separate network connections from the middle tier to the database.

If you want to authenticate from clients through a middle tier to the database, then the full authentication sequence from the client to the middle tier to the database occurs as follows:

  1. The client authenticates to the middle tier, using whatever form of authentication the middle tier will accept. For example, the client could authenticate to the middle tier by using a user name and password or an X.509 certificate by means of SSL.

  2. The middle tier authenticates itself to the database by using whatever form of authentication the database accepts. This could be a password or an authentication mechanism supported by Oracle Database, such as a Kerberos ticket or an X.509 certificate (SSL).

  3. The middle tier then creates one or more sessions for users using OCI, JDBC/OCI, or Thin driver.

    • If the user is a database user, then the session must, as a minimum, include the database user name. If the database requires it, then the session can include a password (which the database verifies against the password store in the database). The session can also include a list of database roles for the user.

    • If the user is an enterprise user, then the session may provide different information depending on how the user is authenticated.

      Example 1: If the user authenticates to the middle tier using SSL, then the middle tier can provide the DN from the X.509 certificate of the user, or the certificate itself in the session. The database uses the DN to look up the user in Oracle Internet Directory.

      Example 2: If the user is a password-authenticated enterprise user, then the middle tier must provide, as a minimum, a globally unique name for the user. The database uses this name to look up the user in Oracle Internet Directory. If the session also provides a password for the user, then the database will verify the password against Oracle Internet Directory. User roles are automatically retrieved from Oracle Internet Directory after the session is established.

    • The middle tier may optionally provide a list of database roles for the client. These roles are enabled if the proxy is authorized to use the roles on behalf of the client.

  4. The database verifies that the middle tier has the privilege to create sessions on behalf of the user.

    The OCISessionBegin call fails if the application server cannot perform a proxy authentication on behalf of the client by the administrator, or if the application server is not allowed to activate the specified roles.

Limits to the Privileges of the Middle Tier

Least privilege is the principle that users should have the fewest privileges necessary to perform their duties and no more.

As applied to middle tier applications, this means that the middle tier should not have more privileges than it needs.

Oracle Database enables you to limit the middle tier such that it can connect only on behalf of certain database users, using only specific database roles. You can limit the privilege of the middle tier to connect on behalf of an enterprise user, stored in an LDAP directory, by granting to the middle tier the privilege to connect as the mapped database user. For instance, if the enterprise user is mapped to the APPUSER schema, then you must at least grant to the middle tier the ability to connect on behalf of APPUSER. Otherwise, attempts to create a session for the enterprise user will fail.

However, you cannot limit the ability of the middle tier to connect on behalf of enterprise users. For example, suppose that user Sarah wants to connect to the database through a middle tier, appsrv (which is also a database user). Sarah has multiple roles, but it is desirable to restrict the middle tier to use only the clerk role on her behalf.

An administrator can grant permission for appsrv to initiate connections on behalf of Sarah using her clerk role only by using the following SQL statement:

ALTER USER sarah GRANT CONNECT THROUGH appsrv WITH ROLE clerk;

By default, the middle tier cannot create connections for any client. The permission must be granted for each user.

To enable appsrv to use all of the roles granted to the client Sarah, you can use the following statement:

ALTER USER sarah GRANT CONNECT THROUGH appsrv;

Each time a middle tier initiates an OCI, JDBC/OCI, or Thin driver session for another database user, the database verifies that the middle tier is authorized to connect for that user by using the role specified.

Note:

Instead of using default roles, create your own roles and assign only necessary privileges to them. Creating your own roles enables you to control the privileges granted by them and protects you if Oracle Database changes or removes default roles. For example, the CONNECT role now has only the CREATE SESSION privilege, the one most directly needed when connecting to a database. However, CONNECT formerly provided several additional privileges, often not needed or appropriate for most users. Extra privileges can endanger the security of your database and applications. These have now been removed from CONNECT.

A proxy user in a proxy session can enable a password-protected role or secure application role only if the role has been allowed to be enabled with the WITH ROLE or WITH ROLE ALL clause. (If this clause is not specified, then WITH ROLE ALL is the default.) If WITH ROLE does not specify the secure roles, then those roles cannot be enabled, even with the correct password.

Authorizing a Middle Tier to Proxy and Authenticate a User

You can authorize a middle-tier server to connect as a user.

A proxy user in a proxy session can enable a password-protected role or secure application role only if the role has been allowed to be enabled with the WITH ROLE or WITH ROLE ALL clause. (If this clause is not specified, then WITH ROLE ALL is the default.) If WITH ROLE does not specify the secure roles, then those roles cannot be enabled, even with the correct password.

  • To authorize a middle-tier server to connect as a user, use the ALTER USER statement.

The following statement authorizes the middle-tier server appserve to connect as user bill. It uses the WITH ROLE clause to specify that appserve activate all roles associated with bill, except payroll.

ALTER USER bill
    GRANT CONNECT THROUGH appserve
    WITH ROLE ALL EXCEPT payroll;

To revoke the middle-tier server (appserve) authorization to connect as user bill, you can use the REVOKE CONNECT THROUGH clause. For example:

ALTER USER bill REVOKE CONNECT THROUGH appserve;
Authorizing a Middle Tier to Proxy a User Authenticated by Other Means

You can authorize a middle tier to proxy a user that has been authenticated by other means.

Currently, PASSWORD is the only means supported.

  • Use the AUTHENTICATION REQURED clause of the ALTER USER ... GRANT CONNECT THROUGH statement to authorize a user to be proxied, but not authenticated, by a middle tier.

For example:

ALTER USER mary
    GRANT CONNECT THROUGH midtier
    AUTHENTICATION REQUIRED;

In the preceding statement, middle-tier server midtier is authorized to connect as user mary, and midtier must also pass the user password to the database server for authorization.

Reauthenticating a User Through the Middle Tier to the Database

You can specify that authentication is required by using the AUTHENTICATION REQUIRED proxy clause with the ALTER USER SQL statement.

In this case, the middle tier must provide user authentication credentials.

For example, suppose that user Sarah wants to connect to the database through a middle tier, appsrv.

  • To require that appsrv provides authentication credentials for the user Sarah, use the following syntax:

    ALTER USER sarah GRANT CONNECT THROUGH appsrv AUTHENTICATION REQUIRED;


The AUTHENTICATION REQUIRED clause ensures that authentication credentials for the user must be presented when the user is authenticated through the specified proxy.

Note:

For backward compatibility, if you use the AUTHENTICATED USING PASSWORD proxy clause, then Oracle Database transforms it to AUTHENTICATION REQUIRED.

Using Password-Based Proxy Authentication

When you use password-based proxy authentication, Oracle Database passes the password of the client to the middle-tier server.

The middle-tier server then passes the password as an attribute to the data server for verification.

The main advantage to this type of authentication is that the client computer does not have to have Oracle software installed on it to perform database operations.

  • To pass the password of the client, configure the the middle-tier server to call the OCIAttrSet() function as follows, passing OCI_ATTR_PASSWORD as the type of the attribute being set.

    OCIAttrSet(
      session_handle,    /* Pointer to a handle whose attribute gets modified. */
      OCI_HTYPE_SESSION, /* Handle type: OCI user session handle. */
      password_ptr,      /* Pointer to the value of the password attribute. */
      0,                 /* The size of the password attribute value is already
                            known by the OCI library. */
      OCI_ATTR_PASSWORD, /* The attribute type. */
      error_handle);     /* An error handle used to retrieve diagnostic
                            information in the event of an error. */
Using Proxy Authentication with Enterprise Users

How the middle-tier responds for proxy authentication depends on how the user is authenticated, either as an enterprise user or a password-authenticated user.

If the middle tier connects to the database as a client who is an enterprise user, then either the distinguished name, or the X.509 certificate containing the distinguished name is passed over instead of the database user name. If the user is a password-authenticated enterprise user, then the middle tier must provide, as a minimum, a globally unique name for the user. The database uses this name to look up the user in Oracle Internet Directory.

  • To configure proxy authentication with enterprise users, configure the application server and the middle tier to use the appropriate Oracle Call Interface settings:

    • To pass over the distinguished name of the client, configure the application server to call the Oracle Call Interface method OCIAttrSet() with OCI_ATTR_DISTINGUISHED_NAME as the attribute type, as follows:

      OCIAttrSet(session_handle,
                 OCI_HTYPE_SESSION,
                 distinguished_name,
                 0,
                 OCI_ATTR_DISTINGUISHED_NAME,
                 error_handle);

    • To pass over the entire certificate, configure the middle tier to call OCIAttrSet() with OCI_ATTR_CERTIFICATE as the attribute type, as follows:

      OCIAttrSet(session_handle,
                 OCI_HTYPE_SESSION,
                 certificate,
                 certificate_length,
                 OCI_ATTR_CERTIFICATE,
                 error_handle);


If the type is not specified, then the database uses its default certificate type of X.509.

Note:

  • OCI_ATTR_CERTIFICATE is Distinguished Encoding Rules (DER) encoded.

  • Certificate based proxy authentication using OCI_ATTR_CERTIFICATE will not be supported in future Oracle Database releases. Use the OCI_ATTR_DISTINGUISHED_NAME or OCI_ATTR_USERNAME attribute instead

If you are using proxy authentication for password-authenticated enterprise users, then use the same OCI attributes as for database users authenticated by password (OCI_ATTR_USERNAME). Oracle Database first checks the user name against the database. If it finds no user, then the database checks the user name in the directory. This user name must be globally unique.

Using Client Identifiers to Identify Application Users Unknown to the Database

Client identifiers preserve user identity in middle tier systems; they also can be used independently of the global application context.

About Client Identifiers

Oracle Database provides the CLIENT_IDENTIFIER attribute of the built-in USERENV application context namespace for application users.

These application users are known to an application but unknown to the database. The CLIENT_IDENTIFIER attribute can capture any value that the application uses for identification or access control, and passes it to the database. The CLIENT_IDENTIFIER attribute is supported in OCI, JDBC/OCI, or Thin driver.

How Client Identifiers Work in Middle Tier Systems

Many applications use session pooling to set up several sessions to be reused by multiple application users.

Users authenticate themselves to a middle-tier application, which uses a single identity to log in to the database and maintains all the user connections. In this model, application users are users who are authenticated to the middle tier of an application, but who are not known to the database. You can use a CLIENT_IDENTIFIER attribute, which acts like an application user proxy for these types of applications.

In this model, the middle tier passes a client identifier to the database upon the session establishment. The client identifier could actually be anything that represents a client connecting to the middle tier, for example, a cookie or an IP address. The client identifier, representing the application user, is available in user session information and can also be accessed with an application context (by using the USERENV naming context). In this way, applications can set up and reuse sessions, while still being able to keep track of the application user in the session. Applications can reset the client identifier and thus reuse the session for a different user, enabling high performance.

Use of the CLIENT_IDENTIFIER Attribute to Preserve User Identity

The CLIENT_IDENTIFIER predefined attribute of the built-in application context namespace, USERENV, captures the application user name for use with a global application context.

You also can use the CLIENT_IDENTIFIER attribute independently.

When you use the CLIENT_IDENTIFIER attribute independently from a global application context, you can set CLIENT_IDENTIFIER with the DBMS_SESSION interface. The ability to pass a CLIENT_IDENTIFIER to the database is supported in Oracle Call Interface (OCI), JDBC/OCI, or Thin driver.

When you use the CLIENT_IDENTIFIER attribute with global application context, it provides flexibility and high performance for building applications. For example, suppose a Web-based application that provides information to business partners has three types of users: gold partner, silver partner, and bronze partner, representing different levels of information available. Instead of each user having his or her own session set up with individual application contexts, the application could set up global application contexts for gold partners, silver partners, and bronze partners. Then, use the CLIENT_IDENTIFIER to point the session at the correct context to retrieve the appropriate type of data. The application need only initialize the three global contexts once and use the CLIENT_IDENTIFIER to access the correct application context to limit data access. This provides performance benefits through session reuse and through accessing global application contexts set up once, instead of having to initialize application contexts for each session individually.

Use of the CLIENT_IDENTIFIER Independent of Global Application Context

Using the CLIENT_IDENTIFIER attribute is especially useful for those applications in which the users are unknown to the database.

In these situations, the application typically connects as a single database user and all actions are taken as that user.

Because all user sessions are created as the same user, this security model makes it difficult to achieve data separation for each user. These applications can use the CLIENT_IDENTIFIER attribute to preserve the real application user identity through to the database.

With this approach, sessions can be reused by multiple users by changing the value of the CLIENT_IDENTIFIER attribute, which captures the name of the real application user. This avoids the overhead of setting up a separate session and separate attributes for each user, and enables reuse of sessions by the application. When the CLIENT_IDENTIFIER attribute value changes, the change is added to the next OCI, JDBC/OCI, or Thin driver call for additional performance benefits.

For example, the user Daniel connects to a Web Expense application. Daniel is not a database user; he is a typical Web Expense application user. The application accesses the built-in application context namespace and sets DANIEL as the CLIENT_IDENTIFIER attribute value. Daniel completes his Web Expense form and exits the application. Then, Ajit connects to the Web Expense application. Instead of setting up a new session for Ajit, the application reuses the session that currently exists for Daniel, by changing the CLIENT_IDENTIFIER to AJIT. This avoids the overhead of setting up a new connection to the database and the overhead of setting up a global application context. The CLIENT_IDENTIFIER attribute can be set to any value on which the application bases access control. It does not have to be the application user name.

Setting the CLIENT_IDENTIFIER Independent of Global Application Context

You can set the CLIENT_IDENTIFIER setting with Oracle Call Interface to be independent of the global application context.

  • To set the CLIENT_IDENTIFIER attribute with OCI, use the OCI_ATTR_CLIENT_IDENTIFIER attribute in the call to OCIAttrSet(). Then, on the next request to the server, the information is propagated and stored in the server sessions.

For example:

OCIAttrSet (session,
OCI_HTYPE_SESSION,
(dvoid *) "appuser1",
(ub4)strlen("appuser1"),
OCI_ATTR_CLIENT_IDENTIFIER,
*error_handle);

For applications that use JDBC, be aware that JDBC does not set the client identifier. To set the client identifier in a connection pooling environment, use Dynamic Monitoring Service (DMS) metrics. If DMS is not available, then use the connection.setClientInfo method. For example:

connection.setClientInfo("E2E_CONTEXT.CLIENT_IDENTIFIER", "appuser");

See Also:

Use of the DBMS_SESSION PL/SQL Package to Set and Clear the Client Identifier

The DBMS_SESSION PL/SQL package manages client identifiers on both the middle tier and the database itself.

To use the DBMS_SESSION package to set and clear the CLIENT_IDENTIFIER value on the middle tier, you must use the SET_IDENTIFIER and CLEAR_IDENTIFIER procedures.

The middle tier uses SET_IDENTIFIER to associate the database session with a particular user or group. Then, the CLIENT_IDENTIFIER is an attribute of the session and can be viewed in session information.

If you plan to use the DBMS_SESSION.SET_IDENTIFIER procedure, then be aware of the following:

  • The maximum number of bytes for the client_id parameter of DBMS_SESSION.SET_IDENTIFIER is 64 bytes. If it exceeds 64, then the additional bytes are truncated.

  • The DBMS_APPLICATION_INFO.SET_CLIENT_INFO procedure can overwrite the value of the client identifier. Typically, these values should be the same, so if SET_CLIENT_INFO is set, then its value can be automatically propagated to the value set by SET_IDENTIFIER if the CLIENTID_OVERWRITE event is set to ON. You can check the status of the CLIENTID_OVERWRITE event by running the SHOW PARAMETER command for the EVENT parameter.

    For example, assuming that CLIENTID_OVERWRITE is enabled:

    SHOW PARAMETER EVENT

    NAME                           TYPE               VALUE
    ------------------------------ ------------------ ------------------
    event                          string             clientid_overwrite
Enabling the CLIENTID_OVERWRITE Event System-Wide

The ALTER SYSTEM statement can enable the CLIENTID_OVERWRITE event system-wide.

  1. Enter the following ALTER SYSTEM statement:
    ALTER SYSTEM SET EVENTS 'CLIENTID_OVERWRITE';


    Or, enter the following line in your init.ora file:

    event="clientid_overwrite"

  2. Restart the database.

    For example:

    SHUTDOWN IMMEDIATE
    STARTUP

See Also:

Enabling the CLIENTID_OVERWRITE Event for the Current Session

The ALTER SESSION statement can enable the CLIENTID_OVERWRITE event for the current session only.

  1. Use the ALTER SESSION statement to set the CLIENTID_OVERWRITE value for the session only.

    For example:

    ALTER SESSION SET EVENTS 'CLIENTID_OVERWRITE OFF';

  2. If you set the client identifier by using the DBMS_APPLICATION_INFO.SET_CLIENT_INFO procedure, then run DBMS_SESSION.SET_IDENTIFIER so that the client identifier settings are the same.

    For example:

    DBMS_SESSION.SET_IDENTIFIER(session_id_p);
Disabling the CLIENTID_OVERWRITE Event

The ALTER SYSTEM statement can disable the CLIENTID_OVERWRITE event.

  1. Enter the following ALTER SYSTEM statement:
    ALTER SYSTEM SET EVENTS 'CLIENTID_OVERWRITE OFF';

  2. Restart the database.

    For example:

    SHUTDOWN IMMEDIATE
    STARTUP

User Authentication Data Dictionary Views

Oracle Database provides data dictionary views that list information about user authentication, such as roles that users have or profiles they use.

Table 3-4 lists the data dictionary views. For detailed information about these views, see Oracle Database Reference.

Table 3-4 Data Dictionary Views That Describe User Authentication

View Description

DBA_PROFILES

Displays information about profiles, including their settings and limits

DBA_ROLES

Displays the kind of authentication used for a database role to log in to the database, such as NONE or GLOBAL (query the AUTHENTICATION_TYPE column)

DBA_USERS

Among other user information, displays the following:

  • The kind of authentication the user used to log in to the database, such as PASSWORD or EXTERNAL (AUTHENTICATION_TYPE column)

  • The list of versions of password versions (also known as hashes) that exist for the user account (PASSWORD_VERSIONS column)

DBA_USERS_WITH_DEFPWD

Displays whether the user account password is a default password

PROXY_USERS

Displays users who are currently authorized to connect through a middle tier

V$DBLINK

Displays user accounts for existing database links (DB_LINK, OWNER_ID columns); applies to the current pluggable database (PDB)

V$PWFILE

Lists the names and granted administrative privileges of the administrative users who are included in the password file

V$SESSION

Querying the USERNAME column displays concurrently logged in users to the current PDB
